Freud RTS5000 Instructions

WARNING
FAILURE TO HEED THESE WARNINGS COULD LEAD TO SERIOUS BODILY INJURY OR DEATH.
• Always wear eye protection complying with current ANSI standard Z87.1.
• Always set table base on level ground or floor surface.
• Table base must be sturdily constructed and securely fastened to the table top.
• Ensure that the assembled router table will not slide, roll or topple during use.
• Before each use, ensure that the router table, router table base, router fence, router and router bit are all free from damage.
• Do not use if damage is noticed or suspected.
• Do not use a router that exceeds 3- 1 ⁄ HP with this router table system.
2
• Keep guards in place. Do not use if guards are damaged or have been removed.
• Read and obey all warnings and instructions contained in router's operator manual and the router bits packaging. If you do
not have the operator's manuals, obtain one from the manufacturer before using.
• Before each use check that router bit is sharp. Never use a router bit that is dull.
• Keep body and clothing clear of spinning bit.
• Before each use ensure that at least 80% of the router bit shank is inserted in the collet of the router. Do not,
however, ''bottom-out'' the bit in the collet. The end of the bit shank should be about 1/8 inch from the bottom of the collet.
• Before each use ensure that the collet of the router has been tightened.
• Use router fence whenever possible.
• Use multiple passes when removing large quantities of material.
• Never use a router bit on a router that will exceed maximum recommended RPM of bit.
Maximum Recommended Router Speeds For Freud Router Bits
Bit Diam.
1''
1
1- / ''
4
1
2- / ''
4
1
3- / ''
2
• Please keep these warnings and instructions in a safe place for future reference.
FREUD LIMITED ONE YEAR ROUTER TABLE WARRANTY
Freud warrants to the original consumer purchaser that each new Freud Router Table System shall be free from defects in material and workmanship for
a period of one (1) year from the purchase date. When warranty service is requested, proof of purchase (e.g., invoice) is required. Should the Router Table
System fail within thirty (30) days from the date of purchase, it will be repaired or replaced AT THE CUSTOMER'S OPTION, subject to the Guidelines
below. Thereafter, upon verification of failure or malfunction, Freud shall, at its option, within sixty (60) days, repair or replace the power tool, subject to
the Guidelines below.
1. In the event of failure or malfunction, return the product, properly packaged and postage prepaid, to Freud at the address listed below or to an
authorized Freud tool service station. You may also contact Freud at (336) 434-3171 for instructions on returns and technical advice.
2. All implied warranties for Freud's power tools (INCLUDING MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE) are limited to the period
of one year from the purchase date. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not
apply to you.
3. A warranty claim shall be limited to repair or replacement as stated in Freud's Limited Router Table Warranty, and in no event shall Freud be liable for
any other direct, indirect, incidental or consequential damages, costs or expenses. INCIDENTAL AND CONSEQUENTIAL DAMAGES ARE EXCLUDED
UNDER ALL WARRANTIES. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or
exclusion may not apply to you.
4. Freud warranties give you specific legal rights, and you may also have other rights which vary from state to state or province to province.
5. Freud warranties shall not be deemed to have failed their essential purpose while Freud is willing to repair or replace defective products.
6. Freud assumes no liability for defects or damage caused by abuse or misuse of any product or unauthorized service of any product. The product
must have been used for its recommended purpose, not modified or changed. Normal wear and tear is not covered under Freud warranties.
7. Any action for breach of warranty must be commenced within one year after the accrual of the cause of action.
To obtain service under Freud warranties, contact an authorized repair station or:
Max. Speed
24000 RPM
l8000 RPM
I6000 RPM
I2000 RPM
GUIDELINES
Freud America, Inc.
(Attn: Customer Services)
218 Feld Avenue
High Point, North Carolina, 27263
(800) 472-7307
® RTS5000
Presicion Router Table System
with Dual Adjustable Fence System
SET UP
INSTRUCTIONS
FOR MODELS:
RTS5000
RTS5220
RTS5300
5/2007
