Specifications - Audio Note M8 Phono Owner's Information

If you require technical support or have any questions, please direct them to your
local Audio Note dealer or alternatively contact us directly at:
Customer Support
Audio Note (UK) Limited
25 Montefiore Road
HOVE
East Sussex
BN3 1RD
United Kingdom
TEL: +44 (0)1273 220511
FAX: +44 (0)1273 731498
EMAIL: info@audionote.co.uk

Specifications

Weight
Dimensions
Max Power Consumption
Fuse Ratings
Input Impedance
Gain @ 1kHz
Input Sensitivity
Output Noise (rms)
Output Impedance
Tube Compliment
NOTE: Due to Audio Note's ongoing research and development programme,
specifications are due to change without notice.
16kg
141(h) x 445(w) x 410(d) mm
81W
1A anti-surge (110/120 V supply)
500mA anti-surge (220/240 V supply)
100kO, Line
47kO, Phono
18dB, Line
65dB, Phono
126mV, Line
< 0.08mV, Line unweighted
< 12mV, Phono unweighted
< 10O
1x ECC82, 1x 6463, 2x 6X5, 2x ECL82, 2x OB2, 3x CV4068
