Connections
Please ensure that the M8 Phono, the power amplifier and any source equipment is
switched off before making any connections.
NOTE: It is important that all connections are firm, secure and airtight; any
oxidisation of the interconnects will result in loss of performance. Always use high
quality interconnects; Audio Note interconnects are recommended, as they are
manufactured to the same exacting standards as all of our products.
Inputs
The M8 Phono offers three standard unbalanced line inputs, one phono input and a
tape input. The inputs each consist of a pair of RCA connectors, one red and one
white, for right and left channels respectively.
The line inputs and tape input are suitable for connection to any line level source
equipment, such as a CD or DVD player.
The phono input is suitable for connection to a turntable with a moving magnet (MM)
type cartridge. Turntables with moving coil (MC) type cartridges will require a step-
up transformer between the turntable and the pre-amplifier; Audio Note produce some
of the best step-up transformers available.
Outputs
The M8 Phono provides two unbalanced outputs and a tape output. Again, all of these
outputs consist of a pair of colour coded RCA connectors.
The two main outputs are for connection to a power amplifier and are identical,
making them suitable for biwiring.
The tape output is routed directly from the input selection switch; this provides a
suitable level for recording. The tape input is not routed to the tape output.
Ground Post
A ground connection is provided to assist in the elimination of any ground loops that
may occur. A ground loop can be identified by excessive background hum. If you
experience a ground loop, try connecting the ground connection with that of other
system components. If the hum persists, contact your dealer.

Mains Power

An IEC power connector is located on the back of the M8 Phono. Use the supplied
power cable to connect the pre-amplifier to the mains supply. Ensure the power is off
at the switch when you do this.
