- Page 1 SAMSUNG LCD Projection TV SERVICE GUIDE *Supercedes and appends service manual data Covers Models: (L52A & L56A-Chassis) PLH403W, PLH403W1, PLH403WS, PLH403W3, PLH403WS3 PLK435WS, PLK405W SLJ402W, SLK407W Last update: 4/18//01...
-
Page 2: Table Of Contents
SAMSUNG LCD Projection TV SERVICE GUIDE Table of Contents Sections 1. How to Use This Guide 2. Service Bulletins 3. Flow Charts 4. Parts Data 5. Assembly/Disassembly 6. Escalation/Who to Call Last update: 4/18//01... -
Page 3: How To Use This Guide
3. If the previous steps do lead to a clear diagnosis, then proceed to the flow chart in section 3 to help assist you in determining the correct PCB’s to order. 4. Place order through Samsung Parts Department. Note: Distributors DO NOT carry PCB’s, so backorder with no eta will result. Parts Department will not accept an order for PTV parts without a serial number because correct ID cannot be assured. - Page 4 SAMSUNG PROJECTION TV SERVICE GUIDE Section 2 - Service Bulletins SERVICE BULLETIN PRODUCT: PJT BULLETIN: LCD-01 MODEL: PLH403W Subject: Microprocessor (IC901) software upgrade. Background: 1. During channel up / down, a pop noise is heard when connected to the “Monitor Audio / Video Output Jacks”.
-
Page 5: Service Bulletins
SAMSUNG PROJECTION TV SERVICE GUIDE Section 2 - Service Bulletins SERVICE BULLETIN PRODUCT: PJT BULLETIN: LCD-02 MODEL: All LCD models Subject: White balance and gamma adjustment. Background: When the white balance and gamma adjustment can not be performed by visual method, refer to method using test equipment. -
Page 6: Flow Charts
SAMSUNG PROJECTION TV SERVICE GUIDE Section 3 - Flow Charts power repair flow chart video repair flow chart video power supply switch detect AP2 pins 3, 6 and 8 switch is closed pin 3 = 8 volts dc, pin 6 = 12 volts dc... -
Page 7: Parts Data
SAMSUNG PROJECTION TV SERVICE GUIDE Section 4 - Parts Data Name Model Part No. Description Main PLH403W AA94-10144F ASSY-PCB,MAIN(OPT);SPT-403JA,L52A,U.S.A, PLH403W1 AA94-01720A ASSY-PCB,MAIN(OPT);PLH403W1X/XAA,L52A,US PLH403WS AA94-02019A ASSY PCB MAIN(OPT);PLH403WSX/XAA,L52A,US PLH403W3 AA94-01956A ASSY PCB MAIN(OPT);SLK407WX,L56A,KOREA,- PLH403WS3 AA94-01956B ASSY PCB MAIN(OPT);PLH403WS3X/XAA,L56A,U SLJ402W AA94-01203A ASSY-PCB,MAIN(OPT);SLJ402WX/XAA,L52A,USA... -
Page 8: Assembly/Disassembly
SAMSUNG PROJECTION TV SERVICE GUIDE Section 5 - Assembly/Disassembly Dis-assembly Procedure Dis-assembly Procedure 1. Open bottom cabinet 2.Unscrew bracket-back 3.Unscrew Bottom screw 4.Unscrew Bottom screw below 2screw 5.open Flat cable and 2 screw 6.open connector Last update: 4/18//01... - Page 9 SAMSUNG PROJECTION TV SERVICE GUIDE Section 5 - Assembly/Disassembly 7.unscrew 1 screw 8.exchange Optical Engine Last update: 4/18//01...
-
Page 10: Escalation/Who To Call
SAMSUNG PROJECTION TV SERVICE GUIDE Section 6 - Escalation/Who to Call Escalation Paths and Technical Support 1. Parts Issues If wrong or defective parts are received, contact Parts Department with the invoice or PO numbers to resolve. If the parts do not fix the problem and you need technical assistance: 973-601-6124 between 9:00 –...
