Emulex StorageTek 4 Gb FC Host Bus Owner's Manual page 14

TABLE 2
Green LED
On
On
Slow Blink
Slow Blink
Slow Blink
Slow Blink
Slow Blink
Fast blink
Fast blink
Fast blink
Fast blink
Fast blink
When attaching the optical cable, be sure to:
1. Connect the fiber-optic cable to an LC connector on the HBA (see
Port 0
Port 1
FIGURE 3
2. Connect the other end of the cable to the Fibre Channel device.
6 Sun StorageTek PCI Express Enterprise 4 Gb FC HBA Emulex Installation Guide • December 2005
LED Status (Continued)
Yellow LED
2 Fast Blinks
3 Fast Blinks
Off
On
Slow Blink
Fast Blink
Flashing
Off
On
Slow Blink
Fast Blink
Flashing
Attaching the Optical Cable
State
2 Gb Link Rate – Normal, Link up
4 Gb Link Rate – Normal, Link up
Normal – Link Down
Not Defined
Off-line for Download
Restricted Off-line Mode (Waiting for Restart)
Restricted Off-line Mode, test active
Debug Monitor in Restricted Mode
Not Defined
Debug Monitor in Test Fixture Mode
Debug Monitor in Remote Debug Mode
Not Defined
).
FIGURE 3
