External Features

This section describes the external features of the DP-101 print server.

Front End

The DP-101 printer port is located at the front.
Printer Port
The printer port, is configurable by commands in the PS Admin program, or by commands issued
to the DP-101 via Telnet. See the PS Admin User's Guide for configuration procedures.

Rear End

The network port, power input socket, and LED indicators are all located at the rear .
Led Indicators
DP-101 Front End
Network Port
DP-101 Rear End
Introduction
DP-101 Print Server Hardware Guide
DC Power
Input
3
