Cpu Q-Fan Control [Enabled]; Chassis Q-Fan Control [Enabled] - Asus P8H61-M2 TPM SI User Manual

2.6.3

CPU Q-Fan Control [Enabled]

[Disabled]
[Enabled]
CPU Fan Speed Low Limit [600 RPM]
This item appears only when you enable the CPU Q-Fan Control feature and allows
you to disable or set the CPU fan warning speed.
Configuration options: [Ignore] [200RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM]
CPU Fan Profile [Standard]
This item appears only when you enable the CPU Q-Fan Control feature and allows
you to set the appropriate performance level of the CPU fan.
[Standard] Sets to [Standard] to make the CPU fan automatically adjust depending on
[Silent]
[Turbo]
[Manual]
The following four items appear only when you set CPU Fan Profile to [Manual].
CPU Upper Temperature [70ºC]
Use the <+> and <-> keys to adjust the upper limit of the CPU temperature. The values range
from 20ºC to 75ºC.
CPU Fan Max. Duty Cycle(%) [100%]
Use the <+> and <-> keys to adjust the maximum CPU fan duty cycle. The values range from
20% to 100%. When the CPU temperature reaches the upper limit, the CPU fan will operate at
the maximum duty cycle.
CPU Lower Temperature [20ºC]
Use the <+> and <-> keys to adjust the lower limit of the CPU temperature. The values range
from 20ºC to 75ºC
CPU Fan Min. Duty Cycle(%) [20%]
Use the <+> and <-> keys to adjust the minimum CPU fan duty cycle. The values range from 0%
to 100%. When the CPU / Chassis temperature is under the lower limit, the CPU fan will operate
at the minimum duty cycle.
2.6.4

Chassis Q-Fan Control [Enabled]

[Disabled]
[Enabled]
Chassis Fan Speed Low Limit [600 RPM]
This item appears only when you enable the Chassis Q-Fan Control feature and
allows you to disable or set the chassis fan warning speed.
Configuration options: [Ignore] [200RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM]
2-22
Disables the CPU Q-Fan control feature.
Enables the CPU Q-Fan control feature.
the CPU temperature.
Sets to [Silent] to minimize the fan speed for quiet CPU fan operation.
Sets to [Turbo] to achieve maximum CPU fan speed.
Sets to [Manual] to assign detailed fan speed control parameters.
Disables the Chassis Q-Fan control feature.
Enables the Chassis Q-Fan control feature.
ASUS P8H61-M2 Series
