OWNER'S
MANUAL
9-INCH COLOR TV/VCR
EWC0902
This Owner's Manual is made of
recycled paper.
As an E
S
NERGY
TAR
Partner, our company has
determined that this product meets
the E
S
®
guidelines for
NERGY
TAR
energy efficiency. E
S
NERGY
a U.S. registered mark.
®
If you need additional assistance for set-up or operating
®
is
TAR
after reading owner's manual, please call
TOLL FREE : 1-800-256-2487.
"EMERSON AND THE G-CLEF LOGO ARE REGISTERED TRADEMARKS
OF EMERSON RADIO CORP., PARSIPPANY, NEW JERSEY, U.S.A."
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
Please read before using this equipment

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EWC0902 and is the answer not in the manual?

Questions and answers

Related Manuals for Emerson EWC0902

Summary of Contents for Emerson EWC0902

  • Page 1 ® energy efficiency. E NERGY a U.S. registered mark. “EMERSON AND THE G-CLEF LOGO ARE REGISTERED TRADEMARKS OF EMERSON RADIO CORP., PARSIPPANY, NEW JERSEY, U.S.A.” INSTRUCCIONES EN ESPAÑOL INCLUIDAS. If you need additional assistance for set-up or operating after reading owner’s manual, please call TOLL FREE : 1-800-256-2487.

  • Page 2: Important Safeguards

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
  • Page 3 EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECT RICAL CODE NEC - NATI O NAL EL ECTRI CAL CO DE S2 8 9 8 A 13.Outdoor Antenna grounding-If an outside antenna or cable system is connected to the TV/VCR, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.

  • Page 4: Avoid The Hazards Of Electrical Shock And Fire

    LOCATION For safe operation and satisfactory performance of your TV/VCR, keep the following in mind when selecting a place for its installation: • Shield it from direct sunlight and keep it away from sources of intense heat. • Avoid dusty or humid places. •...

  • Page 5: Table Of Contents

    C IMPORTANT SAFEGUARDS ... . .2 C PRECAUTIONS ......4 C FEATURES .

  • Page 6: C Features

    • nfrared remote control • Bilingual on screen menu display selectable in English or Spanish • This shows the elapsed recording or Real time counter– playback time in hours, minutes, and seconds. The “–” indication will appear when the tape is rewound further than the tape counter position “0:00:00”.

  • Page 7: Operating Controls And Functions

    OPERATING CONTROLS AND FUNCTIONS - TV/VCR FRONT PANEL - AUDIO VIDEO 3 4 5 - REMOTE CONTROL - WAKE-UP POWER /SLEEP +100 MENU DISPLAY MUTE PLAY STOP RECORD SPEED T-PROG. GAME CLEAR COUNTER RESET Connect to the audio output AUDIO input jack– jack of your audio equipment, video camera or another VCR.
  • Page 8 - REAR VIEW - Press for manual recording. REC button– Activates One Touch Recording. OTR button– (only on the TV/VCR) Adjust the volume VOLUME buttons– level. Press to select the CHANNEL buttons– desired channels for viewing or recording. You may display the main menu on the TV screen by pressing repeatedly this button on the TV/VCR.

  • Page 9: Preparation For Use

    PREPARATION FOR USE From Cable System or Satellite Dish Satellite Box or Cable Box O UT (Not supplied) From Cable System 75-ohm Coaxial Cable (Not supplied) ANTENNA/CABLE CONNECTIONS DIPOLE ANTENNA HOOK UP 1. Push the stem of the Dipole Antenna (accessory) into the hole for antenna at the back of TV/VCR.

  • Page 10: Installing The Batteries

    CABLE WITH CONVERTER/ DESCRAMBLER BOX OR SATELLITE If your cable service supplies you with a converter box or if you use a satellite system, you can use the basic connection shown in drawing. By using this connection you can also record scram- bled channels.

  • Page 11: C Set Up For Use

    You can program the tuner to scan all the channels you receive in your area. NOTE: Channel memory programming is NOT needed when connected to a cable box or satellite box. Just select the TV/VCR channel selector to the output channel of the cable box or satellite box (Ex CH3). Then select the channel to be viewed on the Cable Box or Satellite Box.

  • Page 12: Manual Clock Setting

    NOTES: • Auto clock setting only needs to be set once. But it can be done again if the clock’s time has become incorrect for some reason. • If the TV/VCR is connected directly to a cable converter box or satellite box, the local PBS station must be selected on the cable box itself, and the TV/VCR must be set to the output channel of the cable converter box or satellite box (usually chan-...

  • Page 13: Channel Set Up Again

    Select the year Press the PLAY/K or STOP/L but- ton until your desired year appears. (Example: 2002) Then, press the F.FWD/B button. Select the hour Press the PLAY/K or STOP/L but- ton until your desired hour appears. (Example: 5, PM) Then, press the F.FWD/B button.

  • Page 14: Selecting The Language

    Delete (or add) it from (into) memory Press the F.FWD/B or REW/s button. The channel number changes to light red. The channel is deleted from memory. • To delete another channel, repeat steps [3] and [4]. • If you press the F.FWD/B or REW/s button again, the channel is memorized again.

  • Page 15: C Tv Operation

    WATCHING A TV PROGRAM Turn on the TV/VCR Press the POWER button to turn on the TV/VCR. Select the channel number Press the CHANNEL K or L button to select your desired channel number or press the number buttons on the remote control. Remember: If the TV/VCR is connected to a cable box or satellite box, the TV/VCR must be on CH3 or CH4, then the channel to be viewed must be selected...

  • Page 16: C Playback

    This TV/VCR will operate with any cassette that has the recommend the use of high-quality tapes. Do not use poor quality or damaged tapes. INSERTING A CASSETTE Insert the cassette in the direction as shown. Push in gently, but continuously, on the center-back of the cassette until it is drawn into the TV/VCR.

  • Page 17: Search

    SEARCH PICTURE SEARCH This feature is very useful in finding or skipping over a particular scene on a tape. In this mode, the sound will be muted. 1)You may view a video tape at a high speed in either a forward or reverse direction by pressing the F.FWD or REW button.

  • Page 18: Noise Cancel (In The Still Mode)

    NOISE CANCEL (in the Still mode) This feature allows you to reposition or reduce the noise lines of a still picture. Press the PAUSE/STILL button so that the noise lines change position on the screen so you can see the picture in its entirety with- out distracting noise lines.

  • Page 19: Normal Recording

    Make sure ... • TV/VCR power must be turned on. • Insert a cassette tape with its erase prevention tab in place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.) NOTE: This unit will ONLY record and view the same channel.

  • Page 20: Timer Recording

    Begin OTR Press the REC/OTR button on the TV/VCR as many times as needed. The recording length will be deter- mined by the number of times you press the REC/OTR button. Each additional push will increase the recording time by 30 minutes.

  • Page 21: To Correct A Program

    For every day recording : To record a TV program at the same time on the same channel every day. (Example: Monday through Sunday) Press the STOP/L (down) button until “EVRY DAY” appears. Then, press the F.FWD/B but- ton. For weekly recording : To record a TV program at the same time on the same channel every week.

  • Page 22: Hints For Automatic Timer Recording

    TO CANCEL AN AUTOMATIC TIMER RECORDING • After setting a program; 1)Press the POWER button. 2)Repeat steps [1] ~ [2] on page 20 and select a program you want to cancel. 3)Press the T-PROG. CLEAR button. 4)Press the MENU button on the remote control to return to TV mode.

  • Page 23: Sleep Timer

    Set wake up time Press the PLAY/K or STOP/L but- ton until to point to “TIME”. Press the F.FWD/B or REW/s button until your desired wake up time appears. Each additional push will increase (or decrease) the time by 10 minutes. Exit the Wake Up Timer setting Press the MENU button on the remote control to return to TV mode.

  • Page 24: C On Screen Display

    To check the Counter, Clock and Channel number on the TV screen, press the DISPLAY button on the remote control. Each time you press the DISPLAY button on the remote control, the TV screen will change as follows: • Counter mode: After 5 seconds, only the counter remains.

  • Page 25: Troubleshooting Guide

    TROUBLESHOOTING GUIDE If you have followed the instructions contained in this manual and have difficulty in operating your TV/VCR, locate the PROBLEM in the left column below. Check the corresponding CORRECTIVE ACTION column to remedy the problem. PROBLEM No power. No picture and sound.

  • Page 26: Electrical Specifications

    GENERAL SPECIFICATIONS CRT : 9 inch in-line gun, 90˚ deflection tube Television system : NTSC-M Video Heads : Rotary two-head Tape width : 1/2 inch Tape speed SP : 33.40mm/sec. LP : 16.67mm/sec. SLP : 11.12mm/sec. Tuner channel TV VHF Low : #2~#6 TV VHF High : #7~#13...
  • Page 27 CONTROLES DE OPERACIÓN Y SUS FUNCIONES NOTA: No recomendamos utilizar mandos a distancia universales. No todas las funciones pueden ser controladas mediante un mando a distancia universal. Si decide utilizar un mando a distancia universal con esta unidad, tenga en cuenta que con el número de código dado tal vez no se pueda controlar la unidad.

  • Page 28: Panel Trasero

    - PANEL TRASERO - Botones de volumen (VOLUME X X / Y Y )– volumen. Botones de canales (CHANNEL K/ L)– cionar los canales deseados para ver o grabar. Se puede mostrar el menú principal en la pantalla del televisor pulsando repetidamente este botón del televisor/videograbadora.

  • Page 29: Conexiones De Antena/Cable

    CONEXIONES DE ANTENA/CABLE Desde el cable coaxil o caja de emisiones vía satélite de 75 ohm del sistema de Cable O UT Caja de CATV o caja de emi- siones vía satélite (no incluído) Desde el sistema de Cable Cable coaxil de 75 ohm (no incluído) CONEXION DE LA ANTENA BIPOLAR...

  • Page 30: Modo De Entrada Externa

    CONEXION MOVIL ADVERTENCIA: El conductor nunca debe ver programas del televisor o del videobgrabadora mientras está con- duciendo un vehículo. PRECAUCIÓN: Si usted usa la TV/VCR con el motor del vehículo apagado, recargue la batería del vehículo aprox. cada 4 horas de uso, para evitar que ésta se agote. Cuando termine de usar la TV/VCR, siempre desenchufe el cordón para la batería del automóvil del zócalo del encendedor de cigarrillos.

  • Page 31: Preparación De Canales Por Primera Vez

    PREPARACIÓN DE CANALES POR PRIMERA VEZ 1) Conecte el extremo más prqueño del cordón de CA al conector de CA de 120V en la parte posterior de la TV/VCR. Luego, enchufe el otro extremo enun tomacorriente normal de CA. NOTAS: •...

  • Page 32: Limited Warranty

    FUNAI CORP. RESERVES THE RIGHT TO MODIFY ANY DESIGN OF THIS PRODUCT WITHOUT PRIOR NOTICE. To locate your nearest Emerson Authorized Service Center or for general service procedure, please call 1-800-256-2487 or write to the following: PLEASE DO NOT SHIP YOUR UNIT TO THE TETERBORO ADDRESS.
