Operator's
Manual
DANGER is used in this manual to warn of high
voltages capable of causing shock, burns, or death.
WARNING is used in this manual to warn
of possible personal injury.
CAUTION is used in this manual to warn
of possible equipment damage.
50 Hanover Road, Florham Park, New Jersey 07932-1591 USA
For sales or service call 1 800 800-2726 (ASCO) www.ascopower.com
ASCO POWER TECHNOLOGIES CANADA PO Box 1238, 17 Airport Road, Brantford, Ontario, Canada N3T 5T3
telephone 519 758-8450, fax 519 758-0876, for service call 1 888 234-2726 (ASCO)
7000 Series 7ADTB
Automatic Delayed-Transition Transfer
& Bypass-Isolation Switches
J design 150 through 600 amp.
Refer to the outline and wiring drawings provided
with your 7000 Series ADTB for all installation and
connection details and accessories.
Refer to Group 5 Controller User's Guide 381333-126
for ATS status display messages, time delays, pickup
& dropout settings, and adjustments.
An experienced licensed electrician must install the
7ADTB.
Each 7000 Series 7ADTB contains a rating label to
define the load and fault circuit withstand/closing
ratings. Refer to the label on the Transfer Switch for
specific values.
Do not exceed the values on the rating label.
Exceeding the rating can cause personal injury
Power Connections
Engine Starting & Auxiliary Circuits
Rating Label
or serious equipment damage.
TABLE OF CONTENTS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
www.asco.ca
section-page
1-1
1-1
. . . . . .
1-2
1-2, 1-3, 1-4
2-1
2-1
2-1
2-2
2-2
3-1, 3-2
3-3, 3-4
3-5, 3-6, 3-7
back cover
381333-309
