SERIES 230 C2ADTL Transfer Switch
User Manual
Version
Revision Date
BOM Code
ASCO Power Technologies provides customers with technical support. Users may contact the nearest
ASCO Power Technologies sales office or service center.
Copyright © 2018 by ASCO Power Technologies
All rights reserved. The contents in this document are subject to change without notice.
ASCO Power Technologies
Address: 160 Park Avenue, Florham Park, NJ 07932-1049, USA
Website: www.ascopower.com
Customer Service Hotline: 800 800 ASCO
E-mail: customercare@asco.com
V1.3
th
Jan 12
, 2018
31012691
Advertisement
Table of Contents
Troubleshooting
Related Manuals for ASCO POWER TECHNOLOGIES C2ADTL
Summary of Contents for ASCO POWER TECHNOLOGIES C2ADTL
-
Page 1: User Manual
, 2018 BOM Code 31012691 ASCO Power Technologies provides customers with technical support. Users may contact the nearest ASCO Power Technologies sales office or service center. Copyright © 2018 by ASCO Power Technologies All rights reserved. The contents in this document are subject to change without notice. -
Page 3: Table Of Contents
Contents Chapter 1 Overview ................................1 1.1 Model Description and Order Information ......................1 1.1.1 Model Description ............................1 1.1.2 Configuration Description and Number of Poles ..................2 1.1.3 Accessory Model Description and Order Information ................2 1.2 Appearance ................................3 1.3 Product Composition ............................. -
Page 5: Chapter 1 Overview
Chapter 1 Overview Chapter 1 Overview ASCO Series 230 C2ADTL transfer switch is a professional PC class dual power transfer switch. It adopts a reliable mechanism and an electric design built on a modular concept, and is suitable for various electric continuity applications. -
Page 6: Configuration Description And Number Of Poles
132D-132F: The auxiliary contacts can be used to indicate positions with the OPEN contact , see Schematic 2. Position of Auxiliary Contact Function Code Position of Auxiliary Contact Function Code The transfer The transfer switch switch Schematic 1 132A-132C Diagram Schematic 2 132D-132F Diagram ASCO Series 230 C2ADTL Transfer Switch User Manual... -
Page 7: Appearance
Figure 1-1 Appearance 1.3 Product Composition Series 230 automatic transfer switch includes one transfer switch and one controller. The C2ADTL Size has multiple ampere rating options. Series 230 transfer switch unit can work with either the C1000 or C2000 controller. -
Page 8: Panel Description
Temperature: -5° C to +40° C Humidity: Within 95%, No condensation Pollution Class: Class III Mounting Method: Horizontal or Vertical Product Standards Met: EN60947-6-1 and IEC60947-6-1 Environmental Standards Met: RoHS and WEEE ASCO Series 230 C2ADTL Transfer Switch User Manual... -
Page 9: Technical Parameters
Rated Impulse Withstand Voltage Uimp (kV) Rated Short-time Making Capacity Icm (peak) (kA) 31.5 Rated Short-circuit Withstand Current Icw (kA/0.1s) 200（FUSE）/150（MCCB） Rated Conditional Short-circuit Current Iq (rms) (kA) ＜2.5 Operating Transfer Time (s) ASCO Series 230 C2ADTL Transfer Switch User Manual... -
Page 10: Chapter 2 Installation And Operation
Each automatic transfer switch contains a rating label (Name plate) to define the loads (Ampere rating). Refer to the label on the transfer switch for specific values. Do not exceed the values on the rating label. Exceeding the rating can cause personal injury or serious equipment damage. ASCO Series 230 C2ADTL Transfer Switch User Manual... -
Page 11: Installation
See Appendix 1 (Surge Protection Device) for additional details and recommended wiring methods. 3. Isolation function The C2ADTL transfer switch is not suitable for isolation, and a switch-disconnector must be installed when isolation function is needed. 2.1.1 Installation of Transfer Switch Install the transfer switch to the cabinet according to the mounting dimensions shown in Figure 2-1. -
Page 12: Accessory Installation
2. Pole Partition The pole partition is used to isolate and insulate the poles and ensure electric safety. The installation procedures are as follows: The pole partition as shown in Figure 2-3. ASCO Series 230 C2ADTL Transfer Switch User Manual... - Page 13 Chapter 2 Installation And Operation Figure 2-3 Pole Partition ASCO Series 230 C2ADTL Transfer Switch User Manual...
- Page 14 (A/B/C/N) are in their correct positions as well with A Phase being closest to the main gear driver box area. 3. Auxiliary Contacts (Optional Accessory) There are many different optional auxiliary contact configurations available for the C2ADTL TS unit, See the Figure 2-5 below for what options exists. 132A...
- Page 15 1. With the auxiliary contact screw holes facing outward, snap the 4 claws into the corresponding 4 holes on the transfer switch side plate, and then force it into position, as shown in Figure 2-7. ASCO Series 230 C2ADTL Transfer Switch User Manual...
- Page 16 Figure 2-9 Cable Clamp 4. After wiring the auxiliary contacts, affix the corresponding cable with the closest cable clamp using a cable tie to facilitate and optimize the wiring layout as shown in Figure 2-10. ASCO Series 230 C2ADTL Transfer Switch User Manual...
- Page 17 2.5mm b) Additional Information: AC-15 DC-12 DC-13 P / W P / W 0.55 0.55 0.27 , the auxiliary contact circuit should meet the requirments: Current≥5mA In order to obtain higher reliability ASCO Series 230 C2ADTL Transfer Switch User Manual...
-
Page 18: Operation
If you need to switch it to Position I (Normal Source), rotate the handle 180 degrees counter-clockwise. After hearing a 'click', and the window displays ‘I’, it indicates that the position has successfully switched to Position I. The detailed handle rotation positions are shown in Figure 2-12. ASCO Series 230 C2ADTL Transfer Switch User Manual... -
Page 19: Auto Operation
Position Off. To do this, do the following in this order: 1. Ensure that the auto/manual toggle switch is in ‘MANUAL’ position. ！ CAUTION If the auto/manual toggle switch is not in MANUAL position, the padlock pull-tab cannot be pulled up. ASCO Series 230 C2ADTL Transfer Switch User Manual... - Page 20 3. Finally, pull the padlock pull-tab out and lift up to expose the lock hole. Then insert the proper padlock into the hole to lock it. The specified diameter of the C2ADTL transfer switch padlock must be φ5mm to φ6mm. ASCO Series 230 C2ADTL Transfer Switch User Manual...
-
Page 21: Chapter 3 Maintenance And Troubleshooting
Manual Control to “Manual Control” ,and press the Control Mode is setted,the Control Mode “Enter” button.and then setting is Down contorller will be reset to complete ok,system will be reset. the set. Enter ASCO Series 230 C2ADTL Transfer Switch User Manual... - Page 22 (5) According to The 230 Series Automatic Transfer Switch C1000 Intelligent Controller User Manual, the DIP 7-8 is set to automatic or remote Mode, and the controller will exit manual control mode. ASCO Series 230 C2ADTL Transfer Switch User Manual...
-
Page 23: Maintenance
1. Only a professional electrician should operate to check and replace the the fuse. Such a person MUST be equiped with insulated rubber boots, insulated gloves, and insulated tools. 2. Before removing the damaged fuse, the operator MUST switch the manual/auto toggle switch to the 'MANUAL' Position. ASCO Series 230 C2ADTL Transfer Switch User Manual... -
Page 24: Appendix 1 Surge Protection Device
MCB or Fuse Grouding Cable Surge Protection Lenth Controller ≤ Device Wiring from Main Circuit to Grand lenth ≤0.5m Cable Line ≤ Class C Surge Protection Device Appended Figure 3: Wrong Connection Method ASCO Series 230 C2ADTL Transfer Switch User Manual... -
Page 25: Appendix 2 Glossary
Appendix 1 Appendix 2 Glossary Automatic Transfer Switch Normally Closed Normally Open ASCO Series 230 C2ADTL Transfer Switch User Manual...
