- Page 1 EDR-260 WARNING READ INSTRUCTIONS CAREFULLY AND FOLLOW RULES FOR SAFE OPERATION. FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY. ECHO, INCORPORATED 400 Oakwood Road, Lake Zurich, Illinois 60047-1564 Phone : 847-540-8400 X750-005 05 7 X750409-3607 Printed in Japan 1201/02Asb 1374 ES...
-
Page 2: Table Of Contents
WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints, •... -
Page 3: Introduction
INTRODUCTION ECHO Engine Drill EDR-260 is a lightweight, high WARNING performance, two-stroke engined unit designed for IMPROPER USE OR CARE OF THIS UNIT, OR drilling. FAILURE TO WEAR PROPER PROTECTION This Manual provides the information necessary CAN RESULT IN SERIOUS INJURY. -
Page 4: Safety
• Wear hearing protection. starting the engine. ECHO recommends that hearing protection be worn at all times. • Operate this gasoline powered engine equipment in a well-ventilated area only. - Page 5 • Wear non-slip, heavy-duty work gloves to WARNING improve your grip on the engine drill handles. The gloves also help reduce the transmission PRECAUTION AGAINST VIBRATION of machine vibrations to your hands. AND COLD IT IS BELIEVED THAT A CONDITION PROTECTING OTHERS CALLED RAYNAUD’S PHENOMENON, Spectators, children, fellow workers and animals...
- Page 6 Repetitive Stress Injuries It is believed that over-using the muscles and tendons of the fingers, hands, arms and shoulders may cause soreness, swelling, numbness, weakness and extreme pain in those areas. Certain repetitive hand activities may put you at a high risk for developing a Repetitive Stress Injury (RSI).
-
Page 7: Operating Techniques
OPERATING TECHNIQUES • When starting to drill, run the engine at full • Do not attempt to repair the machine unless throttle. you are qualified to do so. WARNING • Do not operate the machine with a damaged or excessively worn drill bit. BEFORE DRILLING, BE SURE TO READ AND UNDERSTAND THE ENTIRE OPERATOR’S •... -
Page 8: Description
Part Number X505-002310 Part Number X505-002570 * If a decal cannot be read, a new one can be ordered from your ECHO dealer. 1. Operator’s manual - Included with unit. Read 9. Fuel tank - Contains fuel and fuel filter. -
Page 9: Assembling
ASSEMBLING FRONT HANDLE • Insert the front handle to the machine, and turn clockwise. (TIGHTEN THE SCREW FIRMLY) - To operate front handle with right hand, remove right plug then reverse sides when installing handle and plug. Washer Front handle DRILL BIT •... - Page 10 Engine problems due to inadequate lubrication caused by failure to use an ISO-L-EGD METRIC (ISO/CD 13738) and J.A.S.O. FC/FD certified oil, Gasoline Gasoline such as ECHO premium Power Blend X™, will void Gallons US. fl. oz. the two-stroke engine warranty. IMPORTANT 12.8 •...
- Page 11 HANDLING FUEL MIXING INSTRUCTIONS - DANGER 1. Fill an approved fuel container with half of the required amount of gasoline. FUEL IS VERY FLAMMABLE. USE EXTREME CARE WHEN MIXING, STORING OR 2. Add the proper amount of two-stroke oil to HANDLING OR SERIOUS PERSONAL gasoline.
-
Page 12: Starting Cold Engine
STARTING COLD ENGINE WARNING WHEN ENGINE IS STARTED, CONFIRM IF THERE IS NOT ANY ABNORMAL VIBRATION OR SOUND. IF THERE IS ABNORMAL VIBRATION OR SOUND, ASK YOUR DEALER TO REPAIR. • Stand the engine upright on a level surface. • Place ignition switch in ON (START/RUN) position. -
Page 13: Maintenance And Care
REVERSE ROTATION • This model is equipped with reverse rotation mechanism. Counter clockwise • When drilling, set shift lever down to clockwise (CCW) (CW) rotation position. • If bit is locked due to deep penetration during drilling operation, set shift lever up to counterclockwise (CCW) rotation position and operate reversed for easy pulling-out. -
Page 14: Emission Data
SKILL LEVELS Level 1 = Easy to do. Common tools may be required. Level 2 = Moderate difficulty. Some specialized tools may be required. REQ'D 3 MONTHS MAINTENANCE DAILY OR EVERY YEARLY COMPONENT / SYSTEM SKILL OR 90 PROCEDURE BEFORE USE REFUEL 600 HOURS LEVEL... -
Page 15: Trouble Shooting
WARNING • ALL ENGINE DRILL SERVICE OPERATIONS, OTHER THAN ITEMS LISTED IN THE OPERATOR’S MANUAL, SHOULD BE PERFORMED BY AN AUTHORIZED ECHO DEALER. • FUEL VAPORS ARE EXTREMELY FLAMMABLE AND MAY CAUSE FIRE AND/OR EXPLOSION. NEVER TEST FOR IGNITION SPARK BY GROUNDING SPARK PLUG NEAR... -
Page 16: Maintenance
MAINTENANCE AIR FILTER • Clean before use. - Remove air cleaner cover and pull out air filter. - Lightly brush off dust or wash it in water and detergent. - Dry completely before putting it back in place. Air filter Air cleaner cover FUEL FILTER •... -
Page 17: Adjusting Carburetor
1100 feet ASL the NOTE carburetor may need to be adjusted by an When there is some trouble with the carburetor, authorized ECHO service dealer. contact your dealer. IMPORTANT If the engine is adjusted for operation above... - Page 18 CLEANING CYLINDER FINS Cylinder fins (Check Periodically) NOTE Clogged fins will cause poor engine cooling. 1. Carefully remove housing and clean dirt and dust from fins. 2. Reinstall housing. CLEANING SILENCER AND EXHAUST PORT (Check Periodically) 1. Carefully remove housing halves. 2.
-
Page 19: Storage
6. Tighten muffler mounting bolts (or nuts) to 80- 95 in•lbf (90-110 kgf•cm). 7. Start engine, and warm to operating temperature. 8. Stop engine, and re-tighten mounting bolts (or nuts) to specifications. 9. Install engine cover and attach spark plug lead. STORAGE LONG TERM STORAGE 6. -
Page 20: Specifications
Fuel mixture ratio 50:1 ratio with ECHO Power Blend X™ , ISO-L-EGD (ISO/CD 13738) and JASO M345-FC/FD two-stroke, air-cooled engine oil. gasoline Use 89 octane unleaded. Do not use fuel containing methyl alcohol, more than 10% ethyl alcohol or 15% MTBE. -
Page 21: Warranty Statements
ECHO'S RESPONSIBILITY ECHO Incorporated’s Limited Warranty, provides to the original purchaser that this ECHO product is free from defects in material and workmanship. Under normal use and maintenance from date of purchase, ECHO agrees to repair or replace at ECHO’s discretion, any defective product free of charge at any authorized ECHO servicing dealer within listed below application time periods, limitations and exclusions. - Page 22 . Gasohol which contains a is also approved. The prescribed mixing ratio of gasoline to oil is listed on the ECHO oil label and covered in your operator’s manual. engine speeds as listed in your operator’s manual. of unauthorized attachments.
