Echo QV-670 Parts Catalog

Quik vent saw
Hide thumbs Also See for QV-670:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
OPTIONAL ATTACHMENTS & ACCESSORIES
Attachments
99944700190
CSG_QV Storage Case
99988800045
QuikVent Carbide Sawing Chain
99988800141
QuikVent Guide Bar
99988801140
QuikVent Blade Cover
2008 ECHO Incorporated, RePower is Registered Trademark of ECHO Incorporated. All Rights Reserved
PARTS CATALOG
QV-670 Quik Vent Saw
MODEL:SERIAL NUMBERS
QV-670:
S/N: 03001001 - 03999999
ECHO, INCORPORATED
400 Oakwood Road Lake Zurich, Illinois 60047 USA
WWW.ECHO-USA.COM
66.7cc
99922203483 _03
REVISED 10/02/08

Advertisement

Table of Contents
loading

Related Manuals for Echo QV-670

Summary of Contents for Echo QV-670

  • Page 1 99988801140 QuikVent Blade Cover 66.7cc MODEL:SERIAL NUMBERS QV-670: S/N: 03001001 - 03999999 ECHO, INCORPORATED 400 Oakwood Road Lake Zurich, Illinois 60047 USA WWW.ECHO-USA.COM 99922203483 _03 REVISED 10/02/08 2008 ECHO Incorporated, RePower is Registered Trademark of ECHO Incorporated. All Rights Reserved...

  • Page 2: Table Of Contents

    Table of Contents Part Number Index Table of Contents Click Any Diagram Description Below To View That Diagram. QV-670 S/N: 03001001 - 03999999 Intake, Exhaust................................4 Carburetor -- HD-203...............................6 Ignition, Starter................................8 Chain Brake Asssembly, Guide Bar, Chain.........................10 Clutch.....................................12 Auto-Oiler..................................14 Handles...................................16 Engine, Cylinder Cover..............................18 Part Number Index.................................20 Part Description Index..............................21 99922203483 _03...
  • Page 3 This Page Intentionally Left Blank - 3 -...
  • Page 4 Table of Contents Part Number Index QV-670 Quik Vent Saw Intake, Exhaust 99922203483 _03 - 4 - REVISED 10/02/08...
  • Page 5 Table of Contents Part Number Index QV-670 Quik Vent Saw Intake, Exhaust ITEM PART NUMBER DESCRIPTION REMARKS 90016205014 SCREW 5X14 14571132430 BRACKET, MUFFLER 14581331730 COVER, MUFFLER 90016205020 SCREW 5X20 14561032430 MUFFLER 14586232630 SCREEN, MUFFLER A313000280 GUIDE, EXHAUST 90016204010 SCREW 4X10 14551032431 GASKET, MUFFLER A232000070...
  • Page 6 Table of Contents Part Number Index QV-670 Quik Vent Saw Carburetor -- HD-203 99922203483 _03 - 6 - REVISED 10/02/08...
  • Page 7 Table of Contents Part Number Index QV-670 Quik Vent Saw Carburetor -- HD-203 ITEM PART NUMBER DESCRIPTION REMARKS A021000290 CARBURETOR -- HD-203 12313002960 SCREW, METERING DIAPHRAGM COVER 12314217330 COVER, METERING DIAPHRAGM ------------------ BODY, CARBURETOR -- NOT AVAILABLE SEPARATELY P003000010 CAP, MIXTURE LIMITER 12311802261 NEEDLE - LOW SPEED 12312032631...
  • Page 8 Table of Contents Part Number Index QV-670 Quik Vent Saw Ignition, Starter 99922203483 _03 - 8 - REVISED 10/02/08...

  • Page 9: Ignition, Starter

    17722107060 PLATE, STARTER 17722002834 SPRING, REWIND 17722102830 PLATE, STARTER 17722832630 GRIP, STARTER 17722707060 GUIDE, ROPE 90016205020 SCREW 5X20 89011817930 LABEL, ECHO 17723419830 SPRING, RETURN 17724707060 SPACER, RATCHET 17721832630 PAWL, STARTER 90060300005 WASHER 5 90016205014 SCREW 5X14 17723419832 SPRING, RETURN V353000191...

  • Page 10: Chain Brake Asssembly, Guide Bar, Chain

    Table of Contents Part Number Index QV-670 Quik Vent Saw Chain Brake Asssembly, Guide Bar, Chain 99922203483 _03 - 10 - REVISED 10/02/08...
  • Page 11 43320935430 STOPPER, BRAKE 43312238130 SPRING, BRAKE 43331038230 COVER, BRAKE 90050000003 NUT 3 90025204012 SCREW 4X12 43301912330 NUT, FLANGE 8 89011815130 LABEL, ECHO X524000680 LABEL V203000040 BOLT 5 C309000030 TENSIONER, CHAIN V651000010 GEAR, BEVEL V651000000 GEAR, BEVEL V355000030 COLLAR 8 C305000050...

  • Page 12: Clutch

    Table of Contents Part Number Index QV-670 Quik Vent Saw Clutch 99922203483 _03 - 12 - REVISED 10/02/08...
  • Page 13 Table of Contents Part Number Index QV-670 Quik Vent Saw Clutch ITEM PART NUMBER DESCRIPTION REMARKS 682100 SPROCKET, RIM 17510532430 DRUM, CLUTCH 17501232430 BEARING, NEEDLE A056000041 CLUTCH ASY INCLUDES ITEMS 5-9 A551000030 PLATE, CLUTCH A552000031 HUB, CLUTCH V451000260 SPRING, CLUTCH P021002890 CLUTCH SHOE SET 90010504006...

  • Page 14: Auto-Oiler

    Table of Contents Part Number Index QV-670 Quik Vent Saw Auto-Oiler 99922203483 _03 - 14 - REVISED 10/02/08...
  • Page 15 Table of Contents Part Number Index QV-670 Quik Vent Saw Auto-Oiler ITEM PART NUMBER DESCRIPTION REMARKS 90016204012 SCREW 4X12 43760537630 COVER, OIL PUMP V309000010 WASHER 12 43706319930 GEAR, WORM 43700237530 AUTO-OILER ASY 90072000003 O-RING 3 43721132430 PIPE, OIL 43721232430 CONNECTOR, PIPE 13201326630 CLIP 13211512330...

  • Page 16: Handles

    Table of Contents Part Number Index QV-670 Quik Vent Saw Handles 99922203483 _03 - 16 - REVISED 10/02/08...
  • Page 17 Table of Contents Part Number Index QV-670 Quik Vent Saw Handles ITEM PART NUMBER DESCRIPTION REMARKS C400000100 HANDLE, FRONT 35161638230 BRACKET, HANDLE 90023805020 SCREW 5X20 V649000010 RIVET 30510532630 STAND 90016205030 SCREW 5X30 90016205025 SCREW 5X25 V401000050 CUSHION 5 90016205014 SCREW 5X14 13201056030 PIPE, FUEL - 3X6X110mm REPOWER BULK OPTION: 90015...

  • Page 18: Engine, Cylinder Cover

    Table of Contents Part Number Index QV-670 Quik Vent Saw Engine, Cylinder Cover 99922203483 _03 - 18 - REVISED 10/02/08...
  • Page 19 Table of Contents Part Number Index QV-670 Quik Vent Saw Engine, Cylinder Cover ITEM PART NUMBER DESCRIPTION REMARKS A160000210 COVER, ENGINE 90016205020 SCREW 5X20 89019132632 LABEL, CAUTION V341000010 DEFLECTOR, HEAT A130000171 CYLINDER A202000010 BELLOWS, INTAKE 90016205014 SCREW 5X14 90016205025 SCREW 5X25 10101032431 GASKET, CYLINDER.
  • Page 20 Table of Contents Part Number Index Part Number Index Click The Page Number After Any Part Number To View The Diagram Containing That Part. Part Number Page Part Number Page Part Number Page Part Number Page ------------------ ..... 17811432630 .... 90023805014 ....

  • Page 21: Part Description Index

    COVER, OIL PUMP..15 LABEL..11 COVER, SEAL..11 LABEL - MODEL -- QV-670..5 COVER, VENT..17 LABEL, CAUTION..19 CRANKCASE KIT..19 REAR HANDLE ASY..17 LABEL, ECHO..9, 11 CRANKSHAFT ASY..19 REPAIR KIT..7 LABEL, SWITCH..5 CUSHION..5, 19 RETAINER, BRAKE BAND..9 LATCH, AIR CLEANER LID..5 CUSHION 5..17, 19 RETAINER, LINK..17...
  • Page 22 Table of Contents Part Number Index Part Description Index (continued) VALVE, CHOKE..7 VALVE, INLET NEEDLE..7 SCREEN..7 VALVE, THROTTLE..7 SCREEN, INLET..7 VENT ASY..17 SCREEN, MUFFLER..5 SCREW..7, 9, 11, 19 SCREW 3X18..11 SCREW 3X6..11 WASHER..7, 9 SCREW 3X8..17, 19 WASHER 12..15 SCREW 4X10..5, 11, 15 WASHER 5..9, 15 SCREW 4X12..11, 15 WASHER 6..17...
  • Page 23 NOTES 99922203483 _03 - 23 - REVISED 10/02/08...
  • Page 24 ECHO, INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 USA WWW.ECHO-USA.COM...
