Page 1 Lifds Good LCD TV OWNER'S MANUAL 32LG700H 37LG700H 42LG700H Installer Reference for Commercial Mode MPI/PPV Card Setup see page 19 Commercial Mode Setup see pages 85-107 Please read this manual carefully before operating your set. Retain it for future reference. Record model hum of the set.
Page 2: Warning / Caution
Do not attempt to modify this product in any way as practical. without written authorization from LG Electronics. Unauthorized modification could void user's authority to operate this product...
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFETYINSTRUCTIONS Read these instructions. Protect the power cord from being walked on or pinched particularly at plugs, convenience Keep these instructions. receptacles, and the point where they exit from Heed all warnings. the apparatus. Follow all instructions. Do not use this apparatus near water.
Page 4 WARNING - To reduce the risk of fire or electrical Never touch this apparatus or antenna during a thunder or lighting storm. shock, do not expose this product to rain, moisture or other liquids. Do not touch the TV with wet ®...
Page 5 ANTENNAS Ventilation Install your TV where there is proper ventilation. Do Outdoor antenna grounding not install in a confined space such as a bookcase. If an outdoor antenna is installed, follow the precau- Do not cover the product with cloth or other mate- tions below.
Page 6: Table Of Contents
CONTENTS WARNING / CAUTION ......1 - Auto Scan (Auto Tuning) ......38 - Add / Delete Channel (Manual Tuning) ..39 SAFETY INSTRUCTIONS ......2 - Channel Editing ........FEATURES OF THIS TV ......7 Channel Label ..........Input List ............PREPARATION Example Electronic Program Guide ....
Page 7 PARENTAL CONTROL /RATINGS Set Password & Lock System ......76 Channel Blocking ..........Movie & TV Rating ......... Downloadable Rating ........External Input Blocking ........Interactive TV Setup ........Installer Overview ..........Interactive TV Overview ........Commercial Mode Setup for Master TV .... 88 Master TV Profile Setup Learning/Teaching with USB Memory...
Page 8: Features Of This Tv
FEATURES OF THIS TV Manufactured under license from Dolby Laboratories. HDMP, the HDMI logo and High-Definition DOLBY "Dolbz "and the double-D symbol are trademarks of Hm_ll[11111 Multimedia Interface are trademarks or registered DIGITAL J Dolby Laboratories. trademarks of HDMI Licensing." SsrS_ is a trademark of SRS Labs, Inc.
Page 9: Accessories
PREPERATION ACCESSORIES Ensure that the following accessories are included with your TV. If an accessory is missing, please contact dealer where you purchased the TV. The accessories included may differ from the images below. Protective Bracket and Power Cord CD Manual Bolt for Power Cord Owner's Manual...
Page 10: Frontpanelinformation
FRONTPANELINFORMATION _ Image shown may differ from your TV. "O _iiU ¸¸¸ CHANNEL(^ ,v ) CH :, -- Buttons !;ii i[il iiiii VOLUME (+,-) Intelligent Sensor Buttons Adjusts picture according to the surrounding conditions. Stand E.TER®IIIii ENTER Button uE.uiiii MENU Button Power/Standby Indicator Illuminates...
Page 11: Back Panelinformation
PREPARATION BACK PANELINFORMATION _ Image shown may differ from your TV. r.l-I iiiiiiiiiiiiiiiiiiiiiiiiiiiiiil :_;!;!;!;!;!;!;!;!!! _ii!;;;;;;;i i_i iiF iii i i i iiJi ¸iili i]iiii! iiiiiiiiiiiiiiiiiii!!!i]iiiiiii!!i!iiiili i!iiiiiiiiiiiiiiiii! iiiii ¸ iiiiiiiiiiiiiii ; lii]}iiiiiiiiiii:itii_i_i_i!_i!_i!_i!_i!_i!_i!_i!_i!_i!_i!/i!_i!_i!_ iiiii ¸ : _ ii_i_ii!!iiiiilililii/iiiilil...
Page 12 HDMI/DVI REMOTE CONTROL OUT Digital Connection. Supports HD video and Digital IR output for controlling an auxiliary device. audio. Accepts DVI video using an adapter or HDMI to RJPINTERFACE (REMOTE JACK PACK PORT) DVI cable (not included) Connect to remote jack pack control output port. LAN (SERVICE ONLY) COMPONENT ©...
Page 13: Stand Instruction
?RZRARATION STAND INSTRUCTION _ Image shown may differ from your TV. INSTALLATION DETACHMENT Carefully place the TV screen side down on a Carefully place the TV screen side down on a cushioned surface to protect the screen from cushioned surface to protect the screen from damage.
Page 14: Cablemanagement
CABLEMANAGEMENT _ Image shown may differ from your TV. Connect the cables as necessary. ut the cables inside the CABLE MANAGEMENT CLIP and snap it closed. To connect additional equipment, see the EXTERNAL EQUIPMENT SETUP section. Secure the power cable with the PROTECTIVE ©...
Page 15: Desktop Pedestalinstallation
?RERARAI°ION DESKTOP PEDESTALINSTALLATION _ Image shown may differ from your TV. For proper ventilation, allow a clearance of 4 inches on all four sides. 4 inches 4 inches 4 inches 4 inches © _, Do not mount near or above any type of heat source. SWIVELSTAND The TV can be conveniently swivelled on its stand 90 °...
Page 16: Attaching The Tv To A Desk
ATTACHING THE TV TO A DESK The TV must be attached to a desk so it cannot be pulled in a forward/backward direction, potentially causing injury or damaging the product. Stand .._-J '%._ Desk 4-Screws (not provided as parts of the product) _o screw: MSXL ( *L_ Tabie depth _ 8C lo mm) ex) Table dePth: !5 ram, Screw: M5 X 25...
Page 17: Vesawall Mounting
TV or allow the TV to a fall and cause per- assembly are provided, sonal injury. LG is not liable for these kinds of acci- Do not use screws longer then the standard dimen- dents. sion. as they may cause damage to the inside to LG is not liable for TV damage or personal injury the TV.
Page 18: Securing The Tv To The Wall To Preventfalling When The Tv Is Used On A Stand
SECURING THE TV TO THE WALL TO PREVENTFALLING WHEN THE TV IS USED ON A STAND _ You should purchase necessary components to prevent the TV from tipping over (when not using a wall mount). _ Image shown may differ from your TV. * This feature is not available for all models.
Page 19: Antenna Or Cable Connection
?RERARATION _ To prevent damage do not connect to the power outlet until all connections are made between the devices. ANTENNA OR CABLE CONNECTION 1. Antenna (Analog or Digital) l-rl Wall Antenna Socket or Outdoor Antenna without a Cable Box Connection.
Page 20: Mpi Card Slot / Ppvcard Installation
MPI CARD SLOT / PPVCARD INSTALLATION The MPI card is equipped with an RF jack for antenna/cable signal source connection. The MPI card slot is also available for installing a PPV (Pay-Per-View) card. MPI Card Removal/PPV Card Installation 1. Remove the two MPI card retainer screws. 2.
Page 21: Hd Receiversetup
EXTERNAL EQUIPMENT SETUP To prevent the equipment damage, never plug in any power cords until you have finished connecting all equipment. Image shown may differ from your TV. HD RECEIVERSETUP This TV can receive Digital Over-the-air or Digital Cable signals without an external digital set-top box.
Page 22: Hdmi Connection
HDMI Connection 1. How to connect onnect the digital set-top box to HDMI/DVI (DVI) or 2 jack on the TV. No separate audio connection is necessary. HDMI supports both audio and video. 2. How to use Turn on the digital set-top box.
Page 23: Dvi To Hdmi Connection
EXTERNALEQUIPMENT SETUP DVI to HDMI Connection 1. How to connect onnect the DVI output of the digital set-top box to theHDMI/DVl IN 1 (DVl) jack on the TV. Connect the audio output of the digital set-top box to the AUDIO (RGB/DVI) jack on the TV.
Page 24: Dvd Setup
DVD SETUP Component Connection 1. How to connect Connect the video outputs (Y, PB, PR) of the DVD to the COMPONENT IN VIDEO jacks on the TV. Match the jack colors (Y = green, PB = blue, and PR = red). Connect the audio outputs of the DVD to the COMPONENT IN AUDIO...
Page 25: Hdmi Connection
EXTERNALEQUIPMENT SETUP HDMI Connection 1. How to connect Connect the HDMI output of the DVD to the HDMI/DVI IN 1 (DVI) jack on theTV. separate necessary. audio connection HDMI supports both audio and video. "0 2. How to use Select the HDMI1 or HDMI2 input source on the TV using the INPUT...
Page 26: Vcr Setup
VCR SETUP _ To avoid picture noise (interference), leave an adequate distance between the VCR and TV. Antenna Connection 1. How to connect Connect the RF antenna out socket of the VCR to the ANTENNA IN socket on the Connect antenna cable antenna in socket of the VCR.
Page 27: Othera/V Sourcesetup
EXTERNALEQUIPMENT SETUP OTHERA/V SOURCESETUP 1. How to connect Camcorder Video Game Set Connect AUDIO/VIDEO jacks between TV and external equipment. Match the jack colors. (Video = yellow, Audio Left = white, and I'1"1 >< Audio Right = red) ,,-I I"1"1 2.
Page 28: Pc Setup
PC SETUP This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings. VGA (D-Sub 15 pin) Connection 1. How to connect onnect the VGA output ofthe PC to the RGB (PC) jack on the TV. Connectthe PCaudio output to the AUDIO (RGB/DVI) jack on the TV.
Page 29: Dvi To Hdmi Connection
EXTERNALEQUIPMENT SETUP DVI to HDMI Connection 1. How to connect onnect the DVI output of the PC to the HDMI/DVI 1 (DVI) jack on the TV. Connect the PC audio output to the AUDIO (RGB/DVI) jack on the -IV. "O 2.
Page 30: Screen Setup For Pc Mode
Screen Setup for PC mode Selecting Resolution You can choose the resolution in RGB-PC mode. The Position, Phase, and Size can also be adjusted. Screen _-_ Move .._eso_u_: _'_ _ 1024 x 768 "0 "0 Select PICTURE. Select Screen (RGB-PC).
Page 31 EXTERNALEQUIPMENT SETUP Auto Configure Automatically adjusts picture position and minimizes image instability. After adjustment, if the image is still not correct, try using the manual settings or a different resolution or refresh rate on the PC. r'r3 Screen Move Prey. _>...
Page 32 Adjustment for screen Position, Size, and Phase If the picture is not clear after auto adjustment and especially if characters are still trembling, adjust the picture phase manually. This feature operates only in RGB-PC mode. r'r3 r-r3 _> Screen Move P..
Page 33 EXTERNALEQUIPMENT SETUP Screen Reset (Reset to original factory values) Returns Position, Size, and Phase to the default factory settings. This feature operates only in RGB-PC mode. _Prev. Reset Select PICTURE. Select Screen (RGB-PC). Select Reset. Select Yes.
Page 34: Audio Out Connection
AUDIO OUT CONNECTION Send the TV's audio to external audio equipment via the Audio Output port. Digital 1. How to connect Connect end of the optical coaxial cable TV's OPTICAL port of DIGITAL AUDIO OUT. !iili i!i!i optical Connect the other end of the coaxial cable to the digital audio input on the audio equipment.
Page 35: Watching Tv/Channel Control
WATCHING TV / CHANNEL CONTROL REMOTE CONTROL FUNCTIONS When using the remote control, aim it at the remote control sensor on the TV. POWER Turns your TV or any other programmed equipment or off, depending on mode. TV/STB/DVDA/CR Select the remote's operating mode: TV, STB, DVD, or VCR.
Page 36 THUMBSTICK Navigate the on-screen menus and adjust the system settings to your preference. (Up/Down/Left Right/ENTER) RETURN Clears all on-screen displays and returns to TV viewing from any menu. MENU Displays the main menu. INPUT External input modes rotate in regular sequence: TV, AV1-2, Component,...
Page 37: Turning On Tv
WATCHING / CHANNELCONTROL TURNING ON TV First, connect power cord correctly. At this moment, the TV switches to standby mode. _ In standby mode to turn TV on, press the (5/I button on the TV or press the POWER button on the remote control. source viewing using...
Page 38: On-Screenmenusselection
ON-SCREENMENUSSELECTION Your TV's OSD (On Screen Display) may differ slightly from that shown in this manual. -r" < -r" > Display each menu. Select a menu item. Enter to the pop up menu. Return to TV viewing.
Page 39: Channelsetup
WATCHING TV / CHANNEL CONTROL CHANNELSETUP Auto Scan (Auto Tuning) Automatically finds all channels available through antenna or cable inputs, and stores them in memory on the channel list. Run Auto Tuning again after any Antenna/Cable connection changes. -r" < -r"...
Page 40: Add/Delete Channel (Manual Tuning)
Add/Delete Channel (Manual Tuning) If selecting DTV or CADTV input signal, you can view the on-screen signal strength monitor to see the quality of the signal being received. -r" < -r" > Select CHANNEL. Select Manual Tuning. A password is required to gain access to Select DIGITAL or ANALOG.
Page 41: Channel Editing
WATCHING TV / CHANNEL CONTROL Channel Editing The channels in the Custom List are displayed in black and the channels deleted from the Custom List are dis- played in gray. Once a channel is highlighted you can add or delete the channel by referring to the small window at the top-...
Page 42: Channel Label
CHANNEL LABEL Choose preset labels for your channels. If a channel label is provided on the signal from the broadcasting station, the TV displays a short name for a channel even if you didn't preset a label for the channel. -r"...
Page 43: Input List
WATCHING l°V / CHANNEL CONTROL INPUT LIST Select the desired input source. < l..I HoM,1 1_- I R_B-PC l_'IComponent > HDMI2 © © _ TV: Select it to watch over-the-air, cable and digital cable broadcasts. _ AVl -2: Select them to watch a VCR or other external equipment.
Page 44: Exampleelectronic Program Guide
EXAMPLEELECTRONIC PROGRAM GUIDE This is an example of a typical TV electronic program guide showing available programming. --CHANNEL INDICATOR PROGRAMMING GRID Currently tuned channel Program listings arranged in and program. time slots. TV PROGRAM Current program on select- DATE/TIME ed channel. Shows current Date/Time.
Page 45: Pip (Picture-Ln-Picture)
PICTURE CONTROL PIP (PICTURE-IN-PICTURE) PIP enables the end user to view two sources on the screen at the same time. The end user can switch between the Main and Sub picture sizes. PIP Operation 1. Connect auxiliary source(s) to TV connections panel.
Page 46 PIP Operation ¢h Use the PIP function keys to operate the available PIP features. Press PIP on remote to place PIP screen inset on the TV screen. See above. ¢h © 1. With PIP active_ press Swap to switch the PIP inset with the TV picture. See above.
Page 47: Picture Size (Aspect Ratio) Control
PICTURECONTROL PICTURE SIZE (ASPECT RATIO) CONTROL This feature lets you choose the way an analog picture with a 4:5 aspect ratio is displayed on your 0i_ R GB-PC input source use 4:5 or 16:9 aspect ratio. "0 Press the RATIO button repeatedly to select the...
Page 48 16:9 Set by program Selects the proper picture proportion to match Adjust the picture horizontally, in a linear pro- the source'simage. portion to fill the entire screen. (4:3"-_ 4:3) (16:9"* 16:9) © © Choose 4:3 when you want to view a picture with an original 4:3 aspect ratio.
Page 49 PICTURECONTROL Zoom just Scan Choose Zoom 1 when you want to view the pic- Normally the edges of video signals are cropped ture without any alteration. However, the top and 1-2%. Just Scan turns off this cropping bottom portions of the picture will be cropped. shows the complete video.
Page 50: Presetpicture Settings
PRESETPICTURE SETTINGS Picture Mode - Preset There are factory presets for picture settings available in the user menus. You can use a preset, change each setting manually. Select PICTURE. 0_When selecting Intelligent Sensor, the most suitable picture is automatically adjusted according to the surrounding Select Picture Mode.
Page 51: Color Tone - Preset
PICTURECONTROL Color Tone - Preset Choose one of three automatic color adjustments. Set to warm to enhance hotter colors such as red, or set to cool to see less intense colors with more blue. "0 Select PICTURE. Select Advanced Control. Select Color Temperature.
Page 52: Manual Pictureadjustment
MANUAL PICTUREADJUSTMENT Picture Mode - User Mode Adjust the picture appearance to suit your preference and viewing situations. This feature is disable in "Picture Mode-Intelligent Sensor". "0 Select PICTURE. Select Picture Mode. Select Vivid, Standard, Cinema, Sport or Game. Select Back Light, Contrast, Brightness, Sharpness,...
Page 53: Picture Improvement Technology
PICTURECONTROL PICTURE IMPROVEMENT TECHNOLOGY Fresh Contrast: Optimizes the contrast automatically according to the brightness of the reflection. Fresh Color: Adjusts the color of the reflection automatically to reproduce as close as possible natural colors. Noise Reduction: Removes interference up to the point where it does not damage the original picture.
Page 54: Advanced Control-Black (Darkness) Level
ADVANCED CONTROL- BLACK (DARKNESS) LEVEL Adjusting the contrast and the brightness of the screen using the black level of the screen. This feature is disable in DTV and RGB-PC mode. "O © © Select PICTURE. 01_ L ow: The reflection of the screen gets darker.
Page 55: Advancedcontrol- Eyecare
PICTURECONTROL ADVANCEDCONTROL- EYECARE Dims extremely bright pictures. This feature is disabled in "Picture Mode-Vivid, Cinema". © © Select PICTURE. Select Advanced Control. Select Eye Care. Select On or Off. Return to the previous menu. Return to TV viewing.
Page 56: Advanced Control-Film Mode
ADVANCED CONTROL- FILM MODE Set up the TV for the best picture appearance for viewing movies. When you operate Film Mode (3:2 Pull-Down Mode or Cinema Correction Mode), the TV will adjust 24 fps video from movies to 30 fps video for display. This feature operates only in TV (Analog TV, Digital...
Page 57: Picture Reset
PICTURECONTROL PICTURE RESET Settings of the selected picture modes return to the default factory settings. "O Select PICTURE. Select Reset. Initialize the adjusted value. Return to TV viewing.
Page 58: Sound & Language Control
SOUND & LANGUAGE CONTROL AUTO VOLUME LEVELER(AUTO VOLUME) Auto Volume makes sure that the volume level remains consistent whether you are watching a commercial or a regular TV program. Select AUDIO. Select Auto Volume. 1-11 Select 0 n or Off. Return to the previous menu.
Page 59: Presetsound Settings (Sound Mode)
SOUND &LANGUAGE CONTROL PRESETSOUND SETTINGS (SOUND MODE) Sound Mode lets you enjoy the best sound without any special adjustment as the TV sets the appropriate sound options based on the program content. Standard, Music, Cinema, Sport, and Game are preset for optimum sound quality at the factory and are...
Page 60: Sound Setting Adjustment- User Mode
SOUND SETTING ADJUSTMENT- USER MODE Adjust the sound to suit your taste and room situations. Select AUDIO. Select Sound Mode. l'rl Select Standard, Music, Cinema, Sport, or Game. Select Treble or Bass. Make appropriate adjustments. Return to the previous menu. Return to TV viewing.
Page 61: Srstrusurround Xt
SOUND &LANGUAGE CONTROL SRS TRUSURROUND XT Takes advantage of any multi-channel format without needing to add extra speakers or equipment. Dialog clarity, bass enrichment, and the addition of stereo audio enhancement produces an immersive sound experi- ence from standard stereo material.
Page 62: Clear Voice
CLEAR VOICE By differentiating the human sound range from others, it improves the sound quality of voices. Select AUDIO. Select Clear Voice. l'rl f_ If you select "Clear Voice-On", TruSurround XT feature will not work. Select 0 n or Off. Return to the previous menu.
Page 63: Balance
SOUND &LANGUAGE CONTROL BALANCE Adjust the left/right sound of speaker to suit your taste and room situations. Select AUDIO. Select Balance. l'rl Make appropriate adjustments. Return to the previous menu. Return to TV viewing.
Page 64: Tv Speakers On/Off Setup
TV SPEAKERSONIOFF SETUP Turn the TV speakers off if using external audio equipment. Select AUDIO. Select TV Speaker. l'rl Select 0 n or Off. Return to the previous menu. Return to TV viewing.
Page 65: Audio Reset
SOUND &LANGUAGE CONTROL AUDIO RESET Settings of the selected Sound Mode return to the default factory settings. Select AUDIO. Select Reset. l'rl Initialize the adjusted value. Return to TV viewing.
Page 66: Stereo/Sap Broadcastsetup
STEREO/SAP BROADCASTSETUP For Analog only: This TV can receive MTS stereo programs and any SAP (Secondary Audio Program) that accom- panies the stereo program if the station transmits an additional sound signal. Mono sound is automatically used if the broadcast is only in Mono.
Page 67: Audio Language
SOUND &LANGUAGE CONTROL AUDIO LANGUAGE Other languages may be available if a digital signal is provided by the broadcasting station. This feature operates only in DTV mode. Select OPTION. Select Language. l'rl Select Audio. Select your desired language: English, Spanish, or French Return to the previous menu.
Page 68: On-Screen Menus Language Selection
ON-SCREEN MENUS LANGUAGE SELECTION The menus can be shown on the screen in the selected language. Select OPTION. Select Language. l'rl Select Menu. Select your desired language. From this point on, the on-screen menus will be shown in the selected language. Return to the previous menu.
Page 69: Caption Mode
SOUND &LANGUAGE CONTROL CAPTION MODE Caption must be provided to help people with hearing loss watch TV. This feature operates only in TV, AV1-2 mode. Select Caption On or Off. 01_ W hen selecting Off, Sub-menus Analog, DTV, Digital Option become disabled.
Page 70: Digital Broadcasting System Captions
Digital Broadcasting System Captions Choose the language you want the DTV Captions to appear in. Other Languages can be chosen for digital sources only if they are included on the program. This function in only available when Caption Mode is set On. Select OPTION.
Page 71: Caption Option
SOUND &LANGUAGE CONTROL Caption Option Customize the DTV captions that appear on your screen. This function in only available when Caption Mode is set On. _!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! Select OPTION. 01_ Size: Set the word size. Select Caption. l'rl 01_ F ont: Select a typeface for the text.
Page 72: Time Setting
TIME SETTING CLOCK SETTING Auto Clock Setup The time is set automatically from a digital channel signal. The digital channel signal includes information for the current time provided by the broadcasting station. Set the clock manually if the current time is set incorrectly by the auto clock function.
Page 73: Manual Clock Setup
TIME SETTING Manual Clock Setup If the current time setting is wrong, set the clock manually. Select TIME. Select Clock. Select Manual. Select the Year, Month, Date, Hour, or Minute option. Set the Year, Month, Date, Hour, or Minute option. Return to the previous menu.
Page 74: Auto On/Off Time Setting
AUTO ON/OFF TIME SETTING This function operates only if the current time has been set. The Off Time function overrides the On Time function if they are both set to the same time. The TV must be in standby mode for the On Time to work.
Page 75: Sleeptimer Setting
TIME SETTING SLEEPTIMER SETTING The Sleep Time turns the TV off at the preset time. Note that this setting is cleared when the TV is turned off. Press the TIMER button repeatedly to select the number of minutes. Sleep timer options: Off, 10, 20, 50, 60, 90, 120, 180, and 240 minutes. Return to TV viewing.
Page 76: Auto Shut-Off Setting
AUTO SHUT-OFF SETTING TV will be automatically turned off, in case of no signal for 15 minutes. Select TIME. Select Auto Sleep. Select 0 n or Off. Return to the previous menu. Return to TV viewing.
Page 77: Parental Control /Ratings
PARENTALCONTROL / RATINGS Parental Control can be used to block specific channels, ratings and other viewing sources. The Parental Control Function (V-Chip) is used to block program viewing based on the ratings sent by the broad- casting station. The default setting is to allow all programs to be viewed. Viewing can be blocked by choosing the type of the program and the categories.
Page 78 Lock System Enables or disables the blocking scheme you set up previously. Select LOCK. Input the password. © Select Lock System. 01_ When you select 0 n, the Lock System is enable. © Select 0 n or Off. Return to the previous menu. Return to TV viewing.
Page 79 PARENTALCONTROL/RATINGS Set Password Change the password by inputting a new password twice. Select LOCK. Input the password. Select Set password. Choose any 4 digits for your new password. As soon as the 4 digits are entered, re-enter the same 4 digits on the Confirm. Return to the previous menu.
Page 80: Channel Blocking
CHANNEL BLOCKING Blocks any channels that you do not want to watch or that you do not want your children to watch. Block/Unblock Tune Move Move Page MENu Prey ous Exit Select LOCK. Input the password. Select Block Channel. Select a channel to block or unblock. Block or unblock a channel.
Page 81: Movie & Tv Rating
PARENTALCONTROL/RATINGS MOVIE & TV RATING Movie Rating (MPAA) Blocks movies according to the movie ratings limits specified, so children cannot view certain movies. You can set the ratings limit by blocking out all the movies with the ratings above a specified level.
Page 82 TV Rating Children Prevents children from watching certain children's TV programs, according to the ratings limit set. The children rating does not apply to other TV programs. Unless you block certain TV programs intended for mature audi- ences in the TV Rating - sub menu, your children can view those programs.
Page 83 PARENTALCONTROL/RATINGS TV Rating General Based on the ratings, blocks certain TV programs that you and your family do not want to view. Select LOCK. Input the password. Select TV Rating-General. 01_ A ge (applies to TV-G,TV-PG,TV-14,TV- Select Age, Dialogue, Language, MA).
Page 84: Downloadable Rating
DOWNLOADABLE RATING This function may become available in the future and will be available only for digital channels. This function operates only when TV has received Regions Rating data. 01_ B ased on rating table, your TV's OSD (On Screen Display) may differ slightly from what is shown in this manual.
Page 85: External Input Blocking
PARENTALCONTROL/RATINGS EXTERNAL INPUT BLOCKING Enables you to block an input. Select LOCK. Input the password. Select Input Block. © © Select input source. Select On or Off. Return to the previous menu. Return to TV viewing.
Page 86: Interactive Tv Setup
COMMERCIAL MODE SETUP INTERACTIVE TV SETUP Set up the TV for Gem PPV or Gem Operation without a PPV card PPV GEM-TV Setup I. Make all connections as required of PPV system. 2. Set TV to default condition. 3. Configure all relevant installer menu items and TV features.
Page 87: Installeroverview
If necessary, familiarize yourself with the TV Installer menu and how to make and save changes in the menu. LG Installer Remote You will need an LG Installer remote control similar to the one Typical Installer Menu shown to the right.
Page 88: Interactivetv Overview
INTERACTIVETV OVERVIEW Through the interactive TV, the lodging guest is offered a more complete venue of lodge services and amenities. Using the TV in the comfort of the hotel room, the guest can browse the lodge resources available and make selections quickly.
Page 89: Commercialmode Setupfor Mastertv
COMMERCIAL MODE SETUP COMMERCIALMODE SETUPFOR MASTERTV This page provides an overview of a Master TV configuration. Note 1 : Disconnect all Aux inputs. Under certain conditions, Auto Tuning (Channel search) is disabled if there is an Aux input active. [e]:lf_l',i[_] II_[:_:II!=l:i fd:l_LIJ Commercial Mode...
Page 90: Master Tv Profilesetup Learning/Teaching With Usb Memorycard
MASTER TV PROFILESETUP LEARNING/TEACHING WITH USB MEMORYCARD On Master TV, Create Profile and Learn 1. Set up all Master TV features on the menus and do B. By pressing up/down arrow keys(if there is other a Channel Search. Add Channel and Aux Labels etc. menus), place the cursor on Learn From TV, then Tune in an analog channel.
Page 91 COMMERCIAL MODE SETUP On Target TV, Teach Master TV Profile 1. Plug USB memory card with Master TV Profile setup TEACH MODE into Target TV USB input port. The following software files are found in the memory card. 2. Press Menu key to open Main menu and then high- Select the fileyou want to download to this TV.
Page 92: Tll-1100A Cloning Connections/Learning Setup
TLL-1100A CLONING CONNECTIONS/LEARNING SETUP Connections for the TLL-1100A Clone Programmer to Learn the TV Master TV Setup On Master M.P.I. Learning Setup Set up all Master TV features on the ....Selected Bank: CBank X Saved menus and do a Channel Search. Bi|| i _:_ :n,,m = :[o],,l L (2) TEACH TO TV (3) SET CLONE CLOCK FROM W...
Page 93: Lt2002 Cloning Connections/Learning Setup
COMMERCIAL MODE SETUP LT2002 CLONING CONNECTIONS/LEARNING SETUP Connections for the LT2002 Clone Programmer to Learn the TV Master TV Setup " % % i / / Antenna , ii%_ZiJ. or CATV Ferrite Core ......!..........(TDK, ZCAT 2035-0930) QuickSet II Programmer LT2002 Crone Programmer Master TV...
Page 94: Lt2002 Cloning Learningsetup
Since the Clone Programmer's time cannot be set directly, I-I-I the current time needs to be copied from a Zenith/LG I-I-I LT2002 Clone Programmer Communication equipped with M.RI.
Page 95: Cloning Connections/Teaching Setup
COMMERCIAL MODE SETUP CLONING CONNECTIONS/TEACHING SETUP Teaching the Master Setup to Another Connections for the LT2002 to Teach another TV the Master Setup '_" _"r _Antenna or CAW i ..QuickSet II Programmer LTPO02 Crone Programmer Target TV (1) LEARN FROM (2) TEACH TO TV...
Page 96: Installermenu
INSTALLERMENU Use the Installer's Menu to set up or change operational settings. See more detailed descriptions of the Installer menu items on the following pages... Accessing the Installer's Menu Make sure TV is on. Installer's menu items can be accessed by using an installer's remote control.
Page 97 COMMERCIAL MODE SETUP Installer Menu Items 03S through Menu Item Function Value Range Default Value Brief Description of Function and Comments COMPPORT EN. 0 / 1 Note 1. Set to 0 to disable HDMI 1. Set to 1 to enable HDMI 1. YPrPb EN.
Page 98 Detailed Descriptions of Installer Menu Items OOS - CHAN LOCK (Channel Lock) CHAN LOCK is ideal if the system must always be on 000 - INSTALLERSEQUENCE the same channel. Changing channels with Channel Up/Down or keypad numbers is impossible. Channel Specifies entry sequence to the Installer Menu.
Page 99 COMMERCIAL MODE SETUP 023 - CAPTION LOCK - MAX VOLUME (Maximum Volume) This function determines the maximum volume level Set to 1 to restore previous caption On/Off state after turn Off. If set to 0, captions are always Off at turn allowable with the VOLUME (VOL) Up/Down controls.
Page 100 040 - AUTO CAMPORT 073 - CH NOT AVBLE (Channel Not Available) If set to 1 and item 028 CHANNEL OVERRIDE is set to 0, Set to I to automatically switch to Camport when equip- ment is connected to front Video input. "NOT AVAILABLE"...
Page 101 COMMERCIAL MODE SETUP 091 - YPrPb2 (HDMI2 Enable) Set to 202, automatically controls backlighting Set to 0 to disable display panel HDMI2 input. depending upon external spectral sensitivity and picture Set to 1 to enable DTV mode. Set to 2 to enable PC level of the current program.
Page 102: Reference: Detailed Instructions For Making A Master Tv
Be sure to do each task as indicated. If You will also need an LG Installer remote control a procedure or step is left out or not performed com- similar to the one shown in the front of this manual.
Page 103: Reference: Procedures For Adding Channel Label
COMMERCIAL MODE SETUP REFERENCE: P ROCEDURESFOR ADDING CHANNEL LABEL ICONS/CUSTOM CHANNEL LABELS(2-5-4 + MENU MODE) Adding Channel Icons and Labels in the 2-5-4 + Menu Mode Editing/Adding Channel ICONs and/or Editing and adding the labels can only be done if there Labels are channels entered into the TV's channel map either...
Page 104: Reference: Clonable Menu Features
REFERENCE: C LONABLE MENU FEATURES Clonable Menu Features Menu/Sub Menu Features Audio Contd. Lock Treble Movie Rating Installer Menu Bass TV Rating - Children Age Installer Item settings SRS TruSoundXT TV Rating - Children Fantasy Violence TV Speaker Channel TV Rating - General Age Auto Tuning (Channel Lineup) Option Input Block...
Page 105: Reference: Power Saving Setup
COMMERCIAL MODE SETUP REFERENCE: P OWERSAVING SETUP Power Savings Setup Insta[ter Item Power Saving: set to OO1, enabted (Defautt). Installer Item 099 Back[ighting: value set as shown below. (Default value is 255) For 32LG700H Item 099 Picture Powe r Item 099 Picture Power Power...
Page 106 For 42LG700H Item 099 Picture Powe r Item 099 Picture Power Power Power Lumin. Lumin. Backlighting Consumption Savings Backlighting Consumption Savings (Static) (Watts) Ratin_ (Dynamic) (Watts) Ratin_ 41.08 70 164.5 11.08 70 44.32 14Z5 20.27 7o 96.4 4Z89 185.5 133.5 2Z84 7o 89.7 51.51 %...
Page 107: Tv Aux Input Configuration
COMMERCIAL MODE SETUP TV AUX INPUT CONFIGURATION ENABLE MPI DATA MPI DATA DATA STATUS DIRECT ACCESS DATA STATUS TYPE TYPE 0xD2 START Installer Menu Tuning STATUS 0x41 SOURCES CURRENTAV SOURCE TYPE0X0D ASSIGNMENT ENABLED (R/W) SOURCE(R) AUX SOURCE OLDOCV OLD OCV= Source Input Source Mode Number...
Page 108: Tv Camport Auto Senseoperation
TV CAMPORT AUTO SENSEOPERATION The CAMPORTAuto Sensefunction isenabledwhen: CAMPOR's(4Front Video) F_ctional_ Control Item Item 40 FrontVideo 1. InstallerMenu Item 34, CAMPORTEN is set to 1 AND 2. InstallerMenu Item 40, AUTO CAMPORTisenabled (1). CAMPORT EN AUTO CAMPORT Operation Disabled Disabled Selectable= Can be accessed with INPUT key,direct access, Selectable etc.
Page 109: Appendix
APPENDIX TROUBLESHOOTING Is the sleep timer set? Check the power control settings. Power interrupted. I,I,I Check whether the product is turned on. I,I,I Try another channel. The problem may be with the broadcast. inlnl Is the power cord inserted into wall power outlet? inlnff Check your antenna direction and/or...
Page 110 Press the VOL or VOLUME button. Sound muted? Press the MUTE button. Try another channel. The problem may be with the broadcast. Are the audio cables installed properly? Adjust Balance in menu option. A change in ambient humidity or temperature may result in an unusual noise when the product is turned on or off and does not indicate a fault with the...
Page 111: Reference: Lt2002 Cloning Procedure Troubleshooting
I,l_ P ress Reset on clone programmer, redo teach/learn. (Teach/Learn should take a minimum of 1 minute.) ,,i,i Only usean LG Installer remote to operate clone programmer with TV. mConnect M.RI. cord properly, assure good connection. i,i,i TV must be powered On for clone to work.
Page 112: Troubleshootingflowchart
TROUBLESHOOTINGFLOWCHART Quick Controller Check Plug Press 'POWER' or 'ON/OFF' into AC key on TV Power Outlet 1. Defective Defective Press 'POWER' or 'ON/OFF' or 'VOLUME UP/DOWN' 'MUTE' key on Installer Remote 1. Defective Analog Board. 2. Defective Digital Board. 1. Defective 2.
Page 113: Commercialmode Check
COMMERCIALMODE CHECK LIST REFERENCE: RJPMODEL AND INPUT HIERARCHY RiP Model List on the front panel. The On/Off key is always operational. Press the "On/Off" Scaler Models Legacy Models RJP-101M Not Support PCB RJP- 1 01ML Not Support PCB RJP-110F RJP-210F ,_you RJP-110FW RJP-210FW...
Page 114: Glossaryof Terms
GLOSSARYOF TERMS A list of definitions for some of the words found in this guide 7S OHM RF CABLE DIGITAL TELEVISION OUTPUT The wire that comes from an off-air Televisions signals that are transmitted Refers to the output jack that sends a antenna or cable service provider.
Page 115: Maintenance
MAINTENANCE Early malfunctions be prevented. Careful regular cleaning can extend amount of time enjoy your Caution: Be sure to turn power off and unplug the power cord before begin any cleaning. Cleaning the Screen Here's a great way to keep the dust offyour screen for a while.
Page 116: Programming The Remote Control
PROGRAMMING THE REMOTE CONTROL The provided universal remote control can be programmed to operate most remote-controllable devices. Note that the remote may not control all models of other brands. Programming a code into a remote mode Testing your remote control. To find out whether your remote control can operate other...
Page 117 Remote Control Code o3_ 033034o4_ 032040 _o2_o4 MARANTZ ANAM SANSUI SONY 003 009 _!_i_iiiiiiii ii_i!!i!iiiiii_i!iiiii_!_!ii!ii!ii!iiiiii_i!i_!!i_iiiii_ill Iiiiiii'i!ili)!ii!iiiiii_i_ii_ii_il 'ii i i!! _ iii_:i_:i_iii!i_ii!ii_iiii!iiiiiiiii_iiiiii! Zi_i!!ii_ iiilZiiiiiiiiiiiii_! DYNATECH 058 076 EMERSON 029031 0S4 03s 046 I01 OPTONICA SYMPHONIC ..PENTAX 031 033 TATUNG GO VIDEO TECHNICS PHILIPS "O...
Page 118 HDSTB HUGHES SATELUTE S ERVICE CO 028 AMPLICA SCIENTIFICATLANTA 052 SONY BIRDVIEW LEGEND CHANNELM SUPER GUIDE LUTRON CHAPARRAL TEECOM MACOM CURTIS MATHES H]BA NEXTWAVE TRUEVIS!ON(TH ) 155 DXANTENNA 101 135 ......................UBC(TH) ........PHILIPS M RT ELECTRO HOME VlEWSTAR [ 11 PRESIDENT...
Page 119: Ir Codes
IR CODES 1. How to Connect 01_ Connect your wired remote control to the Remote Control port on the TV. 2. Remote Control IR Codes 0_ Output waveform Single pulse, modulated with 3Z917KHz signal at 455KHz Carrier frequency FCAR = 1/TC = fOSC/12 Duty ratio = T1/TC = 1/3 Configuration of frame...
Page 120 POWER Remote control Button (Power On/Off) Discrete IR Code Remote control Button (TV Input Selection) INPUT Remote control Button Discrete IR Code (AV1 Input Selection) Remote control Button Discrete IR Code _1_1 RATIO Remote control Button (AV2 Input Selection) GUIDE Remote control Button COMPONENT...
Page 121: Opensourcelicense
OPENSOURCELICENSE GNU GENERAL PUBLIC LICENSE Version 2, June 1991 Copyright (C) 1989, 1991 Free Software Foundation, Inc., 51 the program proprietary. To prevent this, we have made it clear Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA that any patent must be licensed for everyone's free use or not licensed at all.
Page 122 b) You must cause any work that you distribute or publish, c) Accompany it with the information you received as to the that in whole or in part contains or is derived from the offer to distribute corresponding source code. (This alter- Program or any part there of, to be licensed as a whole at native is allowed only for noncommercial distribution...
Page 123 any later version published by the Free Software Foundation. If, as a consequence of a court judgment or allegation If the program does not specify a version number of this patent infringement or for any other reason (not limited to license, you may choose any version ever published by the patent...
Page 124 END OF TERMS AND CONDITIONS Also add information on how to contact you by electronic paper mail. How to apply these terms to your new programs If the program is interactive, make it output a short notice like this when it starts in an interactive mode: If you develop a new program, and you want it to be of the great- est possible use to the public, the best way to achieve this is to Gnomovision...
Page 125 GNU LESSER GENERAL PUBLIC LICENSE Version 2.1, February 1999 To protect each distributor, we want to make it very clear that Copyright (C) 1991, 1999 Free Software Foundation, Inc. Franklin Street, Fifth Floor, Boston, 02110-1301 there is no warranty for the free library. Also, if the library is mod- Everyone is permitted to copy and distribute verbatim copies...
Page 126 each copy an appropriate copyright notice and disclaimer Although the Lesser General Public License is Less protective the users' freedom, it does ensure that the user of a program that warranty; keep intact all the notices that refer to this license is linked with the Library has the freedom and the wherewithal to and to the absence of any warranty;...
Page 127 the object file is unrestricted, regardless of whether it is legal- You may opt to apply the terms of the ordinary GNU General Public License instead of this License to a given copy of the ly a derivative work. (Executable containing this object code Library.
Page 128 For an executable, the required form of the "work that uses of the rights granted herein. the library" must include any data and utility programs need- You are not responsible for enforcing compliance by third ed for reproducing the executable from it. However, as a spe- parties with this license.
Page 129 To apply these terms, attach the following notices to the library. If the library does not specify a license version number_ you It is safest to attach them to the start of each source file to most may choose any version ever published by the Free Software Foundation.
Page 130 MOZILLA PUBLIC LICENSE Version 1.1 1 •Definitions• code which is described in the source code notice required by exhibit as original code, and which, at the time 1.0.1. "Commercial use" means distribution or otherwise making of its release under this license is not already covered the covered code available to a third party.
Page 131 You may not offer or impose any terms on any source code (c) the licenses granted in this section 2.1 (a) and (b) are effective on the date Initial developer first distributes version that alters or restricts the applicable version original code under the terms of this license.
Page 132 Larger works. (c) Representations. contributor represents that, except as disclosed pursuant You may create a larger work by combining covered code with other code not governed by the terms of this license to section 3.4(a) above, contributor believes that contributor's modifications contributor's original...
Page 133 Z DISCLAIMER OF WARRANTY. such participant under sections 2.1 (b) and 2.2(b) COVERED CODE IS PROVIDED UNDER THIS LICENSE revoked effective as of the date you first made, used, ON AN "AS IS" BASIS, WITHOUT WARRANTY OF ANY sold, distributed, or had made, modifications made by KIND,...
Page 134 11. MISCELLANEOUS• EXHIBIT A -Mozilla Public License• This license represents the complete agreement concerning subject matter hereof. If any provision of this license is The contents of this file are subject to the Mozilla Public License held to be unenforceable, such provision shall be reformed Version 1.1 (the "license");...
Page 135 _®,i,i,l_ s...

This manual is also suitable for:

32lg700h 37lg700h 42lg700h

LG 42700H - 42INCH CLASSHDTV Technical Manual

Quick Links

Troubleshooting

Related Manuals for LG 42700H - 42INCH CLASSHDTV

Summary of Contents for LG 42700H - 42INCH CLASSHDTV

This manual is also suitable for:

Table of Contents
