Emerson Liebert OpenComms-485 Reference Manual page 30

Battery Charger Fail
Data Point
Number Of Input Lines
Number Of Bypass
Lines
Number Of Output
Lines
Number Of
SubModules
Load Circuit Present
Nominal Power Rating
Nominal Input Voltage
Nominal Output
Voltage
Nominal Static Bypass
Switch Voltage
Nominal Input Current
Nominal Input
Frequency
Nominal Output
Frequency
Nominal Power Factor
Nominal Battery
Voltage
Device Low Battery
Time
Load (Apparent
Power)
Load (Real Power)
Load / Capacity
Input Frequency
Output Frequency
Bypass Frequency
Battery Charge Status
Battery Voltage
Battery Current
Battery Time
Remaining
Battery Charge
Percentage
Battery Test Result
10234
Input Holding
Register Register
30004 40004
30004 40004
30004 40004
30009 40009
30013 40013
30021 40021
30027 40027
30028 40028
30029 40029
30030 40030
30031 40031
30032 40032
30033 40033
30034 40034
30053 40053
30102
30104
30106
30107
30108
30109
30112
30113
30114
30115
30116
30130
27
Liebert Monitoring Group –Development
1 1
# of Scale Notes / Units
Reg.
1 1 Bits 12 - 15
1 1 Bits 4 - 7
1 1 Bits 8 - 11
1 1
1 There are 16 possible Load
Circuits. So each bit represents 1
load circuit. Load Circuit 1 is bit
0, Load Circuit 2 is bit 1 and so
on. If the bit is 1 then the Load
Circuit is supported.
2 1 VA
1 1 V
1 1 V
1 1 V
1 1 A
1 10 Hz
1 10 Hz
1 100
1 1 V
1 1 min
2 1 VA
2 1 W
1 1 %
1 10 Hz
1 10 Hz
1 10 Hz
1 1 1 - 100% Charged
2 - Less than 100% Charged
1 1 V
1 1 A
1 1 min
1 1 %
1 1 1 - Unknown
2 - Passed
3 - Failed
4 - In Progress
5 - System Failure
6 - Inhibited
7/6/2007
REV. 5
