  • Page 1 ONITORING OpenComms - 485 Modbus Reference Guide...
  • Page 2 Revision Level Updates: Revision Date Description 11/30/04 Initial Revision 04/10/06 Added Liebert DS Modbus Registers 09/15/06 Updated DS Registers with additional BMS Fan Control data 12/06/06 Update S300/S600 register map 7/6/2007 Document Holding/Input Register, Status and Coil REV. 5 Liebert Monitoring Group –Development 7/6/2007...

  • Page 3: Table Of Contents

    7/6/2007 REV. 5 Liebert Monitoring Group –Development TABLE OF CONTENTS Modbus Communications ... 4 Liebert Nfinity ... 4 Liebert Nx... 4 Liebert PowerSure Interactive ... 4 Liebert PowerSure Interactive 2 ... 4 Liebert GXT2... 4 Liebert HiNet... 4 Liebert UPS Series 600 ... 4 Liebert UPS Series 300 ...

  • Page 4: Modbus Communications

    REV. 5 Liebert Monitoring Group –Development Modbus Communications Connectivity to OpenComms-485 using Modbus This design specification describes the Modbus communications protocol as supported by the OC-485 interface card. It includes information on how to pass information to and from the OC-485 card via Modbus. It is also intended to help facilitate answering questions regarding supported types, frame format, function code support etc.
  • Page 5 Modbus Packet Format Each Modbus packet consists of the following fields: • Device Address • Function Code • Data Field(s) • Error Check Field The address field immediately follows the beginning of the frame and consists of 8-bits (RTU). This bit indicates the user assigned address of the slave device that is to receive the message sent by the attached master device.
  • Page 6 Write multiple Registers The data field varies in length depending on whether the message is a request or a response to a packet. This field typically contains information required by the slave device to perform the command specified or to pass back data to the master device.

  • Page 7: Liebert Nfinity

    Liebert Nfinity Supported Modbus Points Data Point Status Automatic Battery Test 10003 Enabled Battery Charger On 10044 Inverter Ready 10047 Power Factor Correction State 10050 Load On Inverter 10073 Bypass Active 10074 Replace Battery 10081 Battery Under Test 10082 Load On Battery 10128 Load On Bypass 10129...
  • Page 8 UPS Power Not Redundant 10296 Power Module Failure 10298 Battery Module Failure 10299 Power Module Warning 10300 Battery Module Warning 10301 Input Data Point Register Number Of Input Lines 30004 Number Of Bypass Lines 30004 Number Of Output Lines 30004 Number Of Power Mod.
  • Page 9 Battery Charge Percentage 30116 Battery Temperature 30117 Transformer Temperature 30121 Redundant Power Modules 30124 Active Power Module Count 30126 Battery Module Active Count 30127 Battery Test Result 30130 Input Voltage L1 30153 Input Current L1 30154 Bypass Voltage L1 30159 Bypass Current L1 30160 Output Voltage L1...

  • Page 10: Liebert Nx

    Supported Modbus Points Data Point Status Economode 10005 DC-To-DC Converter 10042 Battery Charge Compensation 10046 Inverter Ready 10047 Power Factor Correction State 10050 Battery Charge Mode 10051 Load On Inverter 10073 Bypass Active 10074 Battery Under Test 10082 Load On Battery 10128 Overload Transfer To Bypass...
  • Page 11 Over Temperature DC Bus Balancer Over Temperature 10180 Input Power Supply Fail 10186 Input BrownOut 10189 Bad Input Frequency 10190 Bypass Phase Rotation Error 10191 Bypass Phase Loss 10201 Bypass Input Voltage/Frequency Fault 10202 Output Fuse Blown 10217 Output Over Voltage 10219 Charger Failed 10234...
  • Page 12 Static Bypass Switch Inverter Communication Fail 10281 Rectifier Communication Failure 10282 Parallel Communication Fault 10283 Operation Fault 10289 Data Point Input Register Holding Register # of Reg. Scale Notes / Units Number of Input Lines 30004 Number of Bypass Lines 30004 Number of Output Lines...
  • Page 13 Nominal Battery Float Voltage 30038 Load Bus Sync Mode 30040 Auto Restart Delay 30051 Device Low Battery Time 30053 Input Frequency 30107 Output Frequency 30108 Bypass Frequency 30109 Battery Charge Status 30112 Battery Voltage 30113 Battery Current (Charge/Discharge) 30114 Data Point Register Battery Time Remaining...
  • Page 14 Power L1 Output Power L1 30172 Output Current Crest Factor L1 30186 Input Voltage L2-L3 30201 Input Voltage L2 30203 Input Current L2 30204 Input Power Factor 30205 Bypass Voltage L2 30209 Output Voltage L2 30213 Output Current L2 30214 Output Load L2 30215 Output Power Factor...

  • Page 15: Liebert Powersure Interactive

    Liebert PowerSure Interactive Supported Modbus Points Data Point Status Audible Alarm Enabled 10002 Automatic Battery Test Enabled 10003 Battery Charge Compensation 10046 Inverter Ready 10047 Load Circuit 1 State 10057 Load Circuit 2 State 10058 Load Circuit 3 State 10059 Load Circuit 4 State 10060 Load Circuit 5 State...
  • Page 16 Input Power Supply Fail 10186 Input Over Voltage 10187 Input Under Voltage 10188 Bad Input Frequency 10190 Output Under Voltage 10218 Output Over Voltage 10219 Input Data Point Register Number Of Input Lines 30004 Number Of Bypass Lines 30004 Number Of Output Lines 30004 Number Of SubModules 30009...
  • Page 17 Output Voltage L1 30163 Output Current L1 30164 Input Maximum Voltage L1 30180 Input Minimum Voltage L1 30181 Output Maximum Voltage 30182 Output Minimum Voltage 30183 Black Out Count 30301 Brown Out Count 30302 Liebert Monitoring Group –Development 7/6/2007 REV. 5...

  • Page 18: Liebert Powersure Interactive 2

    Liebert PowerSure Interactive 2 Supported Modbus Points Data Point Status Audible Alarm Enabled 10002 Automatic Battery Test Enabled 10003 DC-To-DC Converter 10042 Battery Charger On 10044 Load Circuit 1 State 10057 Load Circuit 2 State 10058 Load Circuit 3 State 10059 Load Circuit 4 State 10060...
  • Page 19 Hardware Load On Battery 10128 Output Off Pending 10151 Low Battery - Shutdown Imminent 10152 Output Overload 10154 Over Temperature Warning 10171 Input Power Supply Fail 10186 Input Over Voltage 10187 Input Under Voltage 10188 Input BrownOut 10189 Bad Input Frequency 10190 Output Under Voltage 10218...
  • Page 20 Ambient Temperature Warning Point 30069 Over Temperature Limit Point 30072 Load (Apparent Power) 30102 Load (Real Power) 30104 Load / Capacity 30106 Input Frequency 30107 Output Frequency 30108 Battery Charge Status 30112 Battery Voltage 30113 Battery Time Remaining 30115 Battery Charge Percentage 30116 Ambient Temperature...

  • Page 21: Liebert Gxt2

    Liebert GXT2 Supported Modbus Points Data Point Status Audible Alarm Enabled 10002 Automatic Battery Test Enabled 10003 DC-To-DC Converter On 10042 Battery Charge Compensation 10046 Inverter Ready 10047 Power Factor Correction State 10050 Load Circuit 1 State 10057 Load Circuit 2 State 10058 Load Circuit 3...
  • Page 22 Replace Battery 10081 Battery Under Test 10082 Shutdown Reason - Over Temperature 10086 Shutdown Reason - Overload 10087 Shutdown Reason - Link Over Voltage 10088 Shutdown Reason - Output Short 10089 Shutdown Reason - Line Neutral Swap 10090 Shutdown Reason - Low Battery 10092 Shutdown Reason...
  • Page 23 Voltage Data Point Input Register Holding Register # of Reg. Scale Number Of Input Lines 30004 Number Of Bypass Lines 30004 Number Of Output 30004 Lines Number Of SubModules 30009 Load Circuit Present 30013 Battery Cabinet Type 30018 Battery Cabinet Number 30019 Battery AmpHour...
  • Page 24 Battery Charge Status 30112 Battery Voltage 30113 Battery Time Remaining 30115 Battery Charge Percentage 30116 Ambient Temperature 30119 Battery Test Result 30130 Input Voltage L1 30153 Bypass Voltage L1 30159 Output Voltage L1 30163 Output Current L1 30164 Input Maximum Voltage L1 30180 Input Minimum...

  • Page 25: Liebert Hinet

    Liebert HiNet Supported Modbus Points Data Point DC-To-DC Converter On Load On Inverter Bypass Active Load On Battery Permanently On Bypass Bypass SCR Open Circuit Low Battery - Shutdown Imminent Output Overload Inverter Unsynchronized Input Power Supply Fail Bypass Input Voltage/Frequency Fault Data Point Number Of Input Lines...

  • Page 26: Liebert Ups Series 600

    Input Current L2 Input Voltage L3 Input Current L3 Liebert UPS Series 600 Supported Modbus Points Data Point Status Battery Charger On 10044 Battery Charge 10046 Compensation Inverter Ready 10047 Auto Retransfer 10049 Primed Load On Inverter 10073 Load On Bypass 10074 Buck On 10076...
  • Page 27 Input Phase Rotation 10191 Error Bypass Phase Missing 10201 Bypass Input Voltage 10202 Fail Bypass Under Voltage 10203 Fail Bypass Under Voltage 10204 Warning Bypass Over Voltage 10205 Fail Bypass Over Voltage 10206 Warning Output Under Voltage 10218 Output Over Voltage 10219 Output Short Circuit 10220...
  • Page 28 Battery Temperature 30117 PFC Temperature 30118 Ambient Temperature 30119 Local 1 Temperature 30118 Local 2 Temperature 30119 Input Voltage L1 30153 Input Current L1 30154 Bypass Voltage L1 30159 Bypass Current L1 30160 Output Voltage L1 30163 Output Current L1 30164 Input Max.

  • Page 29: Liebert Ups Series 300

    Liebert UPS Series 300 Supported Modbus Points Status Data Point Automatic Restart 10001 Enabled Battery Charge 10046 Compensation Inverter Ready 10047 Load Circuit 1 State 10057 Load Circuit 2 State 10058 Load Circuit 3 State 10059 Load Circuit 4 State 10060 Load Circuit 5 State 10061...
  • Page 30 Battery Charger Fail 10234 Data Point Input Register Number Of Input Lines 30004 Number Of Bypass 30004 Lines Number Of Output 30004 Lines Number Of 30009 SubModules Load Circuit Present 30013 Nominal Power Rating 30021 Nominal Input Voltage 30027 Nominal Output 30028 Voltage Nominal Static Bypass...
  • Page 31 Input Voltage L1 30153 Input Current 30154 Bypass Voltage L1 30159 Bypass Current L1 30160 Output Voltage L1 30163 Output Current L1 30164 Input Voltage L2 30203 Input Current L2 30204 Bypass Voltage L2 30209 Bypass Current L2 30210 Output Voltage L2 30213 Output Current L2 30214...

  • Page 32: Liebert Ds

    Data points Mapped to Input Status and Coils Reference Document: ST100I&C PA Parameters and Events, Version 18.0 Data Description Sleep on Monday Sleep on Tuesday Sleep on Wednesday Sleep on Thursday Sleep on Friday Sleep on Saturday Sleep on Sunday Supply Limit Enable Reheat Lockout Humidifier Lockout...
  • Page 33 Humidification On Dehumidification On Audible Alarm On Reserved MAIN FAN OVERLOAD LOSS OF AIRFLOW LOSS OF FLOW COMP 1 HIGH PRESSURE COMP 1 LOW PRESSURE COMP 1 OVERLOAD COMP 1 PUMPDOWN FAIL COMP 2 HIGH PRESSURE COMP 2 LOW PRESSURE COMP 2 OVERLOAD COMP 2 PUMPDOWN FAIL DIG SCROLL1 HIGH TEMP...
  • Page 34 SENSOR A FAILURE UNIT HRS EXCEEDED COMP 1 HRS EXCEEDED COMP 2 HRS EXCEEDED FC HRS EXCEEDED EL HEAT1 HRS EXCEEDED EL HEAT2 HRS EXCEEDED EL HEAT3 HRS EXCEEDED HW/HG HRS EXCEEDED HUM HRS EXCEEDED DEHUM HRS EXCEEDED NETWORK FAILURE NO CONNECTION W/UNIT 1 UNIT(S) DISCONNECTED UNIT CODE MISSING...
  • Page 35 Data Points Mapped to Input and Holding Registers (A value read from an input register is the real-time data value. A value read from a holding register is the value last set to this modbus server by a user.) Reference Document: ST100I&C PA Parameters and Events, Version 18.0 Data Description Input Register Vendor Id...
  • Page 36 Hour:Minute Sleep Interval 2 30042 Start Time Hour:Minute Sleep Interval 2 30043 End Time Hour:Minute Timer Dead Band 30044 Manual VSD 30045 Timer/Counter[6] High 30050 Temperature Low Temperature 30051 High 30052 Temperature Sensor A Low Temperature 30053 Sensor A High Humidity 30054 Low Humidity 30055...
  • Page 37 Events/Alarm Summary Alarm 30102 Status [8] Fan Ramp 30103 Cooling Ramp 30104 Free Cooling 30105 Ramp Heating Ramp 30106 Humidification 30107 Ramp Dehumidifier 30108 Ramp FreeCooling 30109 Status [9] Return 30110 Temperature Actual 30111 Temperature SP Supply 30112 Temperature Actual Supply 30113 Temperature SP FC Temperature...
  • Page 38 Free cooling run 30146 hours Electrical Heaters 30147 #1 run hours Electrical Heaters 30148 #2 run hours Electrical Heaters 30149 #3 run hours Hot Water / Hot 30150 Gas run hours Daily High 30151 Temperature Daily High Temp 30152 Time Daily Low 30153 Temperature...
  • Page 39 Corporation. All names referred to are trademarks or registered trademarks of their respective owners. Emerson Network Power and the Emerson Network Power logo are trademarks and service marks of Emerson Electric Co. (c)2006 Emerson Electric Co. ONITORING Modbus Reference Guide...
