Page 1: Instruction Manual
INSTRUCTION MANUAL Before using the TV, please read this manual thoroughly, and retain it for future reference. Model:LCD3718A... -
Page 3: Table Of Contents
CONTENTS SAFETY PRECAUTION IMPORTANT SAFETY INSTRUCTION MAINTENANCE ACCESSORIES GETTING STARTED Remote Control CONTROL Front View REFERENCE Back View GUIDE Right Side View Antenna Connection S-Video Connection AV Connection Y Pb Pr Connection CONNECTIONS HDMI Connection VGA Connection Power Cord Connection SPDIF Connection WALL MOUNT INSTALLATION... - Page 4 CONTENTS PC Formats DISPLAY Video Formats MODE SPECIFICATION TROUBLE- SHOOTING GUIDE SAFETY CLASS :This is an IEC safety class I product and it must be grounded for safety.
-
Page 5: Safety Precaution
SAFETY PRECAUTION PLACEMENT INFORMATION CAUTION MARKING WAS LOCATED AT REAR PORTION OF THE APPARATUS. • Do not use this unit in places that are extremely hot, cold, dusty or humid. • Do not restrict the airflow of this unit by placing it somewhere with poor airflow, by covering it with a cloth, by placing it on bedding or carpeting. -
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 12) Use only with the cart, stand, 2) Keep these instructions. tripod, bracket, or table 3) Heed all warnings. specified by the manufacturer, 4) Follow all instructions. or sold with the apparatus. 5) Do not use this apparatus near water. When a cart is used, use caution when 6) Clean only with a dr y cloth. -
Page 7: Accessories
ACCESSORIES Please check and identify the supplied accessories. Remote control ......................... Batter y AA （ ） ......................... . Power Cord ..........................Warranty Card ..........................Instruction Manual ........................GETTING STARTED USING THE REMOTE CONTROL • Point the remote control at the remote sensor located on the unit. -
Page 8: Control Reference Guide
CONTROL REFERENCE GUIDE TV FUNCTION BUTTONS REMOTE CONTROL STANDBY / ON Button Press to turn ON the unit or put it in STANDBY (OFF) mode. 2. MUTE Button Press to turn the sound on / off MUTE DISPLAY 3. Display Button Press to d isplay the source and channel information. -
Page 9: Front View
CONTROL REFERENCE GUIDE FRONT VIEW 1. Color LCD Screen Indicator Light in blue The unit is turned ON Remote Sensor Do not block this sensor or the remote control will not work . Speakers . TV ANTENNA Terminal BACK VIEW S/PDIF out (coaxial) S-VIDEO IN Jack AV IN Jack... -
Page 10: Side View
CONTROL REFERENCE GUIDE SIDE VIEW RIGHT 1. TV / AV Button omponent1 Select TV, AV , 1 AV2, S-VIDEO C omponent2, HDMI1, HDMI2,HDMI3, 2. MENU Button Press to display the on-screen TV menu. 3. CH+ Button Press to change the TV channels and highlight selections on the menu screen. -
Page 11: Connections
CONNECTIONS CONNECTING A TV ANTENNA / CABLE / SATELLITE TV REAR PANEL To view television channels correctly, a signal must be received from one of the following sources: - An indoor or outdoor aerial antenna HDMI 3 HDMI 2 HDMI 1 - A cable system - A satellite system NOTE... -
Page 12: Y Pb Pr Connection
CONNECTIONS CONNECTING A HIGH-DEFINITION (HD) SOURCE USING Y Pb Pr CONNECTION High-Definition (HD) Devices with component video output must be connected to the Y PbPr input. Connect the component video cable and audio cable (not included) as shown. Make sure you connect the component video cable and audio cable from the other equipment Y Pb Pr AUDIO OUT ) to this unit (... - Page 13 CONNECTIONS CONNECTING A Connect the 15-pin D-SUB PC/VGA connector from your computer to the 15-pin D-SUB PC/VGA input on this unit using a monitor cable and an audio cable (not included) as shown. Make sure you connect the cable from the computer AUDIO - PC OUT ) to this unit AUDIO - PC IN...
- Page 14 CONNECTIONS Connection to a Home Theater Audio System For BEST audio performance How To Setup Digital Output* Connecting to a Home Theater System Press the MENU button on the remote control Dolby Digital can deliver optimal 2 channel • Press the right arrow button to select AUDIO stereo or surround sound with five discrete •...
-
Page 15: Wall Mount Installation
WALL MOUNT INSTALLATION INSTALLING REMOVING THE BASE STAND WARNING : The LCD Display is ver y fragile and must be protected at all times when removing the base stand Be sure that no hard or sharp object or anything that could scratch or damage the LCD display comes into contact with it Do NOT exert pressure on the front of the unit at any time because the screen could crack 1 Disconnect all cables or cords connected to the unit 2 Lay the unit down on a flat surface with the back side facing up Please make sure to place a soft... -
Page 16: Initial Setup
INITIAL SETUP PUTTING THE UNIT ON A PROPER PLACE When you turn on your television set for the first time, be sure to place it on a solid stable surface. To avoid danger, do not expose the TV to water, or a heat source (e.g. - Page 17 INITIAL SETUP How to Navigate Air Mode: Cable Mode: Select when connected to an Select CABLE if you subscribe to indoor/outdoor antenna. a pay television service includ ing satellite. Setup Setup Picture Audio Time Parental Picture Audio Time Parental Air/Cable Cable Air/Cable Auto Scan...
-
Page 18: Tv Setup
TV SETUP PICTURE MENU Picture PICTURE menu offers options to enhance and refine the picture displayed on your TV based on ambient room light and personal prefer ences. Adjustment options include contrast, brightness, color, sharpness and color temperature. How to Navigate: Press the MENU button on the remote control. - Page 19 TV SETUP PICTURE MENU Picture PICTURE menu offers options to enhance and refine the picture displayed on your TV based on ambient room light and personal prefer ences. Adjustment options include contrast, brightness, color, sharpness and color temperature. How to Navigate: Press the MENU button on the remote control.
-
Page 20: Audio Menu
TV SETUP AUDIO MENU Audio AUDIO menu offers options to make sound enhancements while listening through the built-in speakers and personal preferences. Adjustment options include bass, treble, balance, surround , AVC and audio language. How to Navigate: Press the MENU button on the remote control. - Page 21 TV SETUP AUDIO MENU Audio AUDIO menu offers options to make sound enhancements while listening through the built-in speakers and personal preferences. Adjustment options include bass, treble, balance, surround , AVC and audio language. How to Navigate: Press the MENU button on the remote control.
-
Page 22: Time Menu
TV SETUP TIME MENU Time TIME menu includes adjustment of settings for your local time zone and daylight savings time. The clock will adjust automatically after the initial Channel Auto Scan of available broadcast channels in your area. How to Navigate: Press the MENU button on the remote control. -
Page 23: Setup Menu
TV SETUP SETUP MENU Setup In the SETUP menu you may change the initial set up of preferences that include settings for language, menu display, computer monitoring, closed captions, enhancement of black detail in the picture and resetting your TV back to its factory default status. How to Navigate: Press the MENU... - Page 24 TV SETUP SETUP MENU Setup SETUP menu includes adjustments for activating the Closed Caption feature for display on the television and customizing CC display types and font styles. How to Navigate: Setup Picture Audio Time Parental Setup Setup Parental Picture Picture Audio Audio...
- Page 25 TV SETUP SETUP MENU Setup In the SETUP menu you may adjust the position of images displayed on screen once you connect an input signal from your PC. Recom mended resolution is 1366 x 768. If your PC system uses a standard signal mode, the screen will adjust automatically. Connect an optional 3.5mm audio cable for stereo sound.
-
Page 26: Parental Menu
TV SETUP PARENTAL MENU Lock In the PARENTAL menu you may block television by inputting passwords. To gain access and select your preferences within the Parental menu make certain your input is set to TV. How to Navigate: Press the MENU button on the remote control. - Page 27 TV SETUP PARENTAL MENU Lock In the PARENTAL menu you may block television and movie programming based on U.S TV and movie rating guidelines. To gain ac cess and select your preferences within the Parental menu make certain your input is set to TV. How to Navigate: Press the MENU...
- Page 28 TV SETUP PARENTAL MENU Lock In the PARENTAL menu you may block television and movie programming based on Canadian TV and movie rating guidelines. To gain ac cess and select your preferences within the Parental menu make certain your input is set to TV. How to Navigate: Press the MENU...
-
Page 29: Tv Menu
TV SETUP TV MENU Channel menu provides for the setup of your television to receive TV channels, store your favorites, add or skip channels and label them by their call letters. How to Navigate: Press the MENU button on the remote control. Navigate using the buttons to select Press the button to highlight your preferences. -
Page 30: Zoom Function
TV SETUP ZOOM MODE ZOOM function offers several viewing display options on the 16:9 screen. Press ZOOM to cycle through the following widescreen settings. TV / AV GUIDE RECALL ZOOM 1 NORMAL Recommended for viewing native widescreen content and undistorted 4:3 images. (With Black Bars) 2 WIDE Stretches certain 4:3 content and... -
Page 31: Display Mode
DISPLAY MODE PC FORMATS Horizontal Vertical Resolution Scanning Frequency Scanning Frequency Format (KHz) (Hz) 1024 1024 1024 1360 47.7 NOTE: This product does not support the display mode not listed above. ● In order to achieve the best display effect, please select the above-listed 12 display modes input signal. -
Page 32: Video Formats
DISPLAY MODE VIDEO FORMATS SUPPORTED COMPONENT Horizontal Vertical Resolution Scanning Frequency Scanning Frequency Format (KHz) (Hz) 59.94 480 i 31.47 15.734 59.94 480 p 720 p 37.5 1280 1280 720 p 1920 1080 1080 i 33.75 28.125 1080 i 1920 1080 HDMI INPUT MODE Horizontal... -
Page 33: Specification
SPECIFICATION " Model Description 37 LCD TV Panel Type Flat Panel LCD Diagonal Size 37 inches 16 9 : Screen Format Resolution 1366 Panel Brightness 400 nit Contrast 2500 : 1 View Angle Response Time 6.5 ms Maximum Color 16.7 M Color System ATSC/QAM/NTSC Sound System... -
Page 34: Troubleshooting Guide
TROUBLESHOOTING GUIDE SYMPTOM CAUSE AND REMEDY • Make sure the AC power cord is connected. No power. • Turn on the unit. The remote does • Remove any obstacles between the remote and the unit. not function. • Use the remote near the unit. •... - Page 35 THANK YOU FOR PURCHASING THIS THANK YOU FOR PURCHASING THIS CURTIS CURTIS PRODUCT . PRODUCT . WE WANT TO HELP YOU ACHIEVE A PERFECT EXPERIENCE. WE WANT TO HELP YOU ACHIEVE A PERFECT EXPERIENCE. Digital Television Transition Notice: This device contains a digital television tuner, so it should...
