- Page 1 P L E A S E T H I N K B E F O R E Y O U P RI N T SMART Document Camera 330 User’s Guide...
-
Page 2: Technical Support
SMART Technologies ULC. Information in this manual is subject to change without notice and does not represent a commitment on the part of SMART. -
Page 3: Important Information
Important information WARNING – Failure to follow the installation instructions shipped with your SMART product can result in personal injury and damage to the product. – Ensure that any cables extending across the floor to your SMART product are properly bundled and marked to avoid a trip hazard. –... - Page 4 – Do not carry your SMART product by the camera arm. Carry it by the base of the unit. – Disconnect your SMART product from the power outlet before cleaning it. Use a clean damp cloth and do not use liquid or aerosol cleaners or solvents when cleaning your SMART product.
-
Page 5: Table Of Contents
Contents Important information..................i Overview ....................... 1 About your SMART Document Camera 330........... 1 Parts of the document camera................ 3 Document camera software................6 Setting up your document camera ................ 7 Document camera basic connection............... 8 Setup configurations for Camera view and SD Card view......9 Connecting your document camera to an external display...... - Page 6 – C O NT EN TS Using the SD Card view on-screen display menu .........38 Troubleshooting ....................45 Hardware environmental compliance ..............47 Waste Electrical and Electronic Equipment regulations (WEEE directive)..47 Restriction of Certain Hazardous Substances (RoHS directive) ....47 Packaging .....................48 China’s Electronic Information Products Regulations (EIP) ......48 U.S.
-
Page 7: Overview
Chapter 1 Overview About your SMART Document Camera 330 Your SMART Document Camera 330 allows you to display 3D objects, printed documents and microscope slides on your computer, projector or television. You can capture images and save them to a SMART Notebook™ collaborative learning software file or to an SD or SDHC memory card. -
Page 8: Document Camera Features
CH A P T E R 1 – OV ERV IEW Document camera features Camera • High resolution 1.3 MP CMOS sensor • 5.2× optical zoom, 8.0× digital zoom • Up to 30 frames per second • Automatic or manual focus •... -
Page 9: Parts Of The Document Camera
CH A P T E R 1 – OV ERV IEW • SD Card view controls your document camera from the camera’s control panel and displays images from an SD or SDHC memory card on a connected projector or television. See Understanding Computer, Camera and SD Card views on page 14 for more information on these views. -
Page 10: Control Panel
CH A P T E R 1 – OV ERV IEW Control panel You can use the control panel to switch between Computer, Camera and SD Card view, capture an image to an SD or SDHC memory card and adjust brightness settings. -
Page 11: Side Connection Panel
CH A P T E R 1 – OV ERV IEW Side connection panel The side connection panel has a security lock slot, an SD or SDHC memory card slot, a USB-A connector, a switch for selecting VGA, DVI-D or composite video output, and a switch to select either SXGA, WXGA, 720p or XGA resolution. -
Page 12: Document Camera Software
CH A P T E R 1 – OV ERV IEW Anti-glare sheet Place the anti-glare sheet over printed documents to reduce glare. Document camera software Your document camera includes software downloads that will help you present images from your document camera. SMART Notebook software and SMART Product Drivers Your document camera uses SMART Notebook collaborative... -
Page 13: Setting Up Your Document Camera
Chapter 2 Setting up your document camera This chapter describes the following set up tasks for your document camera: • Document camera basic connection on page 8 • Setup configurations for Camera view and SD Card view on page 9 –... -
Page 14: Document Camera Basic Connection
CH A P T E R 2 – S E TT I NG UP Y O U R D O C UME NT C A ME RA Document camera basic connection Connect your document camera to a power supply and your computer to use your document camera with SMART Notebook software. -
Page 15: Setup Configurations For Camera View And Sd Card View
CH A P T E R 2 – S E TT I NG UP Y O U R D O C UME NT C A ME RA Setup configurations for Camera view and SD Card view After you complete the basic connection procedure (see page 8), you can connect your document camera to an external display. -
Page 16: Connecting Your Document Camera To An External Display
10 | CH A P T E R 2 – S E TT I NG UP Y O U R D O C UME NT C A ME RA Connecting your document camera to an external display You can connect your document camera directly to an external display to enable the following functions: •... -
Page 17: Connecting Your Document Camera To A Television
11 | CH A P T E R 2 – S E TT I NG UP Y O U R D O C UME NT C A ME RA Connecting to a digital projector or HD display with DVI-D You can connect your document camera to a digital projector or high-definition display using a DVI-D single link cable. -
Page 18: Downloading Software
12 | CH A P T E R 2 – S E TT I NG UP Y O U R D O C UME NT C A ME RA Setting output resolution You can set your document camera’s output resolution to match the projector or display you’re using. -
Page 19: Using Your Document Camera
Chapter 3 Using your document camera This chapter describes how to use your document camera and perform the following tasks: • Understanding Computer, Camera and SD Card views on page 14 – Identifying view features on page 15 – Setting document camera views on page 16 •... -
Page 20: Understanding Computer, Camera And Sd Card Views
14 | CH A P T E R 3 – U S IN G Y O UR D O CU MEN T C A MER A Understanding Computer, Camera and SD Card views You can use your document camera in Computer, Camera and SD Card views. Each view allows you do different things and requires a specific connection to either a display, projector or computer. -
Page 21: Identifying View Features
15 | CH A P T E R 3 – U S IN G Y O UR D O CU MEN T C A MER A Identifying view features The following table describes the differences between each view: Computer Camera SD Card Feature description view... -
Page 22: Performing Basic Operations
16 | CH A P T E R 3 – U S IN G Y O UR D O CU MEN T C A MER A Setting document camera views To set Computer view Press the Computer view button on the control panel. For more information, see page 21. -
Page 23: Using The Led Light
17 | CH A P T E R 3 – U S IN G Y O UR D O CU MEN T C A MER A Using the LED light You can use the LED light on the camera head to illuminate your subject. To turn the LED light on Switch the LED light switch to the left. -
Page 24: Inserting And Removing An Sd Or Sdhc Memory Card
18 | CH A P T E R 3 – U S IN G Y O UR D O CU MEN T C A MER A 2. Select Image Setting, and then press Enter 3. Select Image mode, and then press Enter 4. -
Page 25: Using Your Document Camera With Smart Notebook Software
19 | CH A P T E R 3 – U S IN G Y O UR D O CU MEN T C A MER A Using your document camera with SMART Notebook software Your document camera integrates with SMART Notebook software, allowing you to control your document camera from your computer or a SMART Board interactive whiteboard. - Page 26 20 | CH A P T E R 3 – U S IN G Y O UR D O CU MEN T C A MER A To capture to the current In the SMART Document Camera window, press Capture and close. SMART Notebook page Press the capture button on the control panel.
-
Page 27: Using Your Document Camera In Computer View
Chapter 4 Using your document camera in Computer view Topics in this chapter include: • About Computer view on page 21 • Setting Computer view on page 21 • Using Computer view on page 22 About Computer view This view is for presenting images from your document camera through your SMART Notebook software or Image Mate software. -
Page 28: Using Computer View
22 | CH A P T E R 4 – U S IN G Y O UR D O CU MEN T C A MER A IN CO M P UT E R V IE W 3. Press the Computer view icon on the control panel. IMPORTANT Your document camera must be in Application mode. -
Page 29: Using Your Document Camera In Camera View
Chapter 5 Using your document camera in Camera view This chapter contains the following information on Camera view. • About Camera view on page 23 • Setting Camera view on page 24 • Using Microscope mode on page 25 • Using the Camera view’s on-screen display menu on page 25 –... -
Page 30: Setting Camera View
24 | CH A P T E R 5 – U S IN G Y O UR D O CU MEN T C A MER A IN CA MER A V IE W Setting Camera view Switch your document camera to Camera view to display images on a projector, flat-panel display or television. -
Page 31: Using The Camera View's On-Screen Display Menu
25 | CH A P T E R 5 – U S IN G Y O UR D O CU MEN T C A MER A IN CA MER A V IE W Using Microscope mode The SMART Document Camera allows you to view the microscope stage through the document camera without additional attachments. - Page 32 26 | CH A P T E R 5 – U S IN G Y O UR D O CU MEN T C A MER A IN CA MER A V IE W 6. To return to the previous menu level, use the down arrow button to navigate to Back , and then press Enter To exit the menu, press Menu.
-
Page 33: Camera View Image Settings On-Screen Display Menu
27 | CH A P T E R 5 – U S IN G Y O UR D O CU MEN T C A MER A IN CA MER A V IE W Camera view Image Settings on-screen display menu To access the Image Select Camera view >... - Page 34 28 | CH A P T E R 5 – U S IN G Y O UR D O CU MEN T C A MER A IN CA MER A V IE W Image Setting menu options Description Text 1 Optimizes image for displaying text Image mode documents by emphasizing contrast.
-
Page 35: Camera View Special Tools On-Screen Display Menu
29 | CH A P T E R 5 – U S IN G Y O UR D O CU MEN T C A MER A IN CA MER A V IE W Camera view Special Tools on-screen display menu To access the Special Select Camera view >... - Page 36 30 | CH A P T E R 5 – U S IN G Y O UR D O CU MEN T C A MER A IN CA MER A V IE W To use the 1. Display an object in Camera view, and then press Menu on the control panel. Highlight setting The on-screen display menu appears.
- Page 37 31 | CH A P T E R 5 – U S IN G Y O UR D O CU MEN T C A MER A IN CA MER A V IE W Using Image Masks Image Masks obscure most of the image. You can resize or move the mask to reveal more of the image.
- Page 38 32 | CH A P T E R 5 – U S IN G Y O UR D O CU MEN T C A MER A IN CA MER A V IE W To display the 1. Display an object in Camera view, and then press Menu on the control panel. Scroll setting The on-screen display menu appears.
-
Page 39: Camera View Function Settings On-Screen Display Menu
33 | CH A P T E R 5 – U S IN G Y O UR D O CU MEN T C A MER A IN CA MER A V IE W To turn off the PiP setting Press Enter on the control panel. - Page 40 34 | CH A P T E R 5 – U S IN G Y O UR D O CU MEN T C A MER A IN CA MER A V IE W Function Settings menu options Description English Sets language to English Language Français Sets language to French...
-
Page 41: Saving Images To An Sd Or Sdhc Memory Card
35 | CH A P T E R 5 – U S IN G Y O UR D O CU MEN T C A MER A IN CA MER A V IE W To set your 1. Connect your document camera to a projector or flat-panel display with the VGA document camera to cable (see page 10). -
Page 42: Capturing Images To An Sd Or Sdhc Memory Card
36 | CH A P T E R 5 – U S IN G Y O UR D O CU MEN T C A MER A IN CA MER A V IE W Capturing images to an SD or SDHC memory card To capture images to an 1. -
Page 43: Using Your Document Camera In Sd Card View
Chapter 6 Using your document camera in SD Card view Topics in this chapter include the following: • Setting your document camera to SD Card view on page 37 • Using the SD Card view display on page 38 • Using the SD Card view on-screen display menu on page 38 –... -
Page 44: Using The Sd Card View Display
38 | CH A P T E R 6 – U S IN G Y O UR D O CU MEN T C A MER A IN S D C A RD V I E W Using the SD Card view display To display images 1. - Page 45 39 | CH A P T E R 6 – U S IN G Y O UR D O CU MEN T C A MER A IN S D C A RD V I E W IMPORTANT The SD Settings are only available if you have your document camera set to Application mode in the Camera view on-screen display menu.
- Page 46 40 | CH A P T E R 6 – U S IN G Y O UR D O CU MEN T C A MER A IN S D C A RD V I E W 4. Select SD, and then press Enter 5.
- Page 47 41 | CH A P T E R 6 – U S IN G Y O UR D O CU MEN T C A MER A IN S D C A RD V I E W 4. Repeat steps one to three to unlock other images for your slideshow. Special Tools on-screen display menu To access the Special Select SD Card view...
- Page 48 42 | CH A P T E R 6 – U S IN G Y O UR D O CU MEN T C A MER A IN S D C A RD V I E W Slideshow Settings on-screen display menu To access the Slideshow Select SD Card view >...
- Page 49 43 | CH A P T E R 6 – U S IN G Y O UR D O CU MEN T C A MER A IN S D C A RD V I E W Displaying specific images in a Slideshow You can set your document camera to display only images that you select.
- Page 50 44 | CH A P T E R 6 – U S IN G Y O UR D O CU MEN T C A MER A IN S D C A RD V I E W...
-
Page 51: Troubleshooting
Chapter 7 Troubleshooting Document camera issues Use the following table to troubleshoot issues with your document camera. Issue Solution No image displays or • Turn off your document camera (see page 16). appears. Securely connect all cables and connect the camera’s AC adapter to a power outlet. -
Page 52: Sd Card View Issues
46 | CH A P T E R 7 – T R O U B L E S H O O T I N G Issue Solution The image is too dark. • Press the brightness buttons on your document camera. -
Page 53: Hardware Environmental Compliance
Appendix A Hardware environmental compliance SMART Technologies supports global efforts to ensure that electronic equipment is manufactured, sold and disposed of in a safe and environmentally friendly manner. Waste Electrical and Electronic Equipment regulations (WEEE directive) Waste Electrical and Electronic Equipment regulations apply to all electrical and electronic equipment sold within the European Union. -
Page 54: Packaging
China’s EIP regulations. U.S. Consumer Product Safety Improvement Act The United States has enacted the Consumer Product Safety Improvement Act which limits the lead (Pb) content in products used by children. SMART Technologies is committed to complying with this initiative. -
Page 55: Customer Support
Appendix B Customer support Online information and support Visit www.smarttech.com/support to view and download user’s guides, how-to and troubleshooting articles, software and more. Training Visit www.smarttech.com/trainingcenter for training materials and information about our training services. Technical support If you experience difficulty with your SMART product, please contact your local reseller before contacting SMART Technical Support. -
Page 56: General Inquiries
50 | AP PENDI X B – C U S T O M E R S U P PO R T General inquiries Address SMART Technologies 3636 Research Road NW Calgary, AB T2L 1Y1 CANADA Switchboard +1.403.228.5940 or Toll Free 1.866.518.6791 (U.S./Canada) +1.403.228.2500... - Page 58 Toll Free 1.866.518.6791 (U.S./Canada) or +1.403.228.5940 www.smarttech.com...
