Summary of Contents for Skyworth LCD-22L19
- Page 1 Instruction Manual LCD-22L19 22" LCD TV/MONITOR SIZE:A5 Description: MANUAL(8M34A) 95120H skyworth Job No. Brand Name: 22L19 MODEL: P/No. REV:0 Scale: Engineering Dept: 2009-06-04 Artwork By: Date: Checked By: Date: Approved By: Date:...
-
Page 2: Safety Precaution
SAFETY PRECAUTIONS Read all of the instructions before operating the set. Keep these instructions well for later use. PRODUCT The ventilation should not be impede by covering the ventilation openings with items, such as newspaper, table-cloths, curtains, etc. Do not push any objects of any kind into this unit through the cabinet slots as they could touch the current carrying parts or short-circuit parts, resulting in fire, electric shock, or damage to the unit. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS USE ENVIRONMENT Do not install this equipment in a confined space such as a book case or similar unit. To prevent injury, this apparatus must be securely attached to the wall mount fastened on the wall. Place the set on a place that allows good ventilation. Do not use the set near damp, and cold areas, protect the set from overheating. -
Page 4: Table Of Contents
CONTENT SAFETY PRECAUTION ................. CONTENT ..................... INTRODUCTION, FUNCTIONS AND FEATURES ........EXTERNAL SCHEMATIC AND INSTALLATION ........... FRONT PANEL ................... BACK PANEL ..................ANTENNA/CABLE CONNECTION ............ REMOTE CONTROL ................. PACKAGING ..................10 SETUP TV ..................... MENU CONTROL ..................BASIC OPERATION ................PICTURE SETTINGS ................. SOUND SETTINGS ................ -
Page 5: Introduction, Functions And Features
INTRODUCTION, FUNCTIONS AND FEATURES BRIEF INTRODUCTION: Thanks for your purchase of our digital high-definition LCD television! This product with diverse functions is designed to fulfill the optimum requirements from commercial, industrial and household uses. LCD television possesses the display function of both TV and PC. It features advanced picture performance, smaller in size and lighter in weight, meanwhile, consumes less power and makes no radiation. -
Page 6: External Schematic And Installation
EXTERNAL SCHEMATIC AND INSTALLATION FRONT PANEL Note: The graphics are for representation only. 1.AV/TV Button 2.Menu Button 3.Program Up Button 4.Program Down Button 5.Volume Up Button 6.Volume Down Button 7.Standby Button 8.Power Indicator 9.Remote Sensor 10.Speakers... -
Page 7: Back Panel
EXTERNAL SCHEMATIC AND INSTALLATION BACK PANEL Note: The graphics are for representation only. AV IN HDMI S-VIDEO R-AUDIO-L VIDEO VGA AUDIO IN EARPHONE 1. HDMI:Connect HDMI input signal from signal source such as DVD. 2. VGA: Connect a PC via a VGA cable. 3. -
Page 8: Antenna/Cable Connection
EXTERNAL SCHEMATIC AND INSTALLATION ANTENNA/CABLE CONNECTION There are two kinds of antenna in use. VHF TV ANTENNA TWO KINDS OF ANTENNA UHF TV ANTENNA To TV VHF/UHF No need to install adapter ANTENNA jack (Note 1) U/V MIXER COAXIAL ANTENNA Need to install adapter VHF/UHF (Note 2) -
Page 9: Remote Control
EXTERNAL SCHEMATIC AND INSTALLATION REMOTE CONTROL 1. STANDBY BUTTON Press to turn the TV on or off(standby). 2. MUTE BUTTON Press to mute or restore the TV sound. 3. NUMBER BUTTONS Press to enter a channel number . 4. AV/TV BUTTON Press to display the signal source... - Page 10 EXTERNAL SCHEMATIC AND INSTALLATION REMOTE CONTROL 18. SOUND TYPE BUTTON(NICAM) Press this button to select different sound type. Relevant sound types in TV SOURCE as below: 1. MONO: MONO 2. STEREO: MONO, STEREO 3. DUAL : MONO, DUAL1, DUAL2 NOTE: This button is unavailable for models without NICAM function.
-
Page 11: Packaging
EXTERNAL SCHEMATIC AND INSTALLATION For using the remote control, follow these instructions: 1. Open the back cover of the remote control, then insert two AAA batteries with polarities matching with the marks inside the battery compartment. Then, close the back cover. Point the remote control towards the infra-red remote sensor on the main unit. -
Page 12: Setup Tv
SETUP TV There are several steps you need to follow before you can turn on the TV. Follow the instructions below to set up and turn on your TV. Operation could be different base on existence of hard power switch. 1. -
Page 13: Menu Control
MENU CONTROL This section explains the menus of your TV. Each menu is outlined and detailed to help you get the most from your TV. BASIC OPERATION 1. Press MENU on the remote control or on the TV key panel to display the main menu. 2. -
Page 14: Sound Settings
MENU CONTROL SOUND SETTINGS Sound mode Select the audio mode as you desired. The audio mode are Standard,Music, Film, Voice. Bass Adjusts the lowest part of the sound. SOUND Sound mode Voice Bass Treble Adjusts the highest part of the sound. Treble Balance Balance Adjusts how much audio (loudness) gets... -
Page 15: Time Settings
MENU CONTROL Fine tuning Tune RF frequency finely. Skip Sets the current channel to skip or not. INSTALLATION Notes: 120.25MHZ Fine 1. If the channel is set to skip, you can not Skip Fav. channel select it by pressing PROGRAM UP/DOWN on the remote control. -
Page 16: Function Settings
MENU CONTROL FUNCTION SETTINGS Language Select you desired OSD language. FUNCTION Zoom select your desired picture zoom effect. English Language Zoom 16:9 You can select 16:9 or 4:3( only available for wide screen OSD halftone modesl Parent ctrl. OSD halftone select different OSD background Move Select Return... - Page 17 SHORTCUT FUNCTIONS This section explains the s hortcut and convenient functions PICUTRE shortcut 1. Press the PICTURE button on the remote control to display the current picture state. 2. Press the PICTURE button repeatedly to select different picture effect. 3. The on screen display will disappear in 3 seconds if you stop adjusting. Note: You can select Standard, Bright, Personal or Soft.
-
Page 18: Shortcut Functions
SHORTCUT FUNCTIONS Z-/Z+ shortcut( only available for wide screen models) Press to change the screen format: 4:3, 16:9. Only available for wide screen models FAV. shortcut 1. Press the FAV. button on the remote control repeatly , it will select FAV. -
Page 19: Troubleshooting
TROUBLESHOOTING NO PICTURE, NO SOUND SNOWY DOTS AND INTERFERENCE If the antenna is located in the fringe area of a 1. Check if the fuse or circuit breaker is working. television signal where the signal is weak, the 2. Plug another electrical device into the outlet to picture may be marred by dots. -
Page 20: Specifications
SPECIFICATIONS Mode: LCD-22L19 2W+2W Audio output power (L+R): Working voltage: 100-240V~ 50/60Hz Rated power consumption: Screen size - diagonal: 54.8cm Dimensions (W x D x Hmm): 528 x 200 x 390mm Net weight: 4.3Kg Environment: Working temperature: 5 C~35 C Working humidity: 20%~80% Storage temperature: -15 C~45 C Storage humidity: 10%~90%...
