Summary of Contents for TRENDnet TEW-716BRG

  • Page 1 Table of Contents TRENDnet User’s Guide © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 2: Table Of Contents

    Check connectivity using the router management page ..........30 Advanced Router Setup ..............18 Check the router system information ................. 30 Access your router management page ................ 18 View your router log ....................31 © Copyright 2012 TRENDnet. All Rights Reserved.
  • Page 3 Enable SNMP on your router ..................34 Add static routes to your router .................. 34 Enable dynamic routing on your router ..............35 Router Management Page Structure ..........36 Technical Specifications..............37 Troubleshooting ................38 Appendix ..................39 © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 4: Product Overview

    The device also features a built in hanging hook allowing users to neatly hang the TEW-716BRG on the back of a laptop screen while working. The TEW- 716BRG makes it easy to share a single Internet connection while at the airport, job site, carpooling, or even while on vacation.

  • Page 5: Product Hardware Features

    WPS/Reset Button: Press and hold this button for 3 seconds to activate WPS Push Button Configuration (PBC) or Press and hold for 10 seconds to reset the router back to factory default settings. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 6: Application Diagram

    Hanging Clip: Remove the hanging clip from the router to use as a hanging clip to most monitors. Press the button on the back of the router to release the hanging clip and rotate the clip around and clip back to the router. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 7: Basic Router Setup

    • Computers/devices with an Ethernet port (also called network port) or wireless networking capabilities. • A modem and Internet service to your home, provided by your ISP (modem typically supplied by your ISP). • A router to connect multiple devices to the Internet. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 8: Router Installation

    Next. 3. Connect your 3G dongle to the USB port of the TEW-716BRG. 4. Move the power switch of the TEW-716BRG to the On position and verify that the LEDs are turned on. 5. Connect your computer wirelessly to the TEW-716BRG. The default SSID (Wireless 7.
  • Page 9 9. Select Automatic to have the router automatically detect your 3G WAN settings. Click have applied during the wizard (Network ID, Wireless Security, LAN IP). Next to continue. 10. Enter the Network ID (SSID) you would like to assign to the router. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 10: Wireless Networking And Security

    Setting up wireless security is very important. Leaving your wireless network open and connection speeds. TRENDnet recommends setting your router to this encryption unsecure could expose your entire network and personal files to outsiders. TRENDnet standard. If you find that one of your wireless network devices does not support recommends reading through this entire section and setting up wireless security on your WPA2 encryption, then set your router to either WPA or WPA-Auto encryption.

  • Page 11: Secure Your Wireless Network

    When selecting WPA-Auto security, it is recommended to use AES. secure than Shared Key. o When selecting WPA2 security, it is recommended to use AES. • Encryption: Select WEP • Mode – Choose HEX or ASCII. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 12: Connect Wireless Devices To Your Router

    LED on your router WPS button will flash indicating that the WPS setup process has been activated on your router. (See “Product Hardware Features” on page 4) For connecting additional WPS supported devices, repeat this process for each additional device. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 13: Basic Wireless Settings

    1. Log into your router management page (see “Access your router management page” on page 18). 2. Click on Basic Settings, Wireless, and click on WPS Setup in the bottom. © Copyright 2012 TRENDnet. All Rights Reserved.
  • Page 14 Auto, then click the drop-down list and select the desired Channel for wireless communication. The goal is to select the Channel that is least used by neighboring wireless networks. • Wirless Mode: Select the appropriate mode for your network. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 15: Steps To Improve Wireless Connectivity

    • C or A: Select which rule you would like to apply on the applied MAC address. standard, the performance of the entire wireless network may be slower. If you are still experiencing low or no signal consider repositioning the wireless devices or installing additional access points. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 16: Domain Filters

    • Domain Suffix: A suffix of URL can be restricted, for example, ".com", "xxx.com". websites (e.g. www.trendnet.com, etc.), also called domains or URLs (Uniform Resource • Action: Select the action you would like to apply when someone is accessing the Locators).

  • Page 17: Packet Outbound/Inbound Filters

    Internet. Firewall rules may allow for more granular control of local network to apply the filter. (e.g. 192.168.10.101) specific inbound and outbound access between your network and the Internet. It is © Copyright 2012 TRENDnet. All Rights Reserved.
  • Page 18 To save changes, click Save at the bottom of the page. Next to Inbound Packet Filter, check the Enable option to enable inbound filtering. Note: If you would like to discard the changes, click Undo before you click Save. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 19: Change Your Router Login Password

    2. Click on Advanced Setting, and click on System Time. 3. Review the system time settings and click Save to apply settings. Next to Time Zone, click the drop-down list to select your Time Zone. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 20: Manually Configure Your Internet Connection

    3. In the WAN Type drop-down list, click the type of Internet connection provided by your Internet Service Provider (ISP). 4. Select Manual in the Dial-Up Profile section. 5. Complete the optional settings only if required by your ISP. 6. To save changes, click Apply. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 21: Change Your Router Ip Address

    IP address will use the following format using your new router IP address computer or device will renew the IP address lease with the DHCP server, http://(new.router.ipaddress.here) to access your router management page. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 22: Set Up Dhcp Reservation

    3. Review the DHCP reservation settings. connections through your router as they are needed. 1. Log into your router management page (see “Access your router management page” on page 18). © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 23: Enable/Disable Dos (Denial Of Service) Prevention

    IP Camera and other devices on your local area network. Note: First, you will need to sign up for one of the DDNS service providers listed in the Server Address drop-down list. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 24: Allow Remote Access To Your Router Management Page

    The DMZ feature is an easy way of allowing access from the Internet however, it is a very insecure technology and will open local area network to greater threats from Internet attacks. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 25: Virtual Server

    An example would be forwarding a port to an IP camera (TRENDnet IP cameras default to HTTP TCP port 80 for remote access web requests) on • Server IP: Enter the IP address of the device to forward the port (e.g.

  • Page 26: Special Applications

    Example: To forward TCP port 80 to your IP camera 1. Setup DynDNS service (See DynDNS section). 2. Access TRENDnet IP Camera management page and forward Port 80 (see product documentation) 3. Make sure to configure your network/IP camera to use a static IP address or you can use the DHCP reservation feature (see “Set up DHCP...

  • Page 27: Prioritize Traffic Using Qos (Quality Of Service)

    • Remote IP : Ports – The IP address and port of the remote device on destination on 4. Click Save at the bottom of the page. the Internet. (Port range to use: 1-65535) © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 28: Router Maintenance & Monitoring

    9. Apply the schedule to one of the applicable features (Wireless, Virtual Server, Packet Filters, or QoS) in the drop-down list option Use Rule#. Note: The feature will be activated during the time period specified in the schedule and deactivated during the time period not specified. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 29: Router Default Settings

    To backup your router configuration: 1. Log into your router management page (see “Access your router management page” on page 18). 2. Click on Toolbox and click on Backup Setting. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 30: Upgrade Your Router Firmware

    Toolbox > Firmware Upgrade TRENDnet may periodically release firmware upgrades that may add features or fix problems associated with your TRENDnet router model and version. To check if there is a firmware upgrade available for your device, please check your TRENDnet model and version using the link.

  • Page 31: Check Connectivity Using The Router Management Page

    18). 2. Click on Toolbox and click on Miscellaneous. 2. Click on Status and click on Device Information. 3. Enter in the IP address (e.g. 192.168.10.101) or host name (e.g. www.trendnet.com) 3. Review the device information. to test.

  • Page 32: View Your Router Log

    “Set your router date and time” on • Channel: Displays the current wireless channel your router is operating. page 18) • Security: Displays the current wireless security configured on your router. • Log: Displays the log message. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 33: View Wireless Devices Connected To Your Router

    • Page: (Active Session Number: ) - Displays the current session page you are viewing and number of active sessions. 1. Log into your router management page (see “Access your router management page” on page 18). 2. Click on Status and click on Client List. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 34: Configure Your Router Log

    Enable option. • SMTP Server : port – Enter the IP address (e.g. 10.10.10.10) or domain name (e.g. mail.trendnet.com) of your e-mail server. Enter the port used by your e-mail 3. Click Save to save the changes.

  • Page 35: Enable Snmp On Your Router

    In order to communicate between the two separate networks, routing needs to be configured. Below is an example diagram where routing is needed for devices and computers on your network to access the other network. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 36: Enable Dynamic Routing On Your Router

    RIP version 2 protocol. 4. To save changes, click Save at the bottom of the page. Note: If you would like to discard the changes, click Undo before you click Save. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 37: Router Management Page Structure

    Miscellaneous • Reboot • Miscellaneous UPnP Ping Test Security Setting • Status • Packet Filter • Domain Filter • URL Blocking • MAC Control • Miscellaneous Administrator Time-Out Remote Administrator Discard WAN Ping © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 38: Technical Specifications

    Power Adapter Output: 5V DC, 1.2A Power Consumption 350mA (max.) Dimension (L x W x H) 93 x 65 x 19.5 mm (3.66 x 2.56 x 0.77 in) Weight 66 g (2.3 oz) © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 39: Troubleshooting

    Click Internet Protocol (TCP/IP) and click Properties. d. Then click Obtain an IP address automatically and click OK. Note: If you are experiencing difficulties, please contact your computer or operating system manufacturer for assistance. © Copyright 2012 TRENDnet. All Rights Reserved.

  • Page 40: Appendix

    2. In the Network Preference window, next to "Show:", select Network Status. You'll see select the TCP/IP tab. your network status and your IP address settings displayed. In MAC OS 10.5/10.6, in the left column, select Ethernet. e. Configure TCP/IP to use DHCP. © Copyright 2012 TRENDnet. All Rights Reserved.
  • Page 41 3. You may be prompted to enter a security key in order to connect to the network. 4. Enter in the security key corresponding to the wireless network, and click Connect. © Copyright 2012 TRENDnet. All Rights Reserved.
  • Page 42 Download section limited to, duty, tax, and other fees. and look for the desired TRENDnet product to access to the GPL Code or LGPL Code. These codes are distributed WITHOUT WARRANTY and are subject to the copyrights of WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE AS the developers.
