Technical Specifications

Supported Cameras
• Supports all D-Link network cameras.
Includes support for auto-discovery, and up
to 3 megapixel resolution.
Recording Performance
• Max. capacity (NVR mode only):
• H.264 1080P (bitrate): 90 Mbps
• H.264 720P (bitrate): 90 Mbps
• MJPEG 1080P (frame rate): 90 fps
• MJPEG 720P (frame rate): 192 fps
• Max. capacity (NVR+File Server mode):
• H.264 1080P (bitrate): 68 Mbps
• H.264 720P (bitrate): 68 Mbps
• MJPEG 1080P (frame rate): 70 fps
• MJPEG 720P (frame rate): 150 fps
Camera Search
• UPnP
Audio & Video Recording
• Synchronized audio & video recording
Compression Format
• H.264, MPEG-4, M-JPEG (for supported
cameras)
Video Settings
• Resolution, quality, frame rate, enable
audio, go to camera interface
Recording Type
• Record by schedule, manual, and event-
based recording
• Motion-triggered recording
Remote Live View
• Supported via IE Explorer
(Max. 9 simultaneous channels)
• Supports mydlink portal
(Max. 1 simultaneous channel)
1 Amount of storage is dependent on number of cameras, resolution and frame rate.
Hard drive(s) is not included. An internal 3.5" SATA 2.0 drive is required to store or share files and must be formatted before use. RAID 0 and RAID 1 require the use of two (2) SATA drives. To avoid drive incompatibility in RAID 0 or RAID 1 operation,
2
use SATA drives from the same manufacturer. Formatted drive capacity for RAID 1 operation is dependent on the drive capacity of the lower-sized drive. May not work with older generation SATA drives. For a list of SATA drives that have been
tested to work with the DNR-322L visit your D-Link office website.
3 Only for cameras with PTZ functionality
Computer must adhere to Microsoft's recommended system requirements.
4
5 Please visit the D-Link website for an updated list of supported cameras.
1-Year Limited Warranty available only in the USA and Canada.
6
U.S.A. | 17595 Mt. Herrmann Street | Fountain Valley, CA 92708 | 800.326.1688 | dlink.com
©2012 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, the D-Link logo, mydlink, ShareCenter, the D-Link RoHS logo and trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States and/or
other countries. Other trademarks or registered trademarks are the property of their respective owners. Visit www.dlink.com for more details.
Updated 10/11/12
DNR-322L
Remote Live View Control
• Live view, preset/go, patrol, focus,
PTZ functions, snapshot, full screen,
digital zoom, e-map, multiple view
(1/4/6/9/16/25/36/48) with duplicated
carrier
Remote Playback
• Supported via IE and NVR client
• Playback system with timeline GUI, search
by event, area, cameras, date and time
• Internet Explorer and NVR client support
1-channel playback
• Digital zoom
Overwrite Recording
• Auto recycling when disk storage is full
File Export
• Export videos to AVI or ASF file
• Export images to BMP or JPG file
User Account
• Additional accounts can be created to
allow user access to the system, and specify
authorization for camera channels, PTZ, etc
System Time
• Set the system time (D-Link NTP, input time,
sync with computer, Daylight Saving Time)
DDNS
• D-Link DDNS server support
Remote Backup
• Remote software can backup raw data to
redundant storage
• Auto backup of previous day's video to FTP
server
System Status
• Camera status, System status
• Still picture EMAP support
mydlink™ Network Video Recorder
Network Service Protocols
• IPV4, ARP, TCP, UDP, ICMP
• DHCP Client
• NTP Client (D-Link)
• DNS Client
• DDNS Client (D-Link)
• SMTP Client
• HTTP Server
• PPPoE
• UPnP
• IP filtering
User Interface
• IEEE 802.3/u/z
• Auto MDI/MDI-X
• SATA I, II
Hard Disk
1
• Hard Disk control & management via PC
• Reformat Disk
• RAID 0
2
• RAID 1
2
• JBOD
Two Reset Modes
• Reset firmware GUI button
• HW reset button (hold for 5 seconds)
Flash Rom
• 128 MB
RAM
• 256 MB DDR II

Network Interface

• Gigabit Ethernet LAN port
(10/100/1000 Mbps)
I/O ports
• RJ45 port
• DC-in jack
• USB port for UPS status update (optional)
Power Adapter
• DC 12V/4 A
Power Consumption
• Max. power consumption: 25.20 W
• Standby state max. power consumption:
0.23 W
Dimension (w x d x H)
• 4.53 x 5.76 x 7.03 inches
(115 x 146.4 x 178.5 mm)
Weight
• 0.875 kg (1.93 lbs)
Operating Temperature
• 0˚ to 55˚ C (32˚ to 131˚ F)
Storage Temperature
• Operating: 5% to 90% (non-condensing)
Certifications
• CE
• FCC
• RoHS
