Lightolier Lytecaster 1132T Specification

Page 1 of 2
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim
1132T
White
Features
1. Reflector: Hydroformed aluminum, 18 ga.; white gloss finish on inside and
trim flange.
2. Cross Blade: Die-cast aluminum baffle with powder paint, gloss white
finish.
3. Frame-In Kit: (1102T1 standard frame shown; other frames listed above.)
See 1102T specification sheet for more details.
Options & Accessories
Retaining Clips: 1955 - For installing in existing ceilings.
Extra Wide Flange Trim Ring: 1954 - 8-5/8" O.D.
Plaster Ceiling Ring: 1961 - 7/8" depth for wet plaster ceilings.
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • C1109
Lytecaster
6 3/4" Aperture Cross Blade Low Profile 2 Lt. Reflector Trim
1132T/1102T1 Series
Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Frame-In Kit Ceiling Type
1102T1 Non-IC
1102TH1 Non-IC
1102TH2 Non-IC
1102TM1
Non-IC Emergency
1102TM2 Non-IC Emergency
1102TH1R Non-IC Remodeler
1102T13U Non-IC
1102T18U
Non-IC
1102T26U Non-IC
Recessed Downlighting
®
Fluorescent
Lamping Height
(2) 13W Twin Tube 3 7/8"
Compact Fluorescent 3 7/8"
(2 Pin) 3 7/8"
3 7/8"
3 7/8"
3 7/8"
(2) Lamp 13W Quad Tube 3 7/8"
Compact Fluorescent
(G24q-1) 4 Pin Base
(2) 18W Quad Tube 3 7/8"
Compact Fluorescent
(G24q-2) 4 Pin Base
(2) 26W Quad Tube 3 7/8"
Compact Fluorescent
(G24q-3) 4 Pin Base
Labels
UL (Suitable for Damp Locations and wall), I.B.E.W.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
1132T
Type:
