Lightolier Lytespan DRL70 Specification

Page 1 of 2
Ordering Information
Catalog No. Finishes
dr2Ls70wh White
dr2Ls70bk
Black
dr2Ls70sL Silver
description
Remote controlled spotlight that can be mounted anywhere along the track
and remotely aimed through the use of a hand-held controller. Can not be
dimmed. Can not turn on/off using hand-held controller.
Features
1. Full remote control of pan and tilt movement to aim at any object below
the luminaire.
2. Positions can be recorded for future use.
3. Continuous movement and sequencing option.
4. Interchangeable Click-On™ reflectors to achieve desired beam spread.
REFLECTORS SOLD SEPARATELy.
5. Die-cast aluminum housing.
Electrical
Electronic Ballast
Input Voltage: 120V, 60 Hz
Power Factor: >95%
Input Power: 78W
Max. Input Current: .67A
Total harmonic distortion: <10%
ANsI Code: M139, M143, M98
Do not use on a dimming circuit.
Lytespan
7 1/2"
(190)
12 13/16"
(325)
Track Mounting
Compatible with Lytespan Basic, Radius
and Advent Track Systems; and all
Multipoint and Monopoints.
DO NOT USE with Extension Wands,
Sloped Ceiling Adapter or ProSpec Track.
Track Lighting System
®
2 13/32"
5 1/4"
(133)
Lamp
T6 Single Ended, G12 Base
Ceramic Metal Halide 70W
Labels
cULus Classified
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • B0507
drL70
Director Metal Halide 70W T6
®
Requires Laser
Remote Control
for Operation
(61)
reflectors
Use one of:
DRT6RS
DRT6RM
DRT6RF
SOLD SEPARATELy
Type:
www.lightolier.com
