Clarke FOCUS L17 Operator's Manual
Hide thumbs
Also See for FOCUS L17:
- Operator's manual (142 pages) ,
- Operation manual (6 pages) ,
- Service manual (60 pages)
Table of Contents
Advertisement
Available languages
Available languages
Order Parts Here:
www.ivie-ent.com/parts
Ph:(918)254-5161
U.S. Patent No. 6,105,192; No. 6,557,207; No. 6,760,947 and other Patents Pending
READ THIS BOOK
LEA ESTE MANUAL
LISEZ CE MANUEL
This book has important information for the use and safe operation of this machine. Failure to read this
book prior to operating or attempting any service or maintenance procedure to your Clarke machine
could result in injury to you or to other personnel; damage to the machine or to other property could occur
as well. You must have training in the operation of this machine before using it. If your operator(s) cannot
read this manual, have it explained fully before attempting to operate this machine.
All directions given in this book are as seen from the operator's position at the rear of the machine.
For new books write to: Clarke
Form No. 70899A
4/06
S17/L17 Rotary
L17 Cylindrical
S20/L20 Rotary
Operator's Manual
Manuel d'utilisation
Libro de Instrucciones
®
, 2100 Highway 265, Springdale, Arkansas 72764.
Clarke
EN
English (2 - 27)
ES
Español (28 - 53)
FR
Français (54 - 79)
®
Printed in the U.S.A.
Advertisement
Chapters
Table of Contents
Related Manuals for Clarke FOCUS L17
Summary of Contents for Clarke FOCUS L17
- Page 1 This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your Clarke machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well.
-
Page 2: Table Of Contents
Brush Motor Assembly and Parts List ......................103 Transaxle Repair Parts ............................ 104 FOCUS S17/S20 Connection Diagram ......................105 FOCUS S17/S20 Electrical Schematic ......................106 FOCUS L17/L20 Connection Diagram ......................107 FOCUS L17/L20 Electrical Schematic ......................108 Page Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 3: Operator Safety Instructions
Failure to read the Operator's Manual prior to operating or attempting any service or maintenance procedure to your Clarke machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well. -
Page 4: Machine Introduction
Do not use this machine as a step or furniture. Do not ride on this machine. CAUTION: Your machine warranty will be voided if anything other than genuine Clarke parts are used on your machine. Always use Clarke parts for replacement. - Page 5 Shipping Weight w/Batteries (130AH) 487 lbs. (221 kg) Line of Sight -Operator Height = 5'8" 7.5 feet (2.3 m) Warranty Machine 3 Years, Polydur tanks 8 Years, Batteries 18 Months Pro-rated ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -5-...
-
Page 6: Machine Specifications
454 lbs. (206 kg) 472 lbs. (214 kg) Line of Sight (Operator Height = 5'8") 7.5 feet (2.3 m) Warranty Machine 3 Years, Polydur tanks 8 Years, Batteries 18 Months Pro-rated Page Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 7: Procedures For Transporting Machine
2. Make sure the ramp is clean and dry. 3. Put the ramp in position. 4. Remove squeegee assembly, brush housing and brush or pad driver before loading. Clarke recommends that both the solution tank and recovery tank are empty before loading. - Page 8 Procedures For Transporting (cont.) 11. Fasten the machine to the vehicle. Clarke recommends a strap over the top of the machine and a strap to keep the machine from rolling forward or backwards. If this is not done, there is a possibility of the machine toppling over.
-
Page 9: Symbols Used On Machine
SYMBOLS USED ON FOCUS S17/S20 & L17/L20 Warning Solution Control Power Brush Up/Down Traverse Speed Control ("L Class" only) Vacuum/Squeegee Control Battery Meter AC Power Indicator ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -9-... -
Page 10: Machine Control Panel
When powering up the machine, wise.) the solution setting will automatically adjust to the mid setting (see your authorized Clarke serviceman if a NOTE: The "L model" machine is equipped with self different setting is preferred). To increase the flow, press diagnostics and will sometimes fail to operate if a fault and hold or press the upper button (+) multiple times. -
Page 11: Machine Controls And Features
The brake is located to the right hand rear of the machine. Press pedal to activate brake and lift pedal to disengage brake. Figure 6 ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -11-... -
Page 12: How To Prepare The Machine For Operation
Figure 9 8. While pushing the tank to the rear, carefully lift and remove recovery tank from the machine. Leave the recovery drain hose attached to the recovery tank. Figure 10 Page -12- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... - Page 13 (See figure 13B). 15. Reconnect the blue float connector (See figure 9, page 12). 16. Charge the batteries before using the machine. Figure 13B ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -13-...
-
Page 14: Battery Maintenance
Place your hand behind flange and open the valve. e. When empty, close valve. f. Replace valve and drain hose on top of transaxle. g. Neutralize any acid spills with ammonia or bicarbonate of soda. Page -14- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 15: How To Charge The Batteries
Figure 17). During this stage the charger is supplying its full amp output to the batteries. It will continue to charge the batteries at this rate until the batteries reach approximately 75% of their capacity. ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -15-... -
Page 16: How To Install A Rotary Brush Or Pad Driver
Operating a machine that is not completely or fully assembled could result in injury or property damage. Do not operate this machine unless it is completely assembled. Inspect the machine carefully before operation. Page -16- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 17: How To Remove A Rotary Brush Or Pad Driver
DANGER: Operating a machine that is not completely or fully assembled could result in injury or property damage. Do not operate this machine unless it is completely assembled. Inspect the machine carefully before operation. Figure 24 ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -17-... -
Page 18: How To Operate The Machine
Use only a commercially Figure 26 available cleaners and concentrations intended for floor scrubbing applications. WARNING: Clarke recommends a maximum water temperature of 120 F (49 Operating The Machine NOTE: Put the machine in the lowest traverse speed setting. Use the machine in an area that has no furniture or objects until you can do the following: 1. -
Page 19: How To Clean A Dirty Floor
NOTE: Keep the machine moving when the brush is rotating on the floor. Pre-wet brush/pad or keep light pressure on brush until solution flow is adequate to keep brush/pad from scratching the floor. ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -19-... -
Page 20: Maintenance
Make sure the screen filter is installed properly in the recovery lid and is clean (See figure 30). Make sure the recovery tank lid is on correctly (See Figure 30 Figure 30). Page -20- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 21: Procedures To Perform At The End Of Work
If the squeegee blade is damaged or worn, turn or replace the blade. 6. Check and clean the recovery lid gasket. Use a mild cleaning solution and rinse the parts in clean water. Figure 34 ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -21-... -
Page 22: Procedures To Perform Every Week
Wipe any acid from the machine or the tops of the batteries. Do not add acid to battery after installation. Page -22- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... - Page 23 Pry on the motor close to where the motor contacts the brush head casting (See Figure 36, A). d. Hold tension and tighten 2 screws (See Figure 36,B). e. Replace belt cover. ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -23-...
-
Page 24: Maintenance For The Squeegee
. WARNING: Electrical repairs must be done by authorized personnel only. REAR BLADE 0.06 (1.5 mm) Consult your Clarke Authorized Service Person to do Figure 39 the service procedures. Use only genuine Clarke parts. Page -24- Clarke ®... -
Page 25: Accessories
Clarke FOCUS 17/20 Accessories CCESSORIES Description Part No. Clarke Care Kit 14607A 29" Squeegee Assembly 18820A 32" Squeegee Assembly 10129A Poly Dur Protectant 50478A Hour Meter Kit 10656A Key Switch Kit 10490A Parking Brake Kit 10491A Vacuum Muffler Kit 10492A... -
Page 26: How To Correct Problems In The Machine
Have an authorized service person repair the charger. The battery is defective. Check voltage of each cell while discharging. The batteries are disconnected. Connect the batteries. Brush is in heavy scrub setting. Adjust Pressure. Page -26- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... - Page 27 Turn key or switch on. Batteries are disconnected. Check the battery connections. Battery terminals are dirty. Batteries are discharged Check battery meter and recharge NOTE: If the problem continues consult an authorized service person. ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -27-...
- Page 28 Todas las indicaciones de dirección dadas en este libro están dadas desde la posición del operador en la parte detrás de la máquina. Ud puede. conseguir libros suplementarios dirigiéndose al distribuidor Clarke de su zona. ® Page...
-
Page 29: Instrucciones De Seguridad Para El Operador
Al parar la máquina, compruebe que todos los mandos están en la la posición “OFF”. En los modelos L17 pulse el interruptor en "OFF" (APAGADO) y saque la llave. ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -29-... -
Page 30: Introducción A La Máquina
Introducción y características técnicas Las autolavadoras de pisos Focus S17/S20 y L17/L20 de Clarke son eficientes y de calidad superior. El artefacto Focus usa un cepillo (rotativo) para lavar un ancho de piso de 17 pulgadaso y 20 pulgadaso o 2 cepillos (cilíndricos) para lavar un ancho de piso de 17 pulgadas. -
Page 31: Especificaciones De La Máquina
487 libras (221 kg) Línea de visión - Altura del operador = 5'8" 7.5 pies (2.3 m) Warranty Máquina 3 años, tanques de Polydur 8 Años, Baterías 18 meses en forma prorrateada ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -31-... - Page 32 472 libras (214 kg) Línea de visión (Altura del operador =5'8") 7.5 pies (2.3 m) Garantía de funcionamiento Máquina 3 años, tanques de Polydur 8 Años, Baterías 18 meses en forma prorrateada ® Page -32- Clarke Operator's Manual -FOCUS S17/L17 and S20/L20...
-
Page 33: Transporte De La Máquina
3. Coloque la rampa. 4. Quite el conjunto de la bayeta, la placa de protección del cepillo y el cepillo o el portadisco antes de la carga. Clarke recomienda vaciar tanto el depósito de solución como el de recuperación antes de la carga. - Page 34 TRANSPORTE DE LA MÁQUINA 11. Estibe la máquina en el vehículo. Clarke recomienda poner una correa alrededor de la parte superior de la máquina y otra para impedir que la máquina se resbale hacia adelante o hacia atrás. En caso contrario, la máquina podría...
-
Page 35: Símbolos Empleados En La Máquina
SÍMBOLOS UTILIZADOS EN FOCUS S17/S20 y L17/L20 Aviso Control de la solución Alimentación Cepillo arriba/abajo Control de la velocidad de marcha ("Clase L") Control de la escobilla de goma/aspiración Medidor de baterías Indicador de CA ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -35-... -
Page 36: Panel De Control De La Máquina
(consulte a su funcionar si se detecta una falla. Una vez corregida la agente de reparaciones autorizado por Clarke en caso de falla, la máquina puede ser reiniciada girando el preferir una configuración diferente). Para aumentar el flujo, interruptor de energía a la posición "OFF"... -
Page 37: Mandos Y Características De La Máquina
El freno está ubicado en la parte posterior derecha de la máquina. Presione el pedal para activar el freno y levante el pedal para liberarlo. Figura 6 ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -37-... -
Page 38: Preparación De La Máquina Para Trabajar
8. Mientras empuja el depósito hacia atrás, levante con cuidado y retire el depósito de recuperación de la máquina. Deje la manguera de drenaje de recuperación adosada al depósito de recuperación. Figura 9B ® Page -38- Clarke Operator's Manual -FOCUS S17/L17 and S20/L20... - Page 39 (Refiérase a la Figura 13B). 15. Vuelva a conectar el conector azul del flotador (Refiérase a la figura 10A, página 12). 16. Cargue las baterías antes de usar la máquina. Figura 13B ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -39-...
-
Page 40: Mantenimiento De La Batería
Cuando esté vacía, cierre la válvula. Sustituya la válvula y el tubo de drenaje de la parte superior del eje transversal. Neutralice todos los restos de ácido con amoniaco o bicarbonato de sosa. ® Page -40- Clarke Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 41: Procedimiento De Carga De Las Baterías
(Refiérase a la Figura 17). Durante esta etapa el cargador suministra el máximo amperaje a las baterías y continúa la carga a ese régimen hasta alcanzar aproximadamente el 75% de la capacidad de las baterías. ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -41-... -
Page 42: Modo De Instalación Del Accionamiento De Disco O Cepillo Rotativo
No opere la máquina antes de que esté completamente montada. Compruebe cuidadosamente el estado de la máquina antes de cada utilización. ® Page -42- Clarke Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 43: Modo De Remoción Del Accionamiento De Disco O Cepillo Rotativo
No opere la máquina antes de que esté Figura 24 completamente montada. Compruebe cuidadosamente el estado de la máquina antes de cada utilización. ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -43-... -
Page 44: Puesta En Marcha De La Máquina
¡AVISO!: Clarke aconseja una tempe-ratura máxima del agua de 120°F (49°C). Puesta en marcha de la máquina NOTA: Ajuste la velocidad de la máquina en la velocidad mínima. -
Page 45: Cómo Limpiar Un Suleo Muy Sucio
® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -45-... -
Page 46: Mantenimiento
5. Aspire toda el agua sucia. MANTENIMIENTO ¡AVISO!: Las reparaciones y operaciones de mantenimiento deben ser hechas siempre por técnicos autorizados Clarke. ¡AVISO!: Vacíe siempre los dos depósitos (solución y recuperación) antes de empezar un mantenimiento o una reparación. ¡AVISO!: Todas la fijaciones deben estar bien apretadas. -
Page 47: Procedimientos A Realizar Al Acabar El Trabajo
Controle y limpie la empaquetadura de la tapa de Figura 34 recuperación. Use una solución de limpieza suave y enjuague las partes con agua limpia. ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -47-... -
Page 48: Procedimientos A Realizar Cada Semana
Enjugue todo rebosamiento de ácido en la máquina o las baterías. No añada nunca ácido en las baterías después de su colocación. ® Page -48- Clarke Operator's Manual -FOCUS S17/L17 and S20/L20... - Page 49 (ver figura 36, A). d. Mantenga la tensión y apriete los 2 tornillos (ver figura 36, B). e. Vuelva a colocar la tapa de la correa. ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -49-...
-
Page 50: Mantenimiento De La Bayeta
¡AVISO!: Las reparaciones eléctricas deben LAMINA TRASERA 0.06 (1.5 mm) siempre efectuarse por técnicos autorizados. Figura 39 Se ruega dirigirse a un técnico autorizado de Clarke para efectuar las operaciones de mantenimiento. Sólo utilice recambios originales Clarke. ® Page -50-... -
Page 51: Accesorios
Clarke Focus 17 y 20 Accesorios CCESORIOS Descripción N° Pieza Juego de mantenimiento Clarke 14607A Conjunto de la bayeta de 29" 18820A Conjunto de la bayeta de 32" 10129A Producto de protección para el Polidur 50478A Juego del horómetro 10656A... -
Page 52: Solución De Los Problemas De La Máquina
Las baterías están defectuosas Compruebe la tensión de cada célula en descarga Las baterías están desconectadas Conecte las baterías El cepillo está permanentemente en Ajuste la presión posición de fregado (‘’heavy scrub’’) ® Page -52- Clarke Operator's Manual -FOCUS S17/L17 and S20/L20... - Page 53 Los bornes de las baterías están sucios Compruebe el indicador de las baterías y Las baterías están descargadas cárguelas de nuevo NOTA: si el problema persiste, acuda a un técnico cualificado para comprobar la máquina. ® Clarke Operator's Manual -FOCUS S17/L17 and S20/L20 Page -53-...
- Page 54 à utiliser cette machine. Toutes les indications de direction figurant dans ce manuel sont visualisées depuis la position de l'opérateur, à l'arrière de la machine. Pour toute commande de manuels, adressez-vous à votre revendeur Clarke. Page -54- Clarke ®...
-
Page 55: Instructions Pour La Sécurité De L'opérateur
"O". Sur les modèles L17, tournez l'interrupteur à clé sur « OFF » et retirez la clé. Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 56: Présentation De La Machine
AVERTISSEMENT : Seul du personnel qualifié, agréé par Clarke, a le droit d'effectuer les réparations et l'entretien de nos machines. L'entretien et les réparations doivent être réalisés par un membre autorisé du personnel uniquement. AVERTISSEMENT : Toute modification ou changement apportés à cette machine peuvent l'endommager ou blesser l'opérateur ou d'autres personnes se trouvant à... -
Page 57: Spécifications De La Machine
Poids embarqué avec batteries (130AH) 221 kg Ligne de visée (Hauteur de l'opérateur = 1,73 m) 7.5 feet (2.3 m) Garantie Machine 3 ans, réservoirs Polydur 8 ans, batteries 18 mois au prorata Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20 Page -57-... - Page 58 Poids embarqué avec batteries (130AH) 206 kg 156.5 kg Ligne de visée (Hauteur de l'opérateur = 1,73 m) 2.3 m Garantie Machine 3 ans, réservoirs Polydur 8 ans, batteries 18 mois au prorata Page -58- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20...
-
Page 59: Transport De La Machine
9. Pour les modèles S17/S20 : guidez la machine sur la rampe en marche arrière. 10. Mettez la machine sur « OFF », et sur les modèles L17/L20, tournez l'interrupteur à clé sur « OFF ». Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20 Page -59-... -
Page 60: Symboles Utilisés Pour La Machine
Transport de la machine 11. Arrimez la machine au véhicule Clarke Technology recommande de placer une courroie autour de la partie supérieure de la machine et une autre pour empêcher la machine de glisser vers l'avant ou vers l'arrière. Sinon, la machine risquerait de basculer. - Page 61 SYMBOLES UTILISÉS POUR S17 et L17 Avertissement Commande de la solution Alimentation électrique Position haute/basse de la brosse Commande de la vitesse de traction (Classe L) Contrôle Aspirateur/Racle Niveau de la batterie Indicateur d'alimentation CA Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20 Page -61-...
-
Page 62: Commandes
(consultez clé, l'alimentation peut également être éteinte en tournant la clé votre ingénieur agréé Clarke si un différent réglage est souhaité). dans le sens inverse des aiguilles d'une montre.) Pour augmenter le flux, appuyez sur le bouton supérieur (+) et tenez-le appuyé, ou appuyez sur lui plusieurs fois. - Page 63 Le frein est placé sur la droite, à l'arrière de la ma- chine. Appuyez sur la pédale pour activer le frein et soulevez la pédale pour désengager. Figure 6 Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20 Page -63-...
-
Page 64: Préparation De La Machine Avant La Mise En Service
8. Lorsque vous poussez le réservoir vers l'arrière, soulevez et retriez avec précaution le réservoir de récupération de la machine. Laissez le tuyau d'évacuation de la récupération fixé au réservoir de récupération. Figure 10 Page -64- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... - Page 65 (Voir Figure 13B). 15. Reconnectez le connecteur bleu de flottaison (Voir figure 9, page 12). 16. Chargez les batteries avant d'utiliser la machine. Figure 13B Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20 Page -65-...
-
Page 66: Entretien Des Batteries
Lorsque la vidange est terminée, refermez la vanne. f. Replacez la vanne et le flexible sous la boîte-pont. g. Neutralisez soigneusement tout débordement d'acide à l'ammoniaque ou au bicarbonate de soude. Page -66- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 67: Charge Des Batteries
(Voir Figure 18). Pendant cette étape, le chargeur fournit sa puissance ampère totale aux batteries. Il continuera à charger les batter- ies à ce taux jusqu'à ce qu'elles atteignent environ 75% de leur capacité. Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20 Page -67-... -
Page 68: Comment Installer Une Brosse Rotative Ou Un Porte-Disque
Ne mettez pas la machine en service avant qu'elle ne soit complètement montée. Vérifiez soigneusement l'état de la machine avant chaque utilisation. Page -68- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 69: Comment Retirer Une Brosse Rotative Ou Un Porte-Disque
Ne mettez pas la machine en service avant qu'elle ne soit complètement montée. Vérifiez soigneusement l'état Figure 24 de la machine avant chaque utilisation. Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20 Page -69-... -
Page 70: Mise En Service
à des applications de récurage de sols. AVERTISSEMENT : Clarke recommande de ne pas utiliser une eau dont la temperature dépasse 49 ºC. Fonctionnement de la machine REMARQUE: Réglez la machine sur la vitesse minimale. -
Page 71: Conseils Pour Le Nettoyage
Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20 Page -71-... -
Page 72: Entretien
Assurez-vous que le filtre de l'écran est correctement installé dans le couvercle de récupération et qu'il est propre (Voir Figure 30). Compruebe que la tapa del depósito de recuperación está correctamente colocada (voir figure 30). Figure 30 Page -72- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 73: Tâches De Fin De Travail
6. Vérifiez et nettoyez le joint du couvercle du réservoir de solution. Utilisez une solution à faible concentration de détergent et rincez les pièces à l'eau claire. Figure 34 Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20 Page -73-... -
Page 74: Tâches Hebdomadaires
Essuyez tout débordement d'acide sur la machine ou les batteries. Ne jamais ajouter d'acide dans les batteries après qu'elles aient été installées Page -74- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... - Page 75 (voir figure 36, A). d. Maintenez la tension et resserrez les deux vis (voir figure 36, B). e. Replacez la protection de la courroie. Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20 Page -75-...
-
Page 76: Entretien Du Suceur
AVERTISSEMENT: Les reparations électriques doivent toujours être effectuées par des techniciens agréés. 0.06 (1.5 mm) LAMIE ARRIÈRE Consultez votre technicien agréé Clarke pour faire effectuer les opérations d'entretien. Figure 39 N'utilisez que des pièces Clarke. Page -76- Clarke ®... -
Page 77: Accessoires
Clarke Focus 17/20 Accessoires CCESSORIES Descripción Part No. Kit d'entretien Clarke 14607A Ensemble du suceur (29 pouces) 18820A Ensemble du suceur (32 pouces) 10129A Produit de protection pour le Polydur 50478A Kit de l'horamètre 10656A Interrupteur à clé 10490A Frein de sécurité... -
Page 78: Problèmes Et Solutions Proposées
Vérifiez la tension de chaque cellule en décharge. Les batteries sont déconnectées. Connectez les batteries. La brosse est réglée en permanence sur Réglez la pression. récurage (" heavy scrub "). Page -78- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... - Page 79 Les bornes des batteries sont encrassées. Les batteries sont déchargées. Vérifiez l'indicateur de la batterie et rechargez les. REMARQUE: si le problème persiste, faites vérifier la machine par un technicien agréé. Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20 Page -79-...
- Page 80 SECTION II NOTES Page -80- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20...
- Page 81 SECTION II S17/L17 Rotary S17/L17 Cylindrical S20/L20 Rotary Section II Parts and Service Manual (70899A) U.S. Patent No. 6,105,192; No. 6,557,207; No. 6,760,947 and other Patents Pending Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20 Page -81-...
-
Page 82: Final Assembly
SECTION II ® Clarke FOCUS S17/20, L17/20 and L17 Cyl. Final Assembly 1/05 Page -82- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 83: Parts List
SECTION II ® Clarke FOCUS S17/20, L17/20 and L17 Cyl. Final Assembly Parts List 1/05 Ref. # Part No. Description Page 84 Recovery Tank Assembly 980651 Washer, Flat 5/16" 80212A Screw, M8 x 1.25 x 35mm Hex Head Page 86... -
Page 84: Recovery Tank Assembly
SECTION II Clarke ® FOCUS S17/20, L17/20 and L17 Cyl. Recovery Tank Assembly 1/05 6B 6C Page -84- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 85: Parts List
SECTION II ® Clarke FOCUS S17/20, L17/20 and L17 Cyl. Recovery Tank Parts List 1/05 Ref. # Part No. Description 80176A Screw, M5 x .8 x 12mm Pan Head 30207A Recovery Lid 30065A Lid Gasket 692409 Chain 80196A Nut, M5 x .8 Hex... -
Page 86: Solution Tank Assembly
SECTION II ® Clarke FOCUS S17/20, L17/20 and L17 Cyl. Solution Tank & Front Cover Assembly 1/05 Page -86- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 87: Parts List
SECTION II ® Clarke FOCUS S17/20, L17/20 and L17 Cyl. Solution Tank & Front Cover Parts List 1/05 Ref. # Part No. Description 80199A Nut, M6 x 1 Hex Nylock 980614 Lock Washer, 1/4" Ext. Tooth 87026A Flat Washer, 1/4"... -
Page 88: Electrical Assembly
SECTION II ® Clarke FOCUS S17/20, L17/20 and L17 Cyl. Electrical Assembly 1/05 42 43 Page -88- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 89: Parts List
SECTION II ® Clarke FOCUS S17/20, L17/20 and L17 Cyl. Electrical Parts List 1/05 Ref. # Part No. Description S17/20 L17/20 80179A Screw, M6 x 1 x 15mm, Pan Head 980614 Washer, Lock 1/4" Ext. Tooth 30097A Insulator 40635A Squeegee Switch 980607 Washer, Lock #6 Ext. -
Page 90: Control Housing Assembly
SECTION II ® Clarke FOCUS S17/20, L17/20 and L17 Cyl. Control Housing Assembly 1/05 Page -90- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 91: Parts List
SECTION II Clarke ® FOCUS S17/20, L17/20 and L17 Cyl. Control Housing Parts List 1/05 Ref. # Part No. Description S17/20 L17/20 L17 Cyl 962957 Screw, 10-16 x 1/2" 70352A Membrane Switch 60979A Control Panel 52555A Lever Gasket 60978A Wear Plate... -
Page 92: Squeegee Lift Assembly
SECTION II ® Clarke FOCUS S17/20, L17/20 and L17 Cyl. Squeegee Lift Assembly 1/05 Page -92- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 93: Parts List
SECTION II ® Clarke FOCUS S17/20, L17/20 and L17 Cyl. Squeegee Lift Parts List 1/05 Ref. # Part No. Description 80196A Nut, M5 x .8, Nylock 87036A Washer, Flat #10 61305A Tube Bracket 80199A Nut, M6 x 1, Nylock 80198A Nut, M8 x 1.25, Nylock... -
Page 94: Squeegee Assembly
SECTION II ® Clarke FOCUS S17/20, L17/20 and L17 Cyl. 32" Squeegee Assembly 1/05 Page -94- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 95: Parts List
SECTION II ® Clarke FOCUS S17/20, L17/20 and L17 Cyl. 32" Squeegee Parts List 1/05 Ref. # Part No. Description 80252A Screw, ¼-20 x 1 Hex SS 980657 Washer, ¼ Lock 60243A Bracket, Squeegee Wheel 30049B Wheel, Squeegee 81104A Nut, ¼-20... -
Page 96: Frame Assembly
SECTION II ® Clarke FOCUS S17/20, L17/20 and L17 Cyl. Frame Assembly 4/06 Page -96- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 97: Parts List
SECTION II Clarke ® FOCUS S17/20, L17/20 and L17 Cyl. Frame Parts List 4/06 Ref. # Part No. Description L17 L17 Cyl S20 80199A Nut, M6 x 1, Nylock 87026A Washer, Flat 1/4" SS 80204A Nut, M3 x .5 Nylock 30750A Spring, Spacer Urethane (.75"... -
Page 98: Cylindrical Brush Head Assembly
SECTION II ® Clarke FOCUS L17 Cylindrical Cylindrical Head Assembly 1/05 Page -98- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 99: Parts List
SECTION II ® Clarke FOCUS L17 Cylindrical Cylindrical Head Parts List 1/05 Ref. # Part No. Description 80198A Nut, M8 x 1.25 Nylock 980652 Washer, 5/16" Lock 980692 Washer, 5/16" Flat SS 80165A Shoulder Bolt, M6 x 8 x 12mm 980651 Washer, 5/16"... -
Page 100: Rotary Disk Head Assembly
SECTION II ® Clarke FOCUS S17/20 & L17/20 Rotary Rotary Disk Head Assembly 1/05 Page -100- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 101: Parts List
SECTION II ® Clarke FOCUS S17/20 & L17/20 Rotary Rotary Disk Head Parts List 1/05 Ref. # Part No. Description 41602A Housing, Connector 41601A Contact, Connector 40591A Brush Motor 20014A Motor Shim 87026A Washer, Flat 1/4" 80199A Nut, M6 x 1 Nylock... -
Page 102: Gearbox Assembly And Parts List
SECTION II Clarke ® FOCUS S17/20 & L17/20 Rotary Gearbox Assembly and Parts List 1/05 Ref # Part No. Description 57846A Ring, Snap 507641 Seal, Oil, Small 52050A Cap End 56668A O-Ring 51176A Bearing, Large 902605 Bearing, Small 58144A Seal, Oil Large Darina EP2 Grease 4 oz. -
Page 103: Brush Motor Assembly And Parts List
SECTION II ® Clarke FOCUS S17/20 & L17/20 Rotary Brush Motor Assembly and Parts List 1/05 Seam Location Item Part No. Description 56478A Stator Frame Assembly (w/Magnets & Clips) 50142A Armature Assembly (w. B.E. & F.E. Bearings) 902654 Bearings B.E. -
Page 104: Transaxle Repair Parts
SECTION II ® Clarke FOCUS L17/L20 & L17 Cylindrical Transaxle Drawing 1/05 4, 5 Item Part No. Description 10135A Wheel Flange Kit 51056A Transaxle Mounting Sleeve 40593A Motor Brush 40594A Motor Urethane Sleeve 40595A Motor 40596A Transaxle Only Specifications: - Motor: 24VDC, Permanent Magnet, Tenv - Transaxle: 30:1 Ratio - Gear Oil: Mobile SHC634 12 oz. -
Page 105: Focus S17/S20 Connection Diagram
SECTION II Clarke ® FOCUS S17/20 Connection Diagram 1/05 Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20 Page -105-... -
Page 106: Focus S17/S20 Electrical Schematic
SECTION II Clarke ® FOCUS S17/20 Electrical Schematic 1/05 Page -106- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... -
Page 107: Focus L17/L20 Connection Diagram
SECTION II ® Clarke FOCUS L17/20 Connection Diagram 1/05 Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20 Page -107-... -
Page 108: Focus L17/L20 Electrical Schematic
SECTION II Clarke ® FOCUS L17/20 Electrical Schematic 1/05 Page -108- Clarke ® Operator's Manual -FOCUS S17/L17 and S20/L20... - Page 109 ALTO Cleaning Systems (UK) Ltd., Penrith (810) 544-6300 Gilwilly Industrial Estate Penrith American Lincoln ® / Clarke, Marietta, Georgia 30066 Cumbria CA11 9BN 1455 Canton Road +44 1768 868 995 (770) 973-5225 ALTO France S.A. Strasbourg B.P. 44, 4 Place d’Ostwald...
- Page 110 STATED WARRANTIES ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED Clarke's liability under this warranty is limited to repair of the product and/or replacement of parts and is given to purchaser in lieu of all other remedies, including INCIDENTAL AND CONSEQUENTIAL DAMAGES.
