Page 1: Instruction Manual
Instruction Manual 19"/22" HD Ready LCD TV with Built-in Digital Tuner L19H01 UB/UW/CB/CW L22H01 UB/UW/CB/CW... -
Page 2: Preparation
Safety Warnings SOME DO’S AND DON’TS ON THE SAFE USE OF EQUIPMENT This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured. - Page 3 Safety Warnings Power Source an electric heater. Ensure that no open flame The TV set should be operated only from a sources, such as lighted candles, are placed 100-240V~, 50/60Hz outlet. Ensure that you on top of the TV. Batteries should not be select the correct voltage setting for your exposed to excessive heat such as sunshine, convenience.
-
Page 4: Table Of Contents
Contents Preparation ........................... 1 Safety Warnings ..........................1 Chapter 1 Introducing the LCD TV .................... 4 Package Contents ........................4 Setting Your LCD TV ......................5 Your LCD TV ......................... 6 Remote Control ..........................9 Chapter 2 Installing the LCD TV ..................11 Connecting a TV Cable or Anterial .................. -
Page 5: Chapter 1 Introducing The Lcd Tv
Chapter 1 Introducing the LCD TV Package Contents Make sure all of the following contents are included. LCD TV Bottom Stand (P.N.: FAEBAC05013) Remote Control/ Power Cord AAA Batteries x 2 for UK model) for EU model) EJECT MENU TEXT ZOOM AUDIO REPEAT... -
Page 6: Setting Your Lcd Tv
Setting Your LCD TV How to install the TV Stand Ensure the TV stand is still attached with the bottom foam packaging material in the package. Read all instructions before continuing with the stand installation. a. Open the box, and make sure all necessary parts are in the box. -
Page 7: Your Lcd Tv
Your LCD TV How to setup the TV Use an antenna cable to connect to the LCD TV’s ANT. terminal (refer to page 15). Insert the 2 batteries supplied in remote control. Step1 Press and lift the back cover up to open the battery compartment of the remote control. - Page 8 Your LCD TV Front View and Controls Blue LED light indicates when the LCD TV is activated. Infrared Receiver Scan up and down through channels. Work as up-down navigation of sub-menu items when in the OSD mode. Press once to display the OSD (on screen display), press again to turn the OSD off. Turn the LCD TV on and into standby mode.
- Page 9 Your LCD TV Rear View and Sockets AC IN ON/OFF SWITCH ITEM DESCRIPTION 1 AC IN Connect the AC power cord to this socket Connect to external equipment with SCART socket. This SCART input allows audio and CVBS/RGB of an external device to be shown on your 2 SCART Connect to the component ( Y, Pb, Pr ) video sockets HDTV, 3 Y, Pb, Pr /AUDIO(L/R)
-
Page 10: Remote Control
Your Remote Control Your Remote Control POWER Turn the LCD TV on and into standby mode. Direct access of TV input. Direct access of VGA input INFO Press once to display a variety of information such as the current channel and the input source. INPUT Select the signal sources: TV->... -
Page 11: Your Remote Control
Your Remote Control Your Remote Control The TV navigation buttons allow you to move, select a variety of information such as the current channel and the input source. Turn EPG on/off. EXIT Exit the OSD menu (On Screen Display). Access the TELETEXT items or correspond to the differently coloured page numbers. -
Page 12: Chapter 2 Installing The Lcd Tv
Chapter 2 Installing the LCD TV Connecting a TV Cable or an Antenna Refer to the owner’s manual of any external equipment for connection procedures. When connecting any external equipment, do not connect any AC power cords to wall outlets until all other connections are completed. - Page 13 Disconnecting from the Mains The STANDBY button on the front view and also on the remote control is only used for turning on the TV to standby mode, it does not disconnect the device from the mains supply. To completely disconnect the main voltage, please switch off the power switch on the rear of the TV, or remove the power plug from the socket.
-
Page 14: Connecting A Tv Cable Or An Antenna
Connecting a TV Cable or an Antenna Refer to the owner’s manual of the external equipment to be connected. When connecting external equipment, do not connect any AC power cords to wall outlets until you ha e completed all the connections. -
Page 15: Connecting An External Dvd Player
Connecting an External DVD Player Rear View of TV AC IN ON/OFF SWITCH HDMI CABLE VGA CABLE DVD PLAYER After connecting an aerial to your LCD TV and connecting the mains cable to the TV METHOD A Use a VGA 15 pins cable to connect the TV Cable Box’s RGB output sockets to your LCD TV. Use a 3.5mm socket to RCA adapter cable for connecting audio. -
Page 16: Connecting A Vcr
Connecting a VCR Rear View of TV AC IN ON/OFF SWITCH VCR PLAYER METHOD (AV1) Use a SCART cable to connect the VCR’s SCART socket to the LCD TV ‘s SCART socket. Connect all AV power sources before turning on the power switch of the LCD TV or other connected equipments. -
Page 17: Connecting A Tv Box Or Satellite Receive
Connecting a TV Cable Box or Satellite Receiver Rear View of TV AC IN ON/OFF SWITCH HDMI CABLE VGA CABLE SATELLITE ANTENNA CABLE SATELLITE RECEIVER TV CABLE BOX Method A : Use a VGA 15 pins cable to connect the TV Cable Box’s RGB output sockets to your LCD TV. Use a 3.5mm socket to RCA adapter cable for connecting audio. -
Page 18: Connecting An Audio Receiver
Connecting an Audio Receiver For better sound quality, you may want to play the LCD TV audio through your stereo system. Rear View of TV AC IN ON/OFF SWITCH Use coaxial cable to connect the audio receiver’s coaxial LINE-IN sockets to LCD TV’s SPDIF OUT sockets (Only for DVB-T ). -
Page 19: Hdmi
HDMI This TV SET supports HDCP ( High-Bandwidth Digital Content Protection ) Protocol for TV SET ( 480p, 576p, 720p, 1 When you connect to the output of an HD ready player ( DVD Player, Set Top Box or PC ) by the HDMI source. -
Page 20: Using Conditional Access Module (Cam)
Using Conditional Access Module (CAM) The Conditional Acc ess Module (CAM) menu provides access to functions contained on the CAM. The module can be inserted into the Common Interface (CI) slot located at the backside (facing downwar- ds) of the TV. A Conditional Access Module (CAM) is an electronic device, usually incorporating a slot for a smart card, which equips a DVB television or set-top box with the appropriate hardware facility to view conditional access content... -
Page 21: Chapter 3 Using The Features
Chapter 3 Using The Features BASIC OPERATION Tuning in the TV channels After connecting an aerial to your LCD TV and connecting the mains cable to the TV and 100-240V AC mains socket, turn the POWER SWITCH on (the | position) at the rear panel of the TV, and the red light will show on the front centre panel of the TV. -
Page 22: Osd Menu Operation
Chapter 3 Using The Features To Mute the Sound Press MUTE and the sound cuts off. To turn mute off, press the MUTE button again, or simply press the VOL. +/- buttons. Sleep Timer Press the SLEEP button continuously to select the sleep timer or turn the sleep timer from the OFF, 30, 60, 90 or 120 minutes. -
Page 23: The Picture Setting
OSD Menu Operation Picture Use the Picture setting menu to adjust the picture quality which best corresponds to your viewing requirements. The Picture Menu includes the following options: OPTION DESCRIPTION Custom: Select for user’s settings. The items of video can be adjusted when the picture Picture mode is for user’s settings except advanced Mode... -
Page 24: The Setup Settings
OSD Menu Operation Setup Use this Setup menu to Setup Channel. Use the buttons to highlight the required setting. Press OK button to select the function. Use buttons to adjust the settings. Press OK button to save the adjustment. Allows to do the Channel Installation automatically. Country: Belgium, Czech Rep, Denmark, Finland, France, Germany, Greece, Hungary, Italy, Auto... -
Page 25: The Option Setting
OSD Menu Operation (Only for VGA) Auto Adjust Allows to auto synchronize VGA signal. Allows you to adjust the Horizontal Position of the H-Position picture. Allows you to adjust the Vertical Position of the V-Position picture. Allows you to improve focus clarity and image Frequency stability. -
Page 26: Chapter 4 Using The Tv Features
Chapter 4 Using The TV Features EPG (TV Guide) The TV guide is an Electronic Programme Guide that provides you with a quick and easy way to view a complete list of digital programmes as you would in a newspaper or TV magazine. You can navigate through the list of digital programmes and obtain detailed information on the programmes. -
Page 27: Channel Installation
Using The TV Features CHANNEL INSTALLATION Use these options (Auto Installation, Manual Installation, and Update Installation) if you have moved to another location or want to rescan for new channels. Press the MENU button on the remote control or the MENU button on the control panel. Use the keys to select Setup function. -
Page 28: Child Lock
Using The TV Features Child Lock The program will be locked when you select the On option in the Child Lock menu. 1 To display the channel that you would like to Lock. 2 Press the MENU button on the remote control or the MENU button on the control panel. Use the keys to select Setup function then press OK key to access. -
Page 29: Channel Edit
Using The TV Features Audio Language Allow you to select the audio language in digital channels. Channel List When you finish CHANNEL INSTALLATION, you can press CH LIST key on the Remote Control to view all channels Use the keys to select a programme. (ATV means analogue channels) CHANNEL EDIT Edit Channel... -
Page 30: Ci Information
Using The TV Features Time Base Allow you to set the system time: Date and Time: User Settings. Time zone: Allow you to adjust and offset local time CI Information Note: CAM Module and Card must be inserted prior viewing the CI information. Allow you to view the CI information. -
Page 31: Troubleshooting
Troubleshooting Before consulting service personnel, check the following chart for a possible cause of problem and for a possible solution. TV will not turn on Make sure the power cord is plugged in. The batteries in the remote control may be exhausted. Replace new and same brand batteries. -
Page 32: Specifications
Specifications KEY FEATURES Various Audio/Video terminals for external equipment connection 1 SCART input terminals 1 set of component Video input terminals 1 VGA / Audio input terminal 2 HDMI / Audio input terminals 1 Headphone terminal High De nition Multimedia Interface ( HDMI ) HDTV Component Video Inputs connections. -
Page 33: Display Modes
Specifications DISPLAY MODES The screen resolution has been optimized during production for the display modes listed below. If the signal from the system equals the standard signal mode, the screen adjusts automatically. If the signal from the system is not equal to the standard signal mode, adjust the screen resolution by referring to your Video Card’s user guide, otherwise there may be no video. -
Page 34: Specifications
Specifications MODE L19H01 UB/UW/CB/CW L22H01 UB/UW/CB/CW Panel System 900 pixels 1680 1050 pixels ( vertical ( vertical PAL I, B/G, D/K PAL I, B/G, D/K SECAM L SECAM L 300 cd/m 300 cd/m 1000:1 1000:1 Inputs / Output SCART HDMI SPDIF Out ANT In 3 W+3 W... - Page 35 This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end of its life separately from your household waste. There are separate collection systems for recycling in the EU. For more information, please contact the local authority or your retailer where you purchased the product.
- Page 36 Quick Connecting to a VCR and Connecting to a VCR a Satellite/Cable box Start not connect the TV to the mains supply until you have completed all the connections. Guide Connect one end of an RF lead to the aerial Note: 2-pin adapter for EU market;...
- Page 37 Skip(Uninstall) a channel Checklist... You should have... Put the two AAA size batteries in your remote control. Press the MENU button on the remote control to enter the menu option. Connected your TV to an aerial or VCR and/or to select SETUP, and press OK to enter the SETUP screen. Press VCR Satellite/Cable box.
