Fusion CA-AM41200 Instruction Manual

AMPLIFIERS
CA-AM10900 CA-AM20350 CA-AM20650 CA-AM40700 CA-AM41200
AMPLIFIER SPECIFICATIONS
CA-AM10900
Peak Power (Watts)
900
Frequency Response 15Hz - 185Hz
Dimensions (mm) 267(l) x 230(w) x 49(h)
10-1/2 x 9-1/16 x 1-15/16" 10-1/2 x 9-1/16 x 1-15/16" 14-27/32 x 9-1/16 x 1-15/16"
Power Ratings
300W RMS x 1
@ 4Ω 1% THD+N,
480W RMS x 1
@ 2Ω 1% THD+N
INSTALLATION GUIDELINES
1. Ensure the +12V lead is disconnected from the battery before you connect any new equipment.
2. Ensure the mounting location will not interfere with the gas tank, brake lines or electrical wiring.
3. Ensure the Amplifier is securely fastened to the vehicle to prevent damage in the event of an accident.
4. Ensure all wiring is protected to avoid pinching or crushing which could result in damage to the audio system.
5. Ensure the mounting location has sufficient air flow around the amplifier. If the amplifier is mounted in an enclosed space a
3" fan with ducting should be used to aid in air flow.
6. Do not mount any amplifier on a subwoofer enclosure as extended exposure to vibration may cause malfunction of the amplifier.
7. Ensure you use the recommended gauge wire/cable for all amplifier connections.
WIRING
Ensure the audio system is turned off before making any connections
to the amplifier, speakers or source unit.
Failure to do so could result in permanent damage to the audio
system. When wiring the FUSION amplifier ensure that the cable
is protected from sharp objects and always use rubber grommets
when wiring through metal panels.
Ensure all terminals and connections are protected from the
vehicle chassis and from each other as failure to do so could result
in permanent damage to the audio system.
POWER
FUSION amplifiers should be connected directly to the +12V battery
terminal with an inline fuse or circuit breaker as close to the battery
as possible.
GROUND
When grounding/earthing your amplifier ensure that the location
is a good source of ground (preferably the floor pan). Make sure
the metal is clean of paint etc as a poor earth could damage your
audio system.
CA-AM20350 CA-AM20650
350 650
10Hz -100kHz 10Hz -100kHz
267(l) x 230(w) x 49(h) 377(l) x 230(w) x 49(h)
55W RMS x 2 115W RMS x 2
@ 4Ω 1% THD+N, @ 4Ω 1% THD+N,
85W RMS x 2 170W RMS x 2
@ 2Ω 1% THD+N, @ 2Ω 1% THD+N,
175W RMS x 1 340W RMS x 1
@ 4Ω Bridged @ 4Ω Bridged
1% THD+N 1% THD+N
CA-AM40700
700
10Hz -100kHz
377(l) x 230(w) x 49(h)
14-27/32 x 9-1/16 x 1-15/16" 18 x 9-1/16 x 1-15/16"
50W RMS x 4
@ 4Ω 1% THD+N,
80W RMS x 4
@ 2Ω 1% THD+N,
160W RMS x 2
@ 4Ω Bridged
1% THD+N
REMOTE TURN ON
This connection turns the amplifier on and should be connected to
the remote turn on wire from the Head Unit. If one is not available
a switched 12v source must be used. Either a power antenna wire
or ACC +12V.
LOW LEVEL INPUTS
Choose the correct length RCA interconnects and run them to the
RCA outputs of the source/head unit, avoiding running beside other
looms and or power cable.
LEVEL CONTROL
This control is used to match the input level of the amplifier to the
output level of you head unit. We recommend the following method.
1. Turn the amplifier level to zero
2. Turn the volume of the head unit to ¾ and the bass and treble
to zero
3. Adjust the level control until the desired maximum volume is
achieved without distortion.
4. Failure to follow these steps may cause permanent damage to
the audio system.
CA-AM41200
1200
10Hz -100kHz
457(l) x 230(w) x 49(h)
110W RMS x 4
@ 4Ω 1% THD+N,
150W RMS x 4
@ 2Ω 1% THD+N,
300W RMS x 2
@ 4Ω Bridged
1% THD+N
www.fusionelectronics.com
