Eviant T4 Series Instruction Manual

4.3" portable digital tv
Hide thumbs Also See for T4 Series:
Table of Contents

Advertisement

Quick Links

See also: User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T4 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eviant T4 Series

Summary of Contents for Eviant T4 Series

  • Page 2: Introduction

    Introduction Congratulations on purchasing your Eviant Portable Digital TV. On June 12, 2009 conversion to the digital television broadcasting standard occurred all throughout the United States and Puerto Rico. Your portable digital television is designed to pick up the new digital signals (ATSC) as well as the older analog signals (NTSC).
  • Page 3 Important Safety Information (continued) Warning: To reduce the risk of fire, electric shock or damage, do not expose this product to rain or moisture. Do not use your TV in high explosive areas as the unit may generate sparks. Do not handle the TV with wet hands while it is being charged. It may cause an electric shock or seriously damage your TV.

  • Page 4: Fcc Compliance

    FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with limits for Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 5: Table Of Contents

    Table of Contents Introduction Important Safety Information ........1 FCC Compliance ............3 Accessories..............3 Getting Started Controls & Connections ..........5 Antenna ............... 6 Using AC Power Adapter ..........6 Using Car Adapter ............6 Rechargeable Battery ..........6 Connecting to Earphones..........

  • Page 6: Getting Started

    Getting Started Controls and Connections 1. 4.3’’ LCD Screen 1. Build-in antenna 2. Menu LEFT AND RIGHT SIDES 1. External antenna Jack 2. Earphone Jack 3. ON/OFF 4. LED indicator 5. DC 5V Jack 6. CH (Up) 7. CH (Down) 8.

  • Page 7: Antenna

    Any movement of the TV can result in loss of the digital signal. Handle the antenna with extreme care to avoid bending it. Your Eviant T4 is also supplied with an external antenna that can be located a short distance away from the TV to improve reception. Connect the external antenna to the antenna connector and the “ANT in”.

  • Page 8: Display Options

    Getting Started (continued) Quick Auto Scan Press OK / AutoScan button and hold for 3 seconds. Auto Scan Setup Wizard will display. Select the antenna type and then go to the next step, Quick Auto Scan will start. To exit during scanning, press Menu button and hold for 3 seconds.

  • Page 9: Audio Menu

    Display Options (continued) Picture Mode Press the CH CH buttons to select Picture Mode. Press the VOL VOL buttons to select Personal, Standard, Dynamic or Soft picture quality. Contrast / Brightness / Sharpness / Tint / Color Press the CH CH buttons to select Contrast/Brightness/Sharpness/Tint/Color. Press the VOL VOL buttons to adjust the value.

  • Page 10: Time Menu

    Display Options (continued) Time Menu Press the VOL VOL buttons to select. Press the CH button to enter into Time Menu. Press the CH CH buttons to select the desired sub-menu. Sleep Time Press the CH CH buttons to select the Sleep Mode. Press the VOL VOL buttons to set the auto shut-off timer.

  • Page 11: Setup Menu

    Display Options (continued) Setup Menu Press the VOL VOL buttons to select Press the CH button to enter into setup window. Press the CH CH buttons to select the desired sub-menu. Menu Language Press the CH CH buttons to select Menu Language and press the VOL VOL buttons to select desired language.
  • Page 12 Display Options (continued) In the Closed Caption Submenu: CC Mode Press the CH CH buttons to select CC Mode. Press the VOL VOL buttons to select the desired option. Basic Selection Press the CH CH buttons to select Basic Selection. Press the VOL VOL buttons to select CC1, CC2, CC3, CC4, Text1, Text2, Text3, and Text4.

  • Page 13: Channel Setup Channel Menu

    Channel Setup Channel Menu Press MENU to pull up the on screen setup menus Press the VOL VOL buttons to select. Channel Press the CH button to move down into channel menu. Press the CH CH buttons to select the desired sub-menu. Air/Cable Press the CH CH buttons to select Air/Cable.
  • Page 14 Channel Setup (continued) Show/Hide Use this function to turn off channels that you don’t want to see as you go through the channels. Press the CH CH buttons to select Show/Hide. Press the VOL button to enter Show/Hide Menu. Press the CH CH buttons to select channel. Press OK button to confirm which channel to show or hide.

  • Page 15: Troubleshooting

    Before contacting customer service, review the steps below to solve simple problems. If you still suspect something wrong with this unit, immediately turn the power off, disconnect the power adapter from the unit, and contact Eviant Customer Service. Never try to repair the unit yourself.

  • Page 16: Specifications

    Made in China www.eviant.com Eviant is seriously concerned about environmental protection, and we hope that you share our concern as well. For more information regarding our recycling program, please visit us at http://www.eviant.com/green or call us at 1-866-935-4396.
