Page 2: Introduction Important Safety Information
Use your portable digital TV at work or take it on vacation and relax with your favorite TV programs anywhere. Please read these instructions carefully to get the most from your new Eviant digital TV. Important Safety Instructions WARNING: To reduce the risk of fire or electric shock. - Page 3 Important Safety Instructions Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. Do not defeat the safety purpose of the polarized or grounding-type plug.
- Page 4 apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus. CAUTION: Danger of explosion if battery is incorrectly replaced.
- Page 5 Important Safety Instructions The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric to persons.
-
Page 6: Fcc Compliance
FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation. -
Page 7: Table Of Contents
Accessories The Following Items Are Included With Your TV. TV Unit AC Adaptor DC Adaptor Telescoping Antenna Soft carrying pouch Documentation NOTE: The Telescoping Antenna comes attached to the unit. Table of Contents Introduction Important Safety Information ..........1 FCC Compliance ..............5 Accessories ................ -
Page 8: Getting Started Front View
Display Options & Channel Setup Scan Channel ................ 12 Display Setup ................ 13 Audio Setup ................13 System Menu................. 14 Service & Support Troubleshooting ..............16 Specifications................. 17 Getting Started Front View LCD Screen... -
Page 9: Side View
Side View Power & Hold button Power: Press and hold it to turn off the unit; press it once to turn on the unit. Hold: press it to lock the buttons. DC 5V Power Jack Headphone Jack CH Up/Down (CH+/-, also use as Up&... -
Page 10: Top & Rear View
Top & Rear View Telescoping Antenna (Removable) Menu Speaker Stand Getting Started Antenna The TV unit is supplied with a telescoping antenna that will provide good reception in most situations. Be sure to keep the TV stationary when trying to receive a signal. Any movement of the TV can result in loss of the digital signal. -
Page 11: Using Ac Adaptor
Using AC Adaptor The TV unit is supplied with a 100~240v AC Power Adaptor for charging the internal battery and for powering the unit. Plug the adaptor into the wall socket and plug the small DC plug into the DC jack adjacent to the power switch. -
Page 12: About Rechargeable Battery
About Rechargeable Battery Your portable TV device comes with a built-in rechargeable Lithium-Ion battery. Charge the battery fully before initial use. Charging time is normally about 3.5 hours. A fully charged battery delivers about 3.5 hours of use. When the battery is weak, an indication symbol will appear on the LCD screen and the unit will power off automatically after a few minutes. -
Page 13: Display Options & Channel Setup
Display Options & Channel Setup Use the on-screen menus to adjust the scan channel, audio, display and other functions. Navigate the menus with the navigation buttons on the side view of Press MENU to enter the setup modes. Press MENU again to go back or exit the menu. -
Page 14: Display Setup
Display Options & Channel Setup Display Setup Press the ◄ ► button to select and select OK to enter. Press the ◄ ► button to select the desired sub-menu. Select which screen aspect to use between Normal and Wide Screen. Display Options &... -
Page 15: System Menu
Display Options & Channel Setup System Menu Press the ◄ ► button to select and select OK to enter. Press the ◄ ► button to select the desired sub-menu. Time Zone Setup Press the ▲ ▼ (CH+/-) button to select desired time zone. Parental Lock The option allows you to set up specific channels and ratings through blocking schemes. - Page 16 General Description Rating TV-Y All Children. TV-Y7 Directed toward children age 7 and older. TV-G General Audience. TV-PG Parental Guidance Suggested. TV-14 Parents Strongly Cautioned. TV-MA Mature Audience Only. Note: The age limit meets FCC Standard. Factory Reset Press the ◄ ► button to select Factory Reset. Press OK to enter the menu.
-
Page 17: Troubleshooting
If you still suspect something wrong with this unit, immediately turn the power off, disconnect the power connector from the unit, and contact Eviant Customer Service. Never try to repair the unit yourself. Problem Possible Cause & Solution... -
Page 18: Specifications
Dimensions (H, W, D)......120mm x 78mm x 19.5mm Weight ..........~ 140g Design and specifications are subject to change without notice. All products distributed by Eviant Inc. unless otherwise indicated Eviant ©2009 Quatto Management Limited. Eviant 1661 Fairplex Drive...
