Summary of Contents for Mach Speed Technologies Trio V7000
- Page 2 Thank you for your support and cooperation! Mach Speed Technologies bears no responsibility for any damage or loss of personal data due to misuse of software and/or hardware, damage to the player caused by human factors, replacement of battery, or other unforeseen circumstances.
- Page 3 Note: ● The playback times listed refer to the maximum playback times possible, using the best power savings. The actual playback time may differ as adjustments to screen brightness; power savings modes, volume, etc are made. ● As there are many brands of Micro SD cards in market, using different quality and speed standards.
- Page 4 can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or telephone reception, which can be determined by turning the equipment off and on, the user in encouraged to try to correct the interference by one or more of the following measures: •...
- Page 5 Caution 1． Do not use the player in exceptionally cold or hot, dusty, damp or dry environments. 2． Do not drop, strike, or throw your player. Physical damage to your player will void ALL warranties. 3． Please charge your battery when A.
- Page 6 /PREV NEXT/ VOL. VOL.+ Button Description 1. Power switch 2. Built in Microphone 3. IR window 4. 【 】:Back Button 5. 【 】:Forward Button 6. 【 】: Up Button 7. 【 】:Down Button 8. VOL -：Volume down button 9. VOL+: Volume up button 10.
- Page 7 Remote control button function description： 1. Power off: press to power the player off. : Mute 3.【 / 】 【 / 】Back, Forward, Up, and Down Buttons 4. ESC key to return. 5. VOL-/VOL + volume increase and reduce. Basic Operations Powering ON or OFF Powering On: Switch the On/Off key to ON state.
- Page 8 removing your SD card. With the player powered off, insert the SD card so that the golden “teeth” are on the underside of the card. Slide the card into the card slot, past flush, until you can feel it “click” into place. To remove the card, again make sure that the player is off, and press the card into the slot further.
- Page 9 2. Once you have named your MP3 player, select Finish, and your Windows Media Player will open to the Sync tab. 3. Drag your music to the sync list (on the right of the screen) from the list on the left. Once you have selected the music you wish to add to the player, press Sync.
- Page 10 4. Windows Media player will load the songs on to your player. 5. Once all the songs you have added are synced to the unit, and Windows Media Player says that is safe to disconnect your MP3 player, disconnect the device.
-
Page 11: Copy And Paste
COPY AND PASTE Note- This alternate method is used to load videos, pictures, and ebook files as well as audio files 1. Connect the MP3 player to a working USB port. 2. When the unit is connected to your computer, it will create a gray and green icon in the system tray (lower right hand corner of your desktop). - Page 12 4. Locate the drive created by the unit, generally just called Removable Disk, with a letter in Parenthesis. Drive letters vary depending on your system configuration. 5. Open the drive by either double left clicking on the drive itself, or by right clicking to open the option menu then left click on the desired drive.
- Page 13 7. Once you have located the song files, you can right click on the song itself, and select “copy”. Open the removable disk drive, right click on in the empty space, and select Paste. This will transfer the song on to your player.
- Page 14 8. Repeat step 7 for as many songs as you want to copy on to the unit. NOTE: MAC Computers When connected to your MAC computer, the device will act as a removable drive. Simply drag your files to the device. Main menu: The Main Menu allows you to select the different Modes of the device.
- Page 15 Settings:...
- Page 16 Output Select Output: Allows you to select whether to display through one of the TV out connections, or the onboard LCD. NOTE- if you select TV in this mode, the LCD will power off, and will not power back on until you have changed this setting (which you will need to do when connected to a TV).
- Page 17 Set Language： Allows you to select your display Language. Note- if you accidentally change your language follow these steps to correct it. Power the player on Press the Down button 5 times. (globe should be highlighted) Press the PLAY button once use the up or down arrows to select your language Press the Play button again...
- Page 18 Use the Up and Down buttons to select the different options and press the PLAY button to access it. The Media Library option will update your media library. We recommend using this option anytime you add or remove files from the player. Local disk allows you to access the audio files loaded to the player’s internal memory, and SD Card allows you to access the audio files loaded on the card.
- Page 19 Live Sound Live Sound allows you to adjust your equalizer settings to improve your song quality. Show lyric When you select this option, you will see the song lyrics for your audio file displayed along with the song as it plays, as long as your .lrc files are present.
- Page 20 When selecting a video file you have began but not finished, you will be prompted with a message stating “continue from the last time?" If “Yes” is selected, it will continue to play from the point where you have stopped. Otherwise the video will start from the beginning.
- Page 21 name, size, format, encoding, sample rate, frame rate and dimensions. Power Information Displays the amount of power left on your battery Visual Effect Allows you to sharpen or blur your video file slightly Show Subtitle ON/OFF- displays subtitles for your current video file (if present) Subtitle list Displays a list of subtitle files you have loaded on your player.
- Page 22 While a video file is playing: Press the Up or Down buttons to view the previous or next picture Press the PLAY button to switch to slideshow mode, or return to normal picture viewing Press and hold the Forward button to rotate the image 90 degrees Briefly press the forward button to enter the Photo submenu When Viewing photos, Press the "VOL + / VOL-"...
- Page 23 Recording playback functions identically to the Music mode, so please refer to that section for operating instructions. While recording, press PLAY to begin or pause the recording, and briefly press the back button when the recording is paused to stop the recording. Pressing the Up or Down buttons will adjust the quality of your recording.
- Page 24 press the PLAY button to access it. FM Receiver begins playing the radio, Radio List displays a list of saved radio stations, and Settings allows you turn on or off your stereo settings mode and select the receiving area When listening to the radio, use the Up and Down buttons to adjust your frequency and press the Forward button to enter the FM Submenu.
- Page 25 TV OUT Function There 3 ways to connect to your TV： 1, Connect the cables as shown above 2, In the Settings menu, select Output, Output Select, then TV 3, Set your TV to HD component (not all televisions have this feature)
- Page 26 1, Connect the cables as shown above 2, In the Settings menu, select Output, Output Select, then TV 3, Set your TV to Composite, or AV (not all televisions have this feature)
- Page 27 1, Connect the cable as above picture 2, [setting]->[Output]->[Output Select]->[TV] 3, [setting]->[Output]->[TV Format]->[HDMI] If you have any issues using your player, or any questions for us, please feel free to contact our technical support Department at 580 272 0035 or by email at mssupport@machspeed.com.
- Page 28 Caution Modifications not approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE- This equipment has been tested and found to comply with the limits for Class B Digital device, pursuant to part 15 of the FCC rules.
