Summary of Contents for Mach Speed Technologies TRIO T3000

  • Page 2 Thank you for your support and cooperation! Mach Speed Technologies bears no responsibility for any damage or loss of personal data due to misuse of software and/or hardware, damage to the player caused by human factors, replacement of battery, or other unforeseen circumstances. To prevent loss of your data, please backup your data regularly.
  • Page 3 Note: ● The playback times listed refer to the maximum playback times possible, using the best power savings. The actual playback time may differ as adjustments to screen brightness; power savings modes, volume, etc are made. ● As there are many brands of Micro SD cards in market, using different quality and speed standards.
  • Page 4 installed and used in accordance with the instructions, may cause harmful interference to radio or telephone reception, which can be determined by turning the equipment off and on, the user in encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna.
  • Page 5 Otherwise it may lead to file corruption, firmware failure, and even hardware damage. • Please ensure that the player is powered off before inserting or removing the Micro SD Card • We are not liable for any loss of data stored on this device. •...
  • Page 6 Get to Know Your Player 1. Earphone Jack 6. VOL+ 11. Next 2. USB port 7. power 12. menu 3. Earphone Jack 8. Hold 13. MIC 4. Micro SD card 9. Camera Button 14. Camera 5. VOL- 10. Previous 15. Stylus...
  • Page 7 Basic Operations Powering on To power the player on, slide the power switch to the UP position and hold it there for 5 seconds or until the welcome screen is displayed. Powering off To power the player on, slide the power switch to the UP position and hold it there for 5 seconds or until the goodbye screen is displayed.
  • Page 8 computer. Hold the Micro SD card face up (side with words aligned in the opposite direction of the display screen), and slide the card into the socket on the player, slightly past flush. When you hear the card click into place, you can access the card. Removing: Ensure that the player is powered off, and push the SD card just past flush.
  • Page 9 Loading files Using Windows Media Player (Note: you must use Windows Media Player 10 or later to use this feature.) (Note: this player does not support DRM encrypted audio or video files, such as those downloaded from the Windows Media Player “Overdrive” download service.) 1.
  • Page 10 2. Once you have named your MP3 player, select Finish, and your Windows Media Player will open to the Sync tab. 3. Drag your music to the sync list (on the right of the screen) from the list on the left. Once you have selected the music you wish to add to the player, press Sync.
  • Page 11 4. Windows Media player will load the songs on to your player. 5. Once all the songs you have added are synced to the unit, and Windows Media Player says that is safe to disconnect your MP3 player, disconnect the device.
  • Page 12: Copy And Paste

    COPY AND PASTE Note- This alternate method is used to load videos, pictures, and ebook files as well as audio files 1. Connect the MP3 player to a working USB port. 2. When the unit is connected to your computer, it will create a gray and green icon in the system tray (lower right hand corner of your desktop).
  • Page 13 4. Locate the drive created by the unit, generally just called Removable Disk, with a letter in Parenthesis. Drive letters vary depending on your system configuration. 5. Open the drive by either double left clicking on the drive itself, or by right clicking to open the option menu then left click on the desired drive.
  • Page 14 7. Once you have located the song files, you can right click on the song itself, and select “copy”. Open the removable disk drive, right click on in the empty space, and select Paste. This will transfer the song on to your player.
  • Page 15 Repeat step 7 for as many songs as you want to copy on to the unit. NOTE: MAC Computers When connected to your MAC computer, the device will act as a removable drive. Simply drag your files to the device.
  • Page 16 Main Menu Once you power the player on, the Main Menu will be displayed with icons for the different modes of the player: Music, Video, Camera, eBook, Photo, Recorder, Explorer, Settings, and Other Functions. Tap the icon corresponding with the mode you wish to enter.
  • Page 17 Music Mode • Note- this player supports audio files in MP3, WMA (non encrypted) WAV, FLAC, OGG, and MP2 formats. If your audio files are not in one of these formats, the files will not play. When you tap the Music icon on the Main Menu, you will enter the Music Selection screen as Displayed below.
  • Page 18 selection (artist, album, genre, etc) or manually by selecting the “Dir List” option. Once you have entered the music playback mode, your audio file will begin playing automatically. Tap the PLAY icon to pause the file, and tap it again to resume playback.
  • Page 19 Please note that to display lyrics, the lyric files (.lrc) must be saved in he same directory or folder as the audio file for them, and ID3 tags must be added to the audio files before loading them to the player in order for them to display. Video Mode •...
  • Page 20 Tap the video file you wish to play, and the file will start automatically. When you tap the screen, the video controls will display. Once you have entered the video playback mode, your file will begin playing automatically. Tap the PLAY icon to pause the file, and tap it again to resume playback.
  • Page 21 Volume Adjustment To Adjust the volume on the player, simply press the V+ or V- buttons to increase or decrease the volume. Alternatively, you can tap the speaker icon on the screen, and slide the volume adjustment bar to the desired level. Camera Mode Camera mode both allows you to take still pictures, and record video.
  • Page 22 video recording mode. Briefly press the camera button to begin recording, and press it again to stop and save the recording. EBook Mode Ebook mode allows you to view your text files loaded on the player. To enter eBook mode, tap the eBook icon on the main menu, and you will enter the ebook selection screen.
  • Page 23 • Flip Time- set the length of time a page is displayed before changing when the auto browser is set Photo Mode • Note- this player supports image files in JPG, GIF, and BMP formats. If your image files are not in one of these formats, the files will not display. To enter Photo Mode tap the Photo Icon on the main menu.
  • Page 24 You can tap the rotate left and right buttons ( ) to rate the image, zoom in and out, or simply tap the next or previous buttons to skip to the next or previous images. Tapping the slideshow icon will allow you to set up a slideshow to automatically display your images.
  • Page 25: Display Settings

    adjust the recording quality and volume. Explorer Explorer mode allows you to select a file to play, of any type. The file will automatically open in the appropriate mode (videos in video mode, audio files in Music mode, etc) Settings The settings mode allows you to adjust a large number of your system settings.
  • Page 26: System Information

    Desk Top Use this item to select one of 5 desktop backgrounds to use. Language Select from one of 19 supported languages System Information Displays some system information including the firmware version, Hardware ID number, flash memory, and SD memory. Automatic Shutdown Allows you to set a timer to power the device off Calibrate screen...
  • Page 27 Other Functions Calculator This functions as a standard calculator. Tap the numbers and symbols to perform calculations Calendar Displays a standard Calendar. If at any point, you have questions about your player or experience an issue with your player, please feel free to contact our technicians at mssupport@machspeed.com by phone at 580 272 0035.
