Frigidaire FGHS2679K Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FGHS2679K
  6. Parts catalog
Frigidaire FGHS2679K Parts Catalog

Frigidaire FGHS2679K Parts Catalog

Side-by-side refrigerator
Hide thumbs Also See for FGHS2679K:
Table of Contents

Advertisement

Quick Links

Download this manual
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet 240389638
N58L00002.eps F58FFDCFA0.eps F58RFDAAA0.eps E58BAAAAE0.eps
F58SLDLEK10.eps F58TEBCAE0.eps E58CAAAAC0.eps F58XFAAAA0.eps
N58YDAAAC5.eps N58I115TServo.eps W241912901.eps S241912901.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
FGHS2669KE0 FGHS2669KP0 FGHS2679KE0 FGHS2679KP0
Gallery
Gallery
Gallery
black
white
black
115
115
115
241912901
241912901
241912901
241979200
241979200
241979200
North America North America North America North America
241935565
241935565
241935566
240389638
240389638
Publication No.
5995532701
09/02/06
(EN/SERVICE/KHB)
137
Gallery
white
115
241912901
241979200
241935566
240389638
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FGHS2669K /
FGHS2679K
©
Copyright
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FGHS2679K and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FGHS2679K

Summary of Contents for Frigidaire FGHS2679K

  • Page 1 Product No. FGHS2669KE0 FGHS2669KP0 FGHS2679KE0 FGHS2679KP0 Series Gallery Gallery Gallery Gallery Color black white black white Volts Wiring Diagram 241912901 241912901 241912901 241912901 Owner's Guide 241979200 241979200 241979200 241979200 Market North America North America North America North America Energy Guide 241935565 241935565 241935566...

  • Page 2: Freezer Door

    Publication No: 5995532701 FGHS2669K / FGHS2679K FREEZER DOOR F58FFDCFA0 02/09...
  • Page 3 FGHS2669K / FGHS2679K Publication No: 5995532701 FREEZER DOOR Model Index: A FGHS2669K (FGHS2669KE0) B FGHS2669K (FGHS2669KP0) C FGHS2679K (FGHS2679KE0) D FGHS2679K (FGHS2679KP0) POS. NO PART NO. DESCRIPTION 241786006 A - C - Gasket-frzr door, black, magnetic 241786002 - B - D Gasket-frzr door, white, magnetic 240334201 A B C D...

  • Page 4: Refrigerator Door

    Publication No: 5995532701 FGHS2669K / FGHS2679K REFRIGERATOR DOOR F58RFDAAA0 02/09...
  • Page 5 FGHS2669K / FGHS2679K Publication No: 5995532701 REFRIGERATOR DOOR Model Index: A FGHS2669K (FGHS2669KE0) B FGHS2669K (FGHS2669KP0) C FGHS2679K (FGHS2679KE0) D FGHS2679K (FGHS2679KP0) POS. NO PART NO. DESCRIPTION 241786005 A - C - Gasket-refr door, black, magnetic 241786001 - B - D Gasket-refr door, white, magnetic 240323002 A B C D...
  • Page 6 Publication No: 5995532701 FGHS2669K / FGHS2679K CABINET E58BAAAAE0 02/09...
  • Page 7 FGHS2669K / FGHS2679K Publication No: 5995532701 CABINET Model Index: A FGHS2669K (FGHS2669KE0) B FGHS2669K (FGHS2669KP0) C FGHS2679K (FGHS2679KE0) D FGHS2679K (FGHS2679KP0) POS. NO PART NO. DESCRIPTION 240435914 A B C D Cover-air duct 241719711 A B C D Cover-evap coil, lower 5303208309 A B C D Plug-hole, factory test...
  • Page 8 Publication No: 5995532701 FGHS2669K / FGHS2679K SHELVES 108A 107B F58SLDLEK10 02/09...
  • Page 9 FGHS2669K / FGHS2679K Publication No: 5995532701 SHELVES Model Index: A FGHS2669K (FGHS2669KE0) B FGHS2669K (FGHS2669KP0) C FGHS2679K (FGHS2679KE0) D FGHS2679K (FGHS2679KP0) POS. NO PART NO. DESCRIPTION 241510607 A B C D Trim-basket 240350604 A B C D Shelf-freezer, glass, upper 240324101 A B C D Shelf-pizza...
  • Page 10 Publication No: 5995532701 FGHS2669K / FGHS2679K CONTROLS 210A F58TEBCAE0 02/09...
  • Page 11 FGHS2669K / FGHS2679K Publication No: 5995532701 CONTROLS Model Index: A FGHS2669K (FGHS2669KE0) B FGHS2669K (FGHS2669KP0) C FGHS2679K (FGHS2679KE0) D FGHS2679K (FGHS2679KP0) POS. NO PART NO. DESCRIPTION 5308000010 A B C D Fan Blade, red, evaporator fan 215474201 A B C D Washer, "slinger", nylon, evap fan shaft 241563601 A B C D...
  • Page 12 Publication No: 5995532701 FGHS2669K / FGHS2679K SYSTEM E58CAAAAC0 02/09...
  • Page 13 FGHS2669K / FGHS2679K Publication No: 5995532701 SYSTEM Model Index: A FGHS2669K (FGHS2669KE0) B FGHS2669K (FGHS2669KP0) C FGHS2679K (FGHS2679KE0) D FGHS2679K (FGHS2679KP0) POS. NO PART NO. DESCRIPTION 240333603 A B C D Condenser 218679607 A B C D Block-evap coil, styrofoam, (2) 218944001 A B C D Drier-filter, R134a System...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995532701 FGHS2669K / FGHS2679K ICE & WATER DISPENSER F58XFAAAA0 02/09...
  • Page 15 FGHS2669K / FGHS2679K Publication No: 5995532701 ICE & WATER DISPENSER Model Index: A FGHS2669K (FGHS2669KE0) B FGHS2669K (FGHS2669KP0) C FGHS2679K (FGHS2679KE0) D FGHS2679K (FGHS2679KP0) POS. NO PART NO. DESCRIPTION 218976419 A B C D Tube-water inlet, valve to door 218976429 A B C D Tube-water inlet, 97.50", brown/tan 218976915...

  • Page 16: Ice Container

    Publication No: 5995532701 FGHS2669K / FGHS2679K ICE CONTAINER 37A 34 34 33 N58YDAAAC5 02/09...
  • Page 17 FGHS2669K / FGHS2679K Publication No: 5995532701 ICE CONTAINER Model Index: A FGHS2669K (FGHS2669KE0) B FGHS2669K (FGHS2669KP0) C FGHS2679K (FGHS2679KE0) D FGHS2679K (FGHS2679KP0) POS. NO PART NO. DESCRIPTION 241716101 A B C D Auger-ice 241685201 A B C D Cam-drive 241561302 A B C D Container-ice, bucket only 241685101...

  • Page 18: Ice Maker

    Publication No: 5995532701 FGHS2669K / FGHS2679K ICE MAKER INSTALLATION PARTS N58I115TServo 02/09...
  • Page 19 FGHS2669K / FGHS2679K Publication No: 5995532701 ICE MAKER Model Index: A FGHS2669K (FGHS2669KE0) B FGHS2669K (FGHS2669KP0) C FGHS2679K (FGHS2679KE0) D FGHS2679K (FGHS2679KP0) POS. NO PART NO. DESCRIPTION 218976419 A B C D Tube-water inlet, valve to door 218976429 A B C D Tube-water inlet, 97.50", brown/tan 218976915 A B C D...
  • Page 20 Publication No: 5995532701 FGHS2669K / FGHS2679K ICE MAKER INSTALLATION PARTS N58I115TServo 02/09...
  • Page 21 FGHS2669K / FGHS2679K Publication No: 5995532701 ICE MAKER Model Index: A FGHS2669K (FGHS2669KE0) B FGHS2669K (FGHS2669KP0) C FGHS2679K (FGHS2679KE0) D FGHS2679K (FGHS2679KP0) POS. NO PART NO. DESCRIPTION 218362501 A B C D Screw, hex washer head, 8-18AB x 1.250, spacer, (2) 5304455846 A B C D Clamp, .31 ID, steel, water tube...

  • Page 22: Wiring Schematic

    Publication No: 5995532701 FGHS2669K / FGHS2679K WIRING SCHEMATIC 02/09...

  • Page 23: Wiring Diagram

    FGHS2669K / FGHS2679K Publication No: 5995532701 WIRING DIAGRAM 02/09 # Functional Parts * Non-Illustrated Parts...
