Frigidaire FGHS2644K - Gallery 26.0 cu. Ft. Refrigerator Service Data Sheet

Parts catalog

Hide thumbs Also See for FGHS2644K - Gallery 26.0 cu. Ft. Refrigerator:

Factory parts catalog (24 pages)

Specification sheet (2 pages)

Parts catalog (24 pages)

See also: Use and Care Manual , Wiring Diagram

Product No.

FGHS2634KB2 FGHS2634KE2 FGHS2634KP2 FGHS2634KQ2 FGHS2634KW2 FGHS2644KF2 FGHS2644KM2

Series

Gallery

Color

black

Volts

115

Wiring Diagram

242072901

Owner's Guide

241979202

Market

North America

Energy Guide

241935574

Service Data Sheet 240389641

N58L00003.eps F58FFDAAA1.eps F58RFDACA0.eps F58BAAAAE3.eps

F58SJCAAD1.eps F58TEACAE0.eps N58CAAAAA14.eps F58XFCAAA0.eps

N58YBAAAA7.eps N58I1151-1.eps W242072901.eps S242072901B.eps

Electrolux Major Appliances

North & Latin America

P.O. BOX 212378

AUGUSTA, GA 30917

Gallery

black (smooth) white (smooth) bisque

115

242072901

241979202

North America

241935574

240389641

Publication No.

5995560355

10/02/26

(EN/SERVICE/DCS)

137

Gallery

white

stainless

silvermist

115

242072901

241979202

North America

North America North America

241935574

241935575

240389641

SIDE-BY-SIDE

REFRIGERATOR

Model No.

FGHS2634K /

FGHS2644K

Table of Contents

Need help?

Do you have a question about the FGHS2644K - Gallery 26.0 cu. Ft. Refrigerator and is the answer not in the manual?

Questions and answers

Summary of Contents for Frigidaire FGHS2644K - Gallery 26.0 cu. Ft. Refrigerator

Page 1 Product No. FGHS2634KB2 FGHS2634KE2 FGHS2634KP2 FGHS2634KQ2 FGHS2634KW2 FGHS2644KF2 FGHS2644KM2 Series Gallery Gallery Gallery Gallery Gallery Gallery Gallery Color black black (smooth) white (smooth) bisque white stainless silvermist Volts Wiring Diagram 242072901 242072901 242072901 242072901 242072901 242072901 242072901 Owner's Guide 241979202 241979202 241979202 241979202...
Page 2: Freezer Door
Publication No: 5995560355 FGHS2634K / FGHS2644K FREEZER DOOR F58FFDAAA1 02/10...
Page 3 FGHS2634K / FGHS2644K Publication No: 5995560355 FREEZER DOOR Model Index: A FGHS2634K (FGHS2634KB2) B FGHS2634K (FGHS2634KE2) C FGHS2634K (FGHS2634KP2) D FGHS2634K (FGHS2634KQ2) E FGHS2634K (FGHS2634KW2) F FGHS2644K (FGHS2644KF2) G FGHS2644K (FGHS2644KM2) POS. NO PART NO. DESCRIPTION 241786006 A B - - - F G Gasket-frzr door, black, magnetic 241786002 - - C D E - -...
Page 4: Refrigerator Door
Publication No: 5995560355 FGHS2634K / FGHS2644K REFRIGERATOR DOOR F58RFDACA0 02/10...
Page 5 FGHS2634K / FGHS2644K Publication No: 5995560355 REFRIGERATOR DOOR Model Index: A FGHS2634K (FGHS2634KB2) B FGHS2634K (FGHS2634KE2) C FGHS2634K (FGHS2634KP2) D FGHS2634K (FGHS2634KQ2) E FGHS2634K (FGHS2634KW2) F FGHS2644K (FGHS2644KF2) G FGHS2644K (FGHS2644KM2) POS. NO PART NO. DESCRIPTION 241786005 A B - - - F G Gasket-refr door, black, magnetic 241786001 - - C D E - -...
Page 6 Publication No: 5995560355 FGHS2634K / FGHS2644K CABINET F58BAAAAE3 02/10...
Page 7 FGHS2634K / FGHS2644K Publication No: 5995560355 CABINET Model Index: A FGHS2634K (FGHS2634KB2) B FGHS2634K (FGHS2634KE2) C FGHS2634K (FGHS2634KP2) D FGHS2634K (FGHS2634KQ2) E FGHS2634K (FGHS2634KW2) F FGHS2644K (FGHS2644KF2) G FGHS2644K (FGHS2644KM2) POS. NO PART NO. DESCRIPTION 240435912 A B C D E F G Cover-air duct 241719711 A B C D E F G...
Page 8 Publication No: 5995560355 FGHS2634K / FGHS2644K CABINET F58BAAAAE3 02/10...
Page 9 FGHS2634K / FGHS2644K Publication No: 5995560355 CABINET Model Index: A FGHS2634K (FGHS2634KB2) B FGHS2634K (FGHS2634KE2) C FGHS2634K (FGHS2634KP2) D FGHS2634K (FGHS2634KQ2) E FGHS2634K (FGHS2634KW2) F FGHS2644K (FGHS2644KF2) G FGHS2644K (FGHS2644KM2) POS. NO PART NO. DESCRIPTION 241710601 A B C D E F G Screw, hex washer hd, 1/4 x 7/8, hinge mtg 241911704 A B - - - F G...
Page 10 Publication No: 5995560355 FGHS2634K / FGHS2644K SHELVES F58SJCAAD1 02/10...
Page 11 FGHS2634K / FGHS2644K Publication No: 5995560355 SHELVES Model Index: A FGHS2634K (FGHS2634KB2) B FGHS2634K (FGHS2634KE2) C FGHS2634K (FGHS2634KP2) D FGHS2634K (FGHS2634KQ2) E FGHS2634K (FGHS2634KW2) F FGHS2644K (FGHS2644KF2) G FGHS2644K (FGHS2644KM2) POS. NO PART NO. DESCRIPTION 241657602 A B C D E F G Shelf, flip up, wire 241657502 A B C D E F G...
Page 12 Publication No: 5995560355 FGHS2634K / FGHS2644K CONTROLS 210A F58TEACAE0 02/10...
Page 13 FGHS2634K / FGHS2644K Publication No: 5995560355 CONTROLS Model Index: A FGHS2634K (FGHS2634KB2) B FGHS2634K (FGHS2634KE2) C FGHS2634K (FGHS2634KP2) D FGHS2634K (FGHS2634KQ2) E FGHS2634K (FGHS2634KW2) F FGHS2644K (FGHS2644KF2) G FGHS2644K (FGHS2644KM2) POS. NO PART NO. DESCRIPTION 5308000010 A B C D E F G Fan Blade, red, evaporator fan 215474201 A B C D E F G...
Page 14 Publication No: 5995560355 FGHS2634K / FGHS2644K SYSTEM N58CAAAAA14 02/10...
Page 15 FGHS2634K / FGHS2644K Publication No: 5995560355 SYSTEM Model Index: A FGHS2634K (FGHS2634KB2) B FGHS2634K (FGHS2634KE2) C FGHS2634K (FGHS2634KP2) D FGHS2634K (FGHS2634KQ2) E FGHS2634K (FGHS2634KW2) F FGHS2644K (FGHS2644KF2) G FGHS2644K (FGHS2644KM2) POS. NO PART NO. DESCRIPTION 242039202 A B C D E F G Condenser 218679607 A B C D E F G...
Page 16: Ice And Water Dispenser
Publication No: 5995560355 FGHS2634K / FGHS2644K ICE & WATER DISPENSER F58XFCAAA0 02/10...
Page 17 FGHS2634K / FGHS2644K Publication No: 5995560355 ICE & WATER DISPENSER Model Index: A FGHS2634K (FGHS2634KB2) B FGHS2634K (FGHS2634KE2) C FGHS2634K (FGHS2634KP2) D FGHS2634K (FGHS2634KQ2) E FGHS2634K (FGHS2634KW2) F FGHS2644K (FGHS2644KF2) G FGHS2644K (FGHS2644KM2) POS. NO PART NO. DESCRIPTION 218976409 A B C D E F G Tube, water, door 218976419 A B C D E F G...
Page 18: Ice Container
Publication No: 5995560355 FGHS2634K / FGHS2644K ICE CONTAINER 37A 34 34 33 N58YBAAAA7 02/10...
Page 19 FGHS2634K / FGHS2644K Publication No: 5995560355 ICE CONTAINER Model Index: A FGHS2634K (FGHS2634KB2) B FGHS2634K (FGHS2634KE2) C FGHS2634K (FGHS2634KP2) D FGHS2634K (FGHS2634KQ2) E FGHS2634K (FGHS2634KW2) F FGHS2644K (FGHS2644KF2) G FGHS2644K (FGHS2644KM2) POS. NO PART NO. DESCRIPTION 241716101 A B C D E F G Auger-ice 241685201 A B C D E F G...
Page 20: Ice Maker
Publication No: 5995560355 FGHS2634K / FGHS2644K ICE MAKER L O C L O C A R M A R M K E D K E D I N T I N T U N T U N T L A C L A C INSTALLATION PARTS N58I1151-1...
Page 21 FGHS2634K / FGHS2644K Publication No: 5995560355 ICE MAKER Model Index: A FGHS2634K (FGHS2634KB2) B FGHS2634K (FGHS2634KE2) C FGHS2634K (FGHS2634KP2) D FGHS2634K (FGHS2634KQ2) E FGHS2634K (FGHS2634KW2) F FGHS2644K (FGHS2644KF2) G FGHS2644K (FGHS2644KM2) POS. NO PART NO. DESCRIPTION 218976409 A B C D E F G Tube, water, door 218976419 A B C D E F G...
Page 22 Publication No: 5995560355 FGHS2634K / FGHS2644K ICE MAKER L O C L O C A R M A R M K E D K E D I N T I N T U N T U N T L A C L A C INSTALLATION PARTS N58I1151-1...
Page 23 FGHS2634K / FGHS2644K Publication No: 5995560355 ICE MAKER Model Index: A FGHS2634K (FGHS2634KB2) B FGHS2634K (FGHS2634KE2) C FGHS2634K (FGHS2634KP2) D FGHS2634K (FGHS2634KQ2) E FGHS2634K (FGHS2634KW2) F FGHS2644K (FGHS2644KF2) G FGHS2644K (FGHS2644KM2) POS. NO PART NO. DESCRIPTION 5304455650 A B C D E F G Screw, hex washer head, 8-15A x 0.625, Low Profile 241796401 A B C D E F G...
Page 24: Wiring Schematic
Publication No: 5995560355 FGHS2634K / FGHS2644K WIRING SCHEMATIC 02/10...
Page 25: Wiring Diagram
FGHS2634K / FGHS2644K Publication No: 5995560355 WIRING DIAGRAM 02/10 # Functional Parts * Non-Illustrated Parts...
