Frigidaire FGHS2667K Factory Parts Catalog
Side-by-side refrigerator
Hide thumbs
Also See for FGHS2667K:
- Installation instructions (2 pages) ,
- Specification sheet (2 pages)
Table of Contents
Advertisement
Quick Links
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet 240389638
N58L00002.eps F58FFDAAA0.eps F58RFDACA0.eps E58BAAAAE0.eps
F58SKDIBK10.eps F58TEBCAE0.eps N58CAAAAC14.eps F58XFAAAA0.eps
N58YDAAAC4.eps N58I115TServo.eps W241912901.eps S241912901.eps
P.O. BOX 212378
AUGUSTA, GA 30917
FGHS2667KB0 FGHS2667KE0 FGHS2667KP0 FGHS2667KW0
Gallery
Gallery
Gallery
black
black
white
115
115
115
241912901
241912901
241912901
241979200
241979200
241979200
North America North America North America North America
241935564
241935564
241935564
240389638
240389638
Publication No.
5995532743
09/02/06
(EN/SERVICE/DCS)
137
Gallery
white
115
241912901
241979200
241935564
240389638
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FGHS2667K
©
Copyright
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire FGHS2667K
Summary of Contents for Frigidaire FGHS2667K
- Page 1 Product No. FGHS2667KB0 FGHS2667KE0 FGHS2667KP0 FGHS2667KW0 Series Gallery Gallery Gallery Gallery Color black black white white Volts Wiring Diagram 241912901 241912901 241912901 241912901 Owner's Guide 241979200 241979200 241979200 241979200 Market North America North America North America North America Energy Guide 241935564 241935564 241935564...
-
Page 2: Freezer Door
Publication No: 5995532743 FGHS2667K FREEZER DOOR F58FFDAAA0 02/09... - Page 3 FGHS2667K Publication No: 5995532743 FREEZER DOOR Model Index: A FGHS2667K (FGHS2667KB0) B FGHS2667K (FGHS2667KE0) C FGHS2667K (FGHS2667KP0) D FGHS2667K (FGHS2667KW0) POS. NO PART NO. DESCRIPTION 241786006 A B - - Gasket-frzr door, black, magnetic 241786002 - - C D Gasket-frzr door, white, magnetic 240334201 A B C D Bin-door, frzr-upper...
-
Page 4: Refrigerator Door
Publication No: 5995532743 FGHS2667K REFRIGERATOR DOOR F58RFDACA0 02/09... - Page 5 FGHS2667K Publication No: 5995532743 REFRIGERATOR DOOR Model Index: A FGHS2667K (FGHS2667KB0) B FGHS2667K (FGHS2667KE0) C FGHS2667K (FGHS2667KP0) D FGHS2667K (FGHS2667KW0) POS. NO PART NO. DESCRIPTION 241786005 A B - - Gasket-refr door, black, magnetic 241786001 - - C D Gasket-refr door, white, magnetic 240323002 A B C D Bin-door, pseudo, bottom...
- Page 6 Publication No: 5995532743 FGHS2667K CABINET E58BAAAAE0 02/09...
- Page 7 FGHS2667K Publication No: 5995532743 CABINET Model Index: A FGHS2667K (FGHS2667KB0) B FGHS2667K (FGHS2667KE0) C FGHS2667K (FGHS2667KP0) D FGHS2667K (FGHS2667KW0) POS. NO PART NO. DESCRIPTION 240435914 A B C D Cover-air duct 241719711 A B C D Cover-evap coil, lower 5303208309 A B C D Plug-hole, factory test 14A#...
- Page 8 Publication No: 5995532743 FGHS2667K SHELVES 108A 107B F58SKDIBK10 02/09...
- Page 9 FGHS2667K Publication No: 5995532743 SHELVES Model Index: A FGHS2667K (FGHS2667KB0) B FGHS2667K (FGHS2667KE0) C FGHS2667K (FGHS2667KP0) D FGHS2667K (FGHS2667KW0) POS. NO PART NO. DESCRIPTION 241510607 A B C D Trim-basket 240350604 A B C D Shelf-freezer, glass, upper 240324101 A B C D Shelf-pizza 240350605 A B C D...
- Page 10 Publication No: 5995532743 FGHS2667K CONTROLS 210A F58TEBCAE0 02/09...
- Page 11 FGHS2667K Publication No: 5995532743 CONTROLS Model Index: A FGHS2667K (FGHS2667KB0) B FGHS2667K (FGHS2667KE0) C FGHS2667K (FGHS2667KP0) D FGHS2667K (FGHS2667KW0) POS. NO PART NO. DESCRIPTION 5308000010 A B C D Fan Blade, red, evaporator fan 215474201 A B C D Washer, "slinger", nylon, evap fan shaft 241563601 A B C D Bushing-motor mtg...
- Page 12 Publication No: 5995532743 FGHS2667K SYSTEM N58CAAAAC14 02/09...
- Page 13 FGHS2667K Publication No: 5995532743 SYSTEM Model Index: A FGHS2667K (FGHS2667KB0) B FGHS2667K (FGHS2667KE0) C FGHS2667K (FGHS2667KP0) D FGHS2667K (FGHS2667KW0) POS. NO PART NO. DESCRIPTION 240333603 A B C D Condenser 218679607 A B C D Block-evap coil, styrofoam, (2) 218944001 A B C D Drier-filter, R134a System 241516901...
-
Page 14: Ice And Water Dispenser
Publication No: 5995532743 FGHS2667K ICE & WATER DISPENSER F58XFAAAA0 02/09... - Page 15 FGHS2667K Publication No: 5995532743 ICE & WATER DISPENSER Model Index: A FGHS2667K (FGHS2667KB0) B FGHS2667K (FGHS2667KE0) C FGHS2667K (FGHS2667KP0) D FGHS2667K (FGHS2667KW0) POS. NO PART NO. DESCRIPTION 218976419 A B C D Tube-water inlet, valve to door 218976429 A B C D Tube-water inlet, 97.50", brown/tan 218976915 A B C D...
-
Page 16: Ice Container
Publication No: 5995532743 FGHS2667K ICE CONTAINER 37A 34 34 33 N58YDAAAC4 02/09... - Page 17 FGHS2667K Publication No: 5995532743 ICE CONTAINER Model Index: A FGHS2667K (FGHS2667KB0) B FGHS2667K (FGHS2667KE0) C FGHS2667K (FGHS2667KP0) D FGHS2667K (FGHS2667KW0) POS. NO PART NO. DESCRIPTION 241716101 A B C D Auger-ice 241685201 A B C D Cam-drive 241561302 A B C D Container-ice, bucket only 241685101 A B C D...
-
Page 18: Ice Maker
Publication No: 5995532743 FGHS2667K ICE MAKER INSTALLATION PARTS N58I115TServo 02/09... - Page 19 FGHS2667K Publication No: 5995532743 ICE MAKER Model Index: A FGHS2667K (FGHS2667KB0) B FGHS2667K (FGHS2667KE0) C FGHS2667K (FGHS2667KP0) D FGHS2667K (FGHS2667KW0) POS. NO PART NO. DESCRIPTION 218976419 A B C D Tube-water inlet, valve to door 218976429 A B C D Tube-water inlet, 97.50", brown/tan 218976915 A B C D...
- Page 20 Publication No: 5995532743 FGHS2667K ICE MAKER INSTALLATION PARTS N58I115TServo 02/09...
- Page 21 FGHS2667K Publication No: 5995532743 ICE MAKER Model Index: A FGHS2667K (FGHS2667KB0) B FGHS2667K (FGHS2667KE0) C FGHS2667K (FGHS2667KP0) D FGHS2667K (FGHS2667KW0) POS. NO PART NO. DESCRIPTION 5304455651 A B C D Screw, hex washer head, 8-15A x 0.500 5304455846 A B C D Clamp, .31 ID, steel, water tube 5304458374 A B C D...
-
Page 22: Wiring Schematic
Publication No: 5995532743 FGHS2667K WIRING SCHEMATIC 02/09... -
Page 23: Wiring Diagram
FGHS2667K Publication No: 5995532743 WIRING DIAGRAM 02/09 # Functional Parts * Non-Illustrated Parts...
