Hanna Instruments HI 99141 Instruction Manual

Instruction Manual
HI 99141
Portable Waterproof
pH Meter for Cooling Towers
w w w . h a n n a i n s t . c o m
WARRANTY
All Hanna Instruments meters are warranted
for two years against defects in workmanship
and materials when used for their intended pur-
pose and maintained according to instructions.
The probes are warranted for a period of
six months.
This warranty is limited to repair or replacement
free of charge. Damages due to accident, mis-
use, tampering or lack of prescribed maintenance
are not covered.
If service is required, contact the dealer from
whom you purchased the instrument. If under
warranty, report the model number, date of pur-
chase, serial number and the nature of the prob-
lem. If the repair is not covered by the warranty,
you will be notified of the charges incurred. If the
instrument is to be returned to Hanna Instru-
ments, first obtain a Returned Goods Authoriza-
tion Number from the Customer Service depart-
ment and then send it with shipment costs pre-
paid. When shipping any instrument, make sure it
is properly packaged for complete protection.
All rights are reserved. Reproduction in whole or
in part is prohibited without the written consent of
the copyright owner.
Dear Customer,
Thank you for choosing a Hanna Instruments
product.
Please read this instruction manual care-
fully before using the instrument. If you need
additional technical information, do not hesi-
tate to e-mail us at tech@hannainst.com
This instrument is in compliance with the
directives.
PRELIMINARY EXAMINATION
Remove the instrument from the packing
material and examine it carefully to make
sure that no damage has occurred during
shipment. If noticeable damage is evident,
notify your dealer.
Note: Save all packing material until you
are sure that the instrument func-
tions correctly. All defective items
must be returned in the original
packing together with the supplied
accessories.
GENERAL DESCRIPTION
HI 99141 is a portable, microprocessor-
based pH and temperature meter with a
special probe.
HI 72911 is a rugged double junction pH
electrode with a flat tip and stainless-steel
body that also functions as a matching pin.
The electrode has an annular Teflon ®
tion for maximum surface contact and the
flat tip is easy to clean and prevents solids
in solution from collecting on the sensor.
Moreover, a built-in temperature sensor al-
lows simultaneous pH and temperature
readings and a mini amplifier renders mea-
surements impervious to noise and elec-
trical interferences.
Each meter is supplied complete with:
•
HI 72911 pH/temperature probe
•
calibration & cleaning solution sachets
• 3x1.5V AA alkaline batteries
•
instruction manual
•
rugged carrying case
LCD DESCRIPTION
1. Automatic Temperature Compensation
indicator
2. Stability indicator
3. Battery percentage
4. pH calibration indicator
5. Low battery indicator
6. Selectable temperature unit
7. Secondary display
8. Primary display
ACCESSORIES
HI 72911 Combination amplified pH
electrode with built-in tem-
perature sensor, flat tip and
stainless-steel body
HI 7004L pH 4.01 buffer solution, 500 mL
HI 7006L pH 6.86 buffer solution, 500 mL
HI 7007L pH 7.01 buffer solution, 500 mL
junc-
HI 7009L pH 9.18 buffer solution, 500 mL
HI 7010L pH 10.01 solution, 500 mL
HI 70300L Storage solution, 500 mL
HI 7061L Cleaning solution, 500 mL
HI 70670L Cleaning solution for salt de-
posits on electrodes, 500 mL
HI 70671L Cleaning & disinfection solu-
tion for algae, fungi & bacteria,
500 mL bottle
HI 710007 Blue shockproof rubber boot
HI 710008 Orange shockproof rubber boot
HI 721312 Rugged carrying case
HI 76405 Electrode holder
SPECIFICATIONS
Range -2.00 to 16.00 pH
-5.0 to 105.0°C / 23.0 to 221.0°F
Resolution 0.01 pH
0.1°C / 0.1°F
Accuracy ±0.02 pH
(@20°C)
±0.5°C up to 60°C; ±1°C outside
±1°F up to 140°F; ±2°F outside
Typical EMC ±0.02 pH
Deviation ±0.2°C or ±0.4°F
Temperature Automatic
Compensation
pH Calibration Automatic, 1 or 2 point
with 2 sets of memorized buffers
(pH 4.01/7.01/10.01 or 4.01/6.86/9.18)
Probe HI 72911
(included)
amplified pH-electrode with built-in
temperature sensor and matching pin
Battery Type 3 x 1.5V AA / IEC LR6
Battery Life Approx. 1500 hours
Auto-off After 8 minutes of non-use
Environment 0 to 50°C (32 to 122°F);
RH max 100%
Dimensions 150x80x36 mm (5.9x3.1x1.4")
Weight 210 g (7.4 oz.)
To clean the meter, it is recommended to use water.
Hanna Instruments reserves the right to
modify the design, construction and appear-
ance of its products without advance notice.
IST99141R3 07/05
