SPECIFICATIONS
GENERAL
High quality single bowl sink is seamlessly formed of #18
gauge brass, copper, or type 304 (18-8) nickel bearing stainless
steel material. Specialty Collection brass or copper sinks are
made from genuine solid, uncoated material and will naturally
tarnish.
SCUH1816BH brass with hammered mirror finish
SCUH1816BM brass with mirror finish
SCUH1816BS brass with satin finish
SCUH1816CH copper with hammered mirror finish
SCUH1816CM copper with mirror finish
SCUH1816CS copper with satin finish
SCUH1816SH stainless steel with hammered mirror finish
SCUH1816SM stainless steel with mirror finish
DESIGN FEATURES
Bowl Depth: 7-1/2".
Coved Corners: 4" vertical and 2-3/4" horizontal radii.
Underside: Sound deadening pads on sides.
OTHER
Drain Opening: 3-1/2".
Note: All Elkay undermount sinks are designed to affix easily to
the underside of any solid surface countertop.
Brass and copper sink models furnished complete with match-
ing drain and basket strainer.
SINK DIMENSIONS (INCHES)*
Overall
Inside Bowl
Model
Number
L
W
L
SCUH1816BH
20
18
18
SCUH1816BM
20
18
18
SCUH1816BS
20
18
18
SCUH1816CH
20
18
18
SCUH1816CM
20
18
18
SCUH1816CS
20
18
18
SCUH1816SH
20
18
18
SCUH1816SM
20
18
18
*
Length is left to right. Width is front to back
**
Template and countertop mounting clips are packed with every sink.
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay
www.elkayusa.com
®
Minimum
Cutout in
Cabinet
W
D
Countertop
Size
16
7
1
⁄
24
2
16
7
1
⁄
24
2
16
7
1
⁄
24
2
16
7
1
⁄
24
2
See
Template**
16
7
1
⁄
24
2
16
7
1
⁄
24
2
1
16
7
⁄
24
2
1
16
7
⁄
24
2
.
2222 Camden Court
Oak Brook, IL 60523
Elkay Specialty Collection
18"
16"
Ship.
Wt.
Lbs.
15
15
15
15
15
15
14
14
Installation Profile of SCUH Models
The template provided with each SCUH sink provides
the only type of installation recommended by Elkay.
COUNTERTOP
MOUNTING
BRACKET
FASTENER
(NOT FURNISHED)
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
™
Undermount Sinks
Model SCUH1816 Series
Model SCUH1816
4" R
18"
20"
2-3/4" R
Model SCUH1816
CONTOUR EDGE
TO CUSTOMER DESIRE
1/2"
SILICONE CAULK
(NOT FURNISHED)
SINK
1-1/8"
Printed in U.S.A.
©2005 Elkay
(Rev. 1/05)
7-1/2"
1-177A
