Garage Door Opener
Model 1270LMC
- 1/2 HP -
For Residential Use Only
Owner's Manual
Please read this manual and the enclosed safety materials carefully!
Fasten the manual near the garage door after installation.
The door WILL NOT CLOSE unless the Protector System
®
is connected and
properly aligned
Periodic checks and adjustment of the opener are required to ensure safe
operation.
The model number label is located under the light lens on the left side of your
opener.
Advertisement
Table of Contents
Related Manuals for Chamberlain 1270LMC 1/2 HP
Summary of Contents for Chamberlain 1270LMC 1/2 HP
- Page 1 ® Garage Door Opener Model 1270LMC - 1/2 HP - For Residential Use Only Owner's Manual Please read this manual and the enclosed safety materials carefully! Fasten the manual near the garage door after installation. The door WILL NOT CLOSE unless the Protector System ®...
-
