Eclipse AVN5495 Installation Manual page 2

Components
Components
Main unit components
Main unit x 1
1
Antenna
4
extension cable x 1
GPS antenna components
GPS antenna
8
x 1
Wiring components
Clamp
12
(for GPS antenna) x 3
Tip
When installing the main unit, some vehicle models may require the use of items that need to be
obtained separately such as a power supply adaptor cable, radio antenna adaptor cable or mounting
bracket.
Check that all of the following components are present
Check that all of the following components are present
Interconnecting cable
2
(Power and speaker connector)
Hex-head bolt
5
(Red:M5x8) x 8
Waterproof cushion 10
9
x 1
Cable tie
13
(for GPS antenna) x 4
(16P) x 1
Flathead screw
6
(Red:M5x8) x 8
Body protective sheet
Ground plate
11
x 1
Harness fixing tape
14
- 2 -
Interconnecting cable
3
(video input)
(6P) x 1
Splicing connector
7
x 3
x 1
x 3
