Frigidaire FRT21H7AS Factory Parts Catalog
Top mount r134a series
Hide thumbs
Also See for FRT21H7AS:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT21H7ASB1
FRT21H7AS
MARKET
North America
ENERGY GUIDE LABEL - # 240465001
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET - # 240379009
SERIES
COLOR
R134a
stain/blk
Publication No.
5995371977
020513
-EN/SERVICE/DCS
357
VOLTS
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21H7AS
Advertisement
Related Manuals for Frigidaire FRT21H7AS
Summary of Contents for Frigidaire FRT21H7AS
- Page 1 PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21H7ASB1 FRT21H7AS R134a stain/blk MARKET North America ENERGY GUIDE LABEL - # 240465001 OWNER’S GUIDE - # 240400105 SERVICE DATA SHEET - # 240379009 TOP MOUNT REFRIGERATOR Model No. FRT21H7AS Publication No. 5995371977 020513 -EN/SERVICE/DCS...
- Page 2 DOOR...
- Page 3 5995371977 DOOR POS. NO PART NO DESCRIPTION 240514611 Gasket,frzr door seal ,black ,magnetic 240514612 Gasket,refr door seal ,black ,magnetic 240338303 Door,dairy ,clear 240381305 Plug-button,gray ,hinge brg hole ,(2) 240450323 Panel-frzr door, stainless steel, complete assy 240416304 Nameplate,black 240312405 Door Stop,black ,ref 240312406 Door Stop,black ,frzr 240494005...
- Page 4 CABINET...
- Page 5 5995371977 CABINET POS. NO PART NO DESCRIPTION 240355404 Cover-fan 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240313606 Cover-evap coil 240371303 Seal,insulation ,53.23 in. long, foam, coil cover 10*# 240385402 Wiring Harness,freezer section 5303208309 Plug-hole,factory test 240366801 Plug-ice maker harness,rectangular 240374401 Plug-wtr inlet tube,round ,1"...
- Page 6 SHELVES...
- Page 7 5995371977 SHELVES POS. NO PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 240358003 Shelf,freezer ,full-width ,wire 5303299664 Spacer,shelf 240417802 Diffuser-air,top 240362601 Diffuser,air ,bottom 14 # 240505801 Switch,light/lamp 240436702 Light Bulb/Lamp, A-15, 40 W, 120 V, miniature 241500701 Socket-light/lamp 240407301 Control Box 17*# 240375501 Wiring Harness,control box...
- Page 8 SYSTEM...
- Page 9 5995371977 SYSTEM POS. NO PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240496101 Wiring Harness, machine compt, w/electric cord 6* # 240375501 Wiring Harness,control box 6* # 240385402 Wiring Harness,freezer section 14 # 5303918247 Defrost Heater Kit 15 # 5303918250 Evaporator Kit 5308000110 Strap-evap/heater,aluminum ,(2)
-
Page 10: Wiring Schematic
WIRING SCHEMATIC... -
Page 11: Wiring Diagram
5995371977 WIRING DIAGRAM...
