Elkay LK722B Specifications

Backsplash-Mounted Sensor Faucet
Battery Powered
LK722B

SPECIFICATIONS

GENERAL

LK722B Sensor-operated, non-mixing (tempered water),
backsplash-mounted gooseneck faucet with adjustable
sensor eyes. A continuous beam is emitted from sensor. The
sensor faucet is activated by user placing hands under the
spout. Tempered water will flow as long as hands remain
within sensor range. When hands are removed, the water
stops automatically based on shut off delay setting. The
sensor then resets and is ready for the next user. Battery
powered and has a battery holder with (4) AA batteries.
Chrome plated – solid brass body construction and
12-3/4" (324mm) high (bottom of base to top of spout),
8-3/4" (222mm) from aerator to base, 5-3/8" (137mm) reach
C.P. spout with 2.0 gpm laminar flow control on spout end.
Includes vandal-resistant, water-resistant sensor control
module with armored vandal-resistant control and power
cables. Slow-closing piston operated solenoid valve, in-line
filter with clean out trap, and 3/8" (10mm) copper fittings for
supply tube furnished by contractor. Control circuit is solid
state, has adjustable sensor range (6" [152mm] preset to
30" [762mm]), shut off delay preset at 1 second and field
adjustable to 2, 4 or 8 seconds, and automatic time-out
feature (to prevent sink overflow) is preset at 0 seconds and
is field adjustable to 15, 30 or 60 seconds.
5-3/8"
(137mm)
8-3/4"
(222mm)
30"
(762mm)
MAX
Elkay warrants its faucet and water dispensers to be free of defects in work-
manship and material for a period of one year from the date of purchase.
Replacement parts are available from Elkay for a nominal charge. Upon return
of a defective part to Elkay during the warranty period with written notice of
the claimed defect, Elkay will refund the replacement charge.
WASTE FITTINGS AND ACCESSORIES ARE NOT WARRANTED; OTHER
WARRANTY CONDITIONS:
Our warranty does not cover product failure caused by abusive treatment,
misuse, or damage due to handling or faulty installations. This warranty is
extended only to the original consumer purchaser of the product. This war-
ranty does not cover shipping costs, labor costs, or any other charges for
such items as installation or replacement of the sink, diagnosis or replacement
of any faucet or component part, or any other expense or loss.
ALL INCIDENTAL OR CONSEQUENTIAL DAMAGES ARE SPECIFICALLY
EXCLUDED. NO ADDITIONAL WARRANTIES, EXPRESS OR IMPLIED, ARE
GIVEN. ANY IMPLIED WARRANTY, INCLUDING ONE OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, IS LIMITED TO THE DURATION
OF THIS WRITTEN WARRANTY.
Elkay Manufacturing Company
www.elkay.com
10-1/4"
(261mm)
2-1/2"
(64mm)
ELKAY FAUCET/WATER DISPENSERS LIMITED WARRANTY
Model LK722B
This faucet is ADA compliant.
Some states do not allow the exclusion or limitation of incidental or
consequential damages or limitations on how long an implied warranty lasts,
so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
TO OBTAIN SERVICE UNDER WARRANTY
1. Write to: Elkay Manufacturing Company
Attention: Consumer Service
2222 Camden Court
Oak Brook, Illinois 60523
2. Include a letter containing the following information:
a. Date of purchase and installation
b. Description of nature of defect
c. Model number or description of model and/or component part if
possible.
2222 Camden Court
Oak Brook, IL 60523
®
3/8" (10mm)
COPPER SUPPLY TUBE
(NOT SUPPLIED)
Printed in U.S.A.
©2001 Elkay Mfg. Co.
17-22
(5/01)
