Frigidaire FRT21HC5D Factory Parts Catalog
R134a series top-mount refrigerator
Hide thumbs
Also See for FRT21HC5D:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
N05L00004.eps N05DBDCKA0.eps N05BBAABA6.eps N05SAAAEA13.eps
N05CAAAAA10.eps
240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FRT21HC5DW0
Series
R134a
Color
white
Volts
115
Wiring Diagram
240398801
Owner's Guide
240400111
Market
North America
Energy Guide
241538743
Service Data Sheet
240379014
Installation Instructions 240568300
Publication No.
5995413886
04/07/27
(EN/SERVICE/WC)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRT21HC5D
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FRT21HC5D
Summary of Contents for Frigidaire FRT21HC5D
- Page 1 Volts Wiring Diagram 240398801 Owner's Guide 240400111 Market North America Energy Guide 241538743 Service Data Sheet 240379014 Installation Instructions 240568300 TOP-MOUNT REFRIGERATOR FRT21HC5D Publication No. 5995413886 04/07/27 (EN/SERVICE/WC) © Copyright 2004 Electrolux Home Products, Inc. Model No. All rights reserved.
- Page 2 Publication No: 5995413886 FRT21HC5DW0 DOOR 07/04...
- Page 3 POS. NO PART NO. 240514607 240514608 240534901 240534701 240337703 240534801 240381301 240450301 240415201 240312403 240312404 240494001 240450401 218428101 240383401 240521301 218252200 240527101 218396700 215503200 # Functional Parts * Non-Illustrated Parts FRT21HC5DW0 DOOR DESCRIPTION Gasket, seal, white, frzr door, magnetic Gasket, seal, white, refr door, magnetic Rack-door Rack-door, 4B Door-dairy, w/o graphics, clear...
- Page 4 Publication No: 5995413886 FRT21HC5DW0 CABINET 07/04...
- Page 5 POS. NO PART NO. 240355402 240367001 5303001028 241523701 5308000010 5300157666 5303292396 240313610 240568606 5303208309 240366801 218843800 240374401 12A* 241586701 13 # 240369701 218931001 5303292397 240433201 240411901 218252200 215774901 240335501 240314002 240311303 240313802 240336802 240516401 240337601 240313701 240354401 5303001609 5308009759 240578901 240335003 240516501 5303001343...
- Page 6 Publication No: 5995413886 FRT21HC5DW0 SHELVES 07/04...
- Page 7 POS. NO PART NO. 215667501 240358003 5303299664 240545901 240362601 241554901 241555401 241500701 240368101 17*# 240388701 240360801 21 # 5304421256 5303916855 23 # 215846606 5303001259 240360904 240364717 240361202 240361301 240343801 240361801 240530803 240350609 5308016566 # Functional Parts * Non-Illustrated Parts FRT21HC5DW0 SHELVES DESCRIPTION Tray, ice cube, plastic...
- Page 8 Publication No: 5995413886 FRT21HC5DW0 SYSTEM N05CAAAAA10 07/04...
- Page 9 POS. NO PART NO. 240444401 218944001 240496101 6* # 240388701 6* # 240524701 14 # 5303918247 15 # 5303918274 5308000110 241551801 240518402 21 # 5303918202 240330001 218252200 218513300 240491501 240332602 29 # 5303918299 30 # 241527802 241527901 240405201 240555001 215174700 5308016566 218909915 240542601...
-
Page 10: Wiring Schematic
Publication No: 5995413886 FRT21HC5DW0 WIRING SCHEMATIC 07/04... -
Page 11: Wiring Diagram
FRT21HC5DW0 Publication No: 5995413886 WIRING DIAGRAM 07/04 # Functional Parts * Non-Illustrated Parts...
