SPECIFICATIONS
GENERAL
Elite Gourmet Apron Sink can be customized with optional back-
splash and faucet.
SINK DESIGN FEATURES
Material: Hand fabricated and finished from professional grade
16 gauge, Type 304 stainless steel.
Length: Standard 36".
Bowl Depth: 10".
Coved Corners: 1-3/4" Vertical and Horizontal Radius.
Outer edge of sink has a 5/32" raised rim.
Underside: Fully protected by heavy duty Sound Guard
coating to prevent condensation and deaden sound.
Hand blended and finished stainless steel surface featuring a
highlighted inside top bowl radius.
Drain Fitting: (1) LK99 drain included.
Not compatible with cabinet.
Sinks come standard with backsplash mounting holes. Specify
"WB" suffix to order without.
Backsplash: For design features, reference specification sheet
EG-5.
Faucets: For design features, reference specification sheets, EG-7
and EG-8.
OPTIONAL ACCESSORIES
LKH180/190 Series Instant Hot Water Dispensers
LK2156 Series Instant Cold Water Dispensers
ERS1 Remote Chiller
LK313 Series Soap Dispensers
LKRB1611 Rinse Basket
SINK DIMENSIONS (INCHES)*
Overall
Model
Number
L
W
L
3626EGSF
36
26
28
*
Length is left to right. Width is front to back
TOP VIEW
1-3/4" R
28"
4"
36"
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
Elkay
www.elkayusa.com
®
™
under-
No. of 1-1/2" Dia. Faucet
Fits
Holes. 2 Hole at 8" Centers,
Bowl
Cabinet
3 and 4 Hole at 4" Centers.
W
D
Base
0 Hole Std. w/ 2" Backsplash
16
10
36"
.
3/8" DIA. HOLE
(5 PLACES)
5-1/2"
5"
26"
16"
14"
4-1/2"
4"
2222 Camden Court
Oak Brook, IL 60523
Model 3626EGSF
shown with optional
3/4" Backsplash
0, 2, 3 or 4
10"
2-1/16"
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elite Gourmet
36" SINGLE BOWL APRON SINK
Model 3626EGSF
SIDE VIEW
23-15/16" 1/16
Printed in U.S.A.
©2003 Elkay
(Rev. 4/03)
™
by Elkay
1-1/2"
EG-11B
