Frigidaire FRT21NRH Factory Parts Catalog
Hide thumbs
Also See for FRT21NRH:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
Download this manual
See also:
Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT21NRHD0
FRT21NRH
FRT21NRHW0
FRT21NRH
MARKET
North America
WIRING DIAGRAM - #193832
OWNER'S GUIDE - # 218942600
SERVICE DATA SHEET - # 218755000
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
almond
R134a System
white
Publication No.
5995330957
991213
-EN/SERVICE /ECL
357
REFRIGERATOR
VOLTS
115
115
REFRIGERATOR
Model No.
FRT21NRH
©1999 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire FRT21NRH
Summary of Contents for Frigidaire FRT21NRH
- Page 1 FACTORY PARTS CATALOG REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21NRHD0 FRT21NRH R134a System almond FRT21NRHW0 FRT21NRH R134a System white MARKET North America WIRING DIAGRAM - #193832 OWNER’S GUIDE - # 218942600 SERVICE DATA SHEET - # 218755000 REFRIGERATOR Model No.
- Page 2 Publication No. FRT21NRH 5995330957 DOOR 12/99...
- Page 3 FRT21NRH Publication No. 5995330957 DOOR A = FRT21NRH (FRT21NRHW0) B = FRT21NRH (FRT21NRHD0) POS. NO PART NO DESCRIPTION 215608913 Gasket-frzr door,white ,magnetic 218730609 Gasket-refr door,white ,magnetic 215393201 Panel-inner door,refr 218763644 Rack-door,23.09" x 2.04" 218763643 Rack-door,22.51" x 2.04" 218763642 Rack-door,9.24" x 2.04" 218758601 Support-door rack,RH/LH 218809701...
- Page 4 Publication No. FRT21NRH 5995330957 CABINET 12/99...
- Page 5 FRT21NRH Publication No. 5995330957 CABINET A = FRT21NRH (FRT21NRHW0) B = FRT21NRH (FRT21NRHD0) POS. NO PART NO DESCRIPTION 5304402655 Cover-fan 5303307351 Knob-damper control 5303001028 Nut,push-on 218722200 Damper-fan cover,black 218649000 Fan Blade,black 5300157666 Bushing-motor mtg,(2) 5304414684 Bracket-motor mtg,front 218802800 Cover-evap coil 5303209814 Nut,"U"...
- Page 6 Publication No. FRT21NRH 5995330957 SHELVES 12/99...
- Page 7 FRT21NRH Publication No. 5995330957 SHELVES A = FRT21NRH (FRT21NRHW0) B = FRT21NRH (FRT21NRHD0) POS. NO PART NO DESCRIPTION 218651900 Mullion,white 218651901 Mullion,almond 218781002 Heater-mullion 218845602 Tapping Plate,mullion mtg ,(2) 218866101 Top Panel-refr 218909706 Divider,styrofoam ,w/foil tape 218878600 Wiring Harness,control/divider 218865900 Bottom Panel-frzr 215667501 Tray-ice,plastic...
- Page 8 Publication No. FRT21NRH 5995330957 SYSTEM 12/99...
- Page 9 FRT21NRH Publication No. 5995330957 SYSTEM A = FRT21NRH (FRT21NRHW0) B = FRT21NRH (FRT21NRHD0) POS. NO PART NO DESCRIPTION 218657100 Condenser 5304406039 Spacer-tube,5/8 OD x 3" lg 5304406040 Spacer-tube,5/8 OD x 12" lg 5304406721 Spacer-cond tube,round ,5/8 OD x .81"lg 5304406722 Spacer-tube,5/8 OD x 2"...
-
Page 10: Wiring Schematic
Publication No. FRT21NRH 5995330957 WIRING SCHEMATIC 12/99... -
Page 11: Wiring Diagram
FRT21NRH Publication No. 5995330957 WIRING DIAGRAM # = Fast-moving Parts 12/99 * = Non-Illustrated Parts...
