Frigidaire FRT21C5A Factory Parts Catalog
Top mount refrigerator r134a series
Hide thumbs
Also See for FRT21C5A:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
Download this manual
See also:
Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT21C5AQ7
FRT21C5A
FRT21C5AQ8
FRT21C5A
FRT21C5AW7
FRT21C5A
FRT21C5AW8
FRT21C5A
MARKET
North America
ELECTROLUX HOME PRODUCTS,INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
bisque
R134a
white
R134a
white
Publication No.
5995398731
031111
-EN/SERVICE/KHB
357
VOLTS
115
115
115
115
©2003 Electrolux Home Products, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire FRT21C5A
Summary of Contents for Frigidaire FRT21C5A
- Page 1 PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21C5AQ7 FRT21C5A R134a bisque FRT21C5AQ8 FRT21C5A R134a bisque FRT21C5AW7 FRT21C5A R134a white FRT21C5AW8 FRT21C5A R134a white MARKET North America ELECTROLUX HOME PRODUCTS,INC. P.O. Box 212378, Augusta, GA 30917 Publication No. 5995398731 031111 -EN/SERVICE/KHB ©2003 Electrolux Home Products, Inc.
- Page 2 Publication No. FRT21C5A 5995398731 DOOR 11/03...
- Page 3 FRT21C5A Publication No. 5995398731 DOOR A = FRT21C5A (FRT21C5AQ7) B = FRT21C5A (FRT21C5AQ8) C = FRT21C5A (FRT21C5AW7) D = FRT21C5A (FRT21C5AW8) POS. NO PART NO DESCRIPTION 240514607 A B C D Gasket,seal ,white ,frzr door ,magnetic 240514608 A B C D Gasket,seal ,white ,refr door ,magnetic 240534901 A B C D...
- Page 4 Publication No. FRT21C5A 5995398731 CABINET 11/03...
- Page 5 FRT21C5A Publication No. 5995398731 CABINET A = FRT21C5A (FRT21C5AQ7) B = FRT21C5A (FRT21C5AQ8) C = FRT21C5A (FRT21C5AW7) D = FRT21C5A (FRT21C5AW8) POS. NO PART NO DESCRIPTION 240355402 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D Nut,push-on 240367401...
- Page 6 Publication No. FRT21C5A 5995398731 SHELVES 11/03...
- Page 7 FRT21C5A Publication No. 5995398731 SHELVES A = FRT21C5A (FRT21C5AQ7) B = FRT21C5A (FRT21C5AQ8) C = FRT21C5A (FRT21C5AW7) D = FRT21C5A (FRT21C5AW8) POS. NO PART NO DESCRIPTION 215667501 A B C D Tray,ice cube ,plastic 240358003 A B C D Shelf,freezer ,full-width ,wire 5303299664 A B C D Spacer,shelf...
- Page 8 Publication No. FRT21C5A 5995398731 SYSTEM 11/03...
- Page 9 FRT21C5A Publication No. 5995398731 SYSTEM A = FRT21C5A (FRT21C5AQ7) B = FRT21C5A (FRT21C5AQ8) C = FRT21C5A (FRT21C5AW7) D = FRT21C5A (FRT21C5AW8) POS. NO PART NO DESCRIPTION 240444401 A B C D Condenser,dynamic 218944001 A B C D Drier-filter,R134a System 240581701 A B C D Harness-wiring, machine compt 6* #...
-
Page 10: Wiring Schematic
Publication No. FRT21C5A 5995398731 WIRING SCHEMATIC 11/03... -
Page 11: Wiring Diagram
FRT21C5A Publication No. 5995398731 WIRING DIAGRAM # = Fast-moving Parts 11/03 * = Non-Illustrated Parts...
