Frigidaire FRT21C5A Factory Parts Catalog
Top mount refrigerator r134a series
Hide thumbs
Also See for FRT21C5A:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
Download this manual
See also:
Factory Parts Catalog
N05L00004.eps N05DBDCKA0.eps N05BBAABA6.eps N05SAAAEA13.eps
N05CABBAB6.eps
240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FRT21C5AQF
Series
R134a
Color
bisque
Volts
115
Wiring Diagram
240398801
Owner's Guide
240400112
Market
North America
Service Data Sheet
240379014
Installation Instructions 240568300
Publication No.
5995427118
05/01/19
(EN/SERVICE/DCS)
357
Copyright
TOP-MOUNT
REFRIGERATOR
Model No.
FRT21C5A
©
All rights reserved.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21C5A
Summary of Contents for Frigidaire FRT21C5A
- Page 1 Product No. FRT21C5AQF Series R134a Color bisque Volts Wiring Diagram 240398801 Owner's Guide 240400112 Market North America Service Data Sheet 240379014 Installation Instructions 240568300 TOP-MOUNT N05L00004.eps N05DBDCKA0.eps N05BBAABA6.eps N05SAAAEA13.eps REFRIGERATOR N05CABBAB6.eps 240398801.eps 240398601.eps ELECTROLUX HOME PRODUCTS, INC. Model No. P.O. Box 212378, Augusta, GA 30917 FRT21C5A Publication No.
- Page 2 Publication No: 5995427118 FRT21C5AQF DOOR N05DBDCKA0 01/05...
- Page 3 FRT21C5AQF Publication No: 5995427118 DOOR POS. NO PART NO. DESCRIPTION 240514607 Gasket, seal, white, frzr door, magnetic 240514608 Gasket, seal, white, refr door, magnetic 240534901 Rack-door 240534701 Rack-door, 4B 240337703 Door-dairy, w/o graphics, clear 240534801 Rack-door 240381302 Plug-button, bisque, hinge brg hole, (2) 240450305 Door, frzr, bisque 240415203...
- Page 4 Publication No: 5995427118 FRT21C5AQF CABINET 01/05...
- Page 5 FRT21C5AQF Publication No: 5995427118 CABINET POS. NO PART NO. DESCRIPTION 240355402 Cover-fan 240367001 Knob-damper control 5303001028 Nut, push-on 241523701 Damper-fan cover 5308000010 Fan Blade, red, evaporator fan 5300157666 Bushing-motor mtg, (2) 5303292396 Bracket-motor mtg, front 240313610 Cover-evap coil, w/o light 240568606 Seal-coil cover 10*#...
- Page 6 Publication No: 5995427118 FRT21C5AQF SHELVES 01/05...
- Page 7 FRT21C5AQF Publication No: 5995427118 SHELVES POS. NO PART NO. DESCRIPTION 215667501 Tray, ice cube, plastic 240358003 Shelf, freezer, full-width, wire 240545901 Diffuser-air, top 240362601 Diffuser, air, bottom 241554901 Switch-light/lamp 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature 241500701 Socket-light/lamp 240368101 Control Box...
- Page 8 Publication No: 5995427118 FRT21C5AQF SYSTEM N05CABBAB6 01/05...
- Page 9 FRT21C5AQF Publication No: 5995427118 SYSTEM POS. NO PART NO. DESCRIPTION 240444401 Condenser, dynamic 218944001 Drier-filter, R134a System 240581701 Harness-wiring, machine compt 6* # 240388701 Wiring Harness, control box 6* # 240524701 Wiring Harness, freezer section 6* # 240581801 Harness-wiring, compressor 14 # 5303918247 Defrost Heater Kit...
-
Page 10: Wiring Schematic
Publication No: 5995427118 FRT21C5AQF WIRING SCHEMATIC 01/05... -
Page 11: Wiring Diagram
FRT21C5AQF Publication No: 5995427118 WIRING DIAGRAM 01/05 # Functional Parts * Non-Illustrated Parts...
