Frigidaire FRT17A2A Factory Parts Catalog

Frigidaire FRT17A2A Factory Parts Catalog

Top-mount refrigerator
Hide thumbs Also See for FRT17A2A:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT17A2AQ2
FRT17A2A
FRT17A2AW2
FRT17A2A
MARKET
North America
ENERGY GUIDE - 218791450
OWNER'S GUIDE - # 240400107
SERVICE DATA SHEET - # 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a, Static
bisque
R134a, Static
white
Publication No.
5995380010
021022
-EN/SERVICE/KHB
390
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT17A2A
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT17A2A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT17A2A

Summary of Contents for Frigidaire FRT17A2A

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT17A2AQ2 FRT17A2A R134a, Static bisque FRT17A2AW2 FRT17A2A R134a, Static white MARKET North America ENERGY GUIDE - 218791450 OWNER’S GUIDE - # 240400107 SERVICE DATA SHEET - # 240379010 TOP MOUNT REFRIGERATOR Model No.
  • Page 2 Publication No. FRT17A2A 5995380010 DOOR 10/02...
  • Page 3 FRT17A2A Publication No. 5995380010 DOOR A = FRT17A2A (FRT17A2AQ2) B = FRT17A2A (FRT17A2AW2) POS. NO PART NO DESCRIPTION 240542101 Gasket,frzr door seal ,white ,magnetic 240542104 Gasket-refr door,white ,magnetic 240535101 Rack-door 240337701 Door-dairy,w/o graphics ,white 240535001 Rack-door 240381302 Plug-button,bisque ,hinge brg hole ,(2) 240381301 Plug-button,white ,hinge brg hole ,(2) 240433502...
  • Page 4 Publication No. FRT17A2A 5995380010 CABINET 03/02...
  • Page 5 FRT17A2A Publication No. 5995380010 CABINET A = FRT17A2A (FRT17A2AQ2) B = FRT17A2A (FRT17A2AW2) POS. NO PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462004 Cover-evap coil 240532101 Seal,coil cover...
  • Page 6 Publication No. FRT17A2A 5995380010 SHELVES 10/02...
  • Page 7 FRT17A2A Publication No. 5995380010 SHELVES A = FRT17A2A (FRT17A2AQ2) B = FRT17A2A (FRT17A2AW2) POS. NO PART NO DESCRIPTION 240545001 Diffuser,air ,top 240362601 Diffuser,air ,bottom 240505801 Switch,light/lamp 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V,miniature 241500701 Socket-light/lamp 240368001 Control Box 17*# 240388701 Wiring Harness, control box...
  • Page 8 Publication No. FRT17A2A 5995380010 SYSTEM 10/02...
  • Page 9 FRT17A2A Publication No. 5995380010 SYSTEM A = FRT17A2A (FRT17A2AQ2) B = FRT17A2A (FRT17A2AW2) POS. NO PART NO DESCRIPTION 240406403 Condenser,static 240405201 Grommet,rubber ,black ,cond tube/wire 5303208866 Spacer,condenser tube ,black 5308000296 Bracket,condenser mtg ,(4) 5308009617 Washer,ext tooth lock ,#10 ,grounding 218944001 Drier-filter,R134a System 240375401 Wiring Harness,mach compt, w/service cord...

  • Page 10: Wiring Schematic

    Publication No. FRT17A2A 5995380010 WIRING SCHEMATIC 10/02...

  • Page 11: Wiring Diagram

    FRT17A2A Publication No. 5995380010 WIRING DIAGRAM # = Fast-moving Parts 10/02 * = Non-Illustrated Parts...
