Toyota Sienna Quick Reference Manual page 9

07 Sienna PRG Inside 11/30/06
FEATURES/OPERATIONS
Doors-Power sliding (if equipped)
Instrument panel
On
ON/OFF switch
Push
Front overhead console
Open: Push
Close: Push again
NOTE:
• When the key is in the "ON" position, power
sliding doors will open only when gear selector is
in the "P" Park position, and doors are unlocked.
Refer to the Owner's Manual for more details.
• An alarm will sound if a sliding door is open and
the vehicle is shifted out of "Park."
• If battery is disconnected, the power sliding doors
need to be reinitialized. Refer to the Owner's
Manual for more details.
Door-Power back (if equipped)
Instrument panel
On
Off
Push
ON/OFF switch
NOTE: If battery is disconnected, the power back
door needs to be reinitialized. Refer to the Owner's
Manual for more details.
11:01 AM Page 12
Off
Center pillar
Front overhead console
Push
Open: Push
Close: Push again
12
Console box (if equipped)
Remove
Second row seat
Lock
release
lever
Auxiliary box
The console box can be removed and installed
between the front or second row seats.
To remove Open the auxiliary box on the rear
side, and pull the lock release lever. Lift the box
from the rear to release it from the hook.
To install Place the hook into the striker. Lower
box and push down to engage the rear lock.
Front seat console table (if equipped)
Clock
With manual
Air Conditioning system
H- Hour set
M- Minute set
13
all
Inst
Front seat
Lock
release
lever
With automatic
Air Conditioning system
