1 Controls, Ports and Indicators

Before operating your HP Cache Server Appliance, familiarize yourself with the
appliance's controls, ports, and indicators as described in this chapter.
The HP Cache Server Appliance hardware configuration and software has been
optimized at the factory. The power, LAN, and serial ports are the only
connections that are supported. Please contact your HP authorized reseller or HP
Support directly for more information.
NOTE

Front Panel

The front panel of the HP Cache Server Appliance provides the controls and
indicators commonly used when operating the appliance.
CD-ROM
SCSI Drives (3)
Reset
Switch
DO NOT USE
This appliance carries a whole unit exchange warranty. The
hardware, operating system and cache software have been
optimized at the factory. No upgrades or replacement of the
CPU, drives, memory or any other component are supported.
LED Indicators
Figure 1-1. sa2100/sa2150 Front Panel
Flexible Disk Drive
Power LED & Switch
Power Power
LED Switch
