OWNER'S MANUAL
32" TFT LCD DIGITAL TV WITH DVD PLAYER
HDLCDVD320A
If you purchase a universal remote control from your local retailer, please contact the remote
manufacturer for the required programming code.
When shipped from the factory, the TV/CABLE menu option is set to the "CABLE" (Cable Television) mode.
If not using CABLE, set this menu option to the "TV" position.
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL
FOR INFORMATION ON OUR OTHER PRODUCTS, PLEASE VISIT OUR WEBSITE AT
Before operating the unit, please read this manual thoroughly.
TV/CABLE MODE SELECTION
IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED
CUSTOMER SERVICE – 1-800-289-0980
ORION WEBSITE
www.orionsalesinc.com
ATTENTION
R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDLCDVD320A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sansui HDLCDVD320A

Summary of Contents for Sansui HDLCDVD320A

  • Page 1 OWNER’S MANUAL 32” TFT LCD DIGITAL TV WITH DVD PLAYER HDLCDVD320A ATTENTION If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the required programming code. TV/CABLE MODE SELECTION When shipped from the factory, the TV/CABLE menu option is set to the “CABLE” (Cable Television) mode. If not using CABLE, set this menu option to the “TV”...
  • Page 2 The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock. CAUTION: TO REDUCE THE RISK OF ELECTRIC The exclamation point within an...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a clean dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. 8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS (continued) EXAMPLE OF ANTENNA GROUNDING AS PER THE NATIONAL ELECTRICAL CODE ANTENNA LEAD IN WIRE GROUND CLAMP ANTENNA DISCHARGE UNIT (NEC SECTION 810-20) GROUNDING CONDUCTORS ELECTRIC SERVICE (NEC SECTION 810-21) EQUIPMENT GROUND CLAMPS POWER SERVICE GROUNDING NEC-NATIONAL ELECTRICAL CODE ELECTRODE SYSTEM S2898A (NEC ART 250, PART H)
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS (continued) CONDENSATION Moisture will form in the operating section of the player if the player is brought from cool surroundings into a warm room or if the temperature of the room rises suddenly. When this happens, player's performance will be impaired.

  • Page 6: Safety Precautions

    SAFETY PRECAUTIONS The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating. Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine. When placing on a shelf leave 10 cm (4 inches) free space around the entire unit.

  • Page 7: Features

    Features LCD color TV With DVD/CD player Unique space saving design combines a 32” LCD color TV and a DVD/CD player. A DVD disc has much more capacity, but is the same size as an audio CD disc. The Picture/Audio quality of a DVD exceeds other software.

  • Page 8: Table Of Contents

    Contents Before using your unit Playback operation Preparation ............. 28 IMPORTANT SAFETY INSTRUCTIONS ..3 Status display of disc ........28 SAFETY PRECAUTIONS ........ 6 Playback procedure ........29 IMPORTANT NOTICE ........6 Special playback ..........29 Features ............7 MP3/WMA/JPEG and Audio CD playback ..

  • Page 9: Disc

    Disc Playable discs Disc type and logo mark content CAUTION: • Only the left types of discs can be played on this unit. Audio DVD-ROM, CD-ROM, SVCD, CVD, VCD, etc. cannot be played. Video DVD Video • 8cm discs can be played directly. If an 8cm disc adapter is (moving used it will cause errors.

  • Page 10: Location Of Controls

    Location of controls VOLUME +/– buttons CHANNEL ▲/▼ buttons EJECT button MENU button SKIP button STOP button INPUT button PLAY button POWER button Front POWER POWER Remote sensor POWER indicator To display the menu screen. Press MENU button to display the menu screen. CHANNEL ▲/▼...
  • Page 11 Location of controls (continued) Rear COAXIAL DIGITAL AUDIO OUT jack RF (ANT) IN jack AV1 IN jacks • Bundle cables with a cable clip. Left side PC IN jack PC/HDMI AUDIO IN jack HDMI1 IN jack HDMI2 IN jack COMPONENT IN jacks AV2 IN jacks DISC slot...

  • Page 12: Remote Control

    Remote control Page POWER Power On/Off 16,28,29 DISPLAY/– Call TV information 17,19 Call DVD information Input “–” for digital channels TV/DVD Switch between TV/AV and DVD 16,28,29 5 (EJECT) Eject a disc 29,38 Direct channel selection of TV Input setting 20,21,30,33 Enter a password 18~20,37~38...

  • Page 13: Power Source

    Remote control (continued) Inserting Batteries Open the battery compart- Install two “AAA” batteries, Replace the compartment ment cover in the direction of paying attention to the polarity cover. the arrow. diagram in the battery compartment. Operation • Aim the remote control at the remote sensor and press control buttons to operate.

  • Page 14: Antenna Connections

    Antenna connections If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a Cable TV service, see page 15 for Cable TV connections. Combination VHF/UHF Antenna (Single 75 ohm cable or 300 ohm twin-lead wire) Connect the 75 ohm cable from the combination Antenna Antenna...

  • Page 15: Cable Tv Connections

    Cable TV connections This TV/DVD has an extended tuning range and can tune most cable channels without using a Cable TV Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which is generally provided by the Cable TV company.

  • Page 16: Tv Operation

    Setting the on-screen Press the Direct Channel Selection (0-9,–) buttons to select the channel. display language To select analog channels When the TV/CABLE menu option is in the TV You can choose from three different languages position, all channels can be instantly selected by (English, French and Spanish) for the on-screen using two buttons.

  • Page 17: Memorizing Channels

    briefly every ten minutes to remind you that the sleep timer is operating. To confirm the sleep timer setting, Press and release CH . The channel auto- press SLEEP and the remaining time will be dis- matically stops at the next channel set into memory. played for a few seconds.

  • Page 18: Setting The V-Chip

    CABLE CHART The chart below is typical of many cable system A D D / D E L E T E A D D I N G C H A N N E L channel allocations. A D D / D E L E T E S I G N A L A N A L O G A D D /...
  • Page 19 Press ▲ or ▼ to select “MOVIE RATING”, then Select and enter a password (4 digits) using Number buttons (0-9), then press ENTER. press or . The RATING SET menu appears. LOCKS RATING SET NEW PASSWORD ON/OFF PG-13 NC-17 [0-9] : SELECT ENTER : SET :SELECT :ADJUST...

  • Page 20: Labeling Channels

    If the character which you desire appears, press To change the password ENTER. Repeat this step to enter the rest of the characters. Press SETUP/TV MENU in the TV mode. If you would like a blank space in the label name, The TV menu screen will appear.

  • Page 21: Labeling The Video Input Source

    Labeling the video input Press or . The PICTURE SIZE menu will appear. Press ▲/▼ or a Number button (0-4) to source select the desired picture size, as described below and on the next page, then press ENTER. The video label feature allows you to label each P I C T U R E S I Z E input source for your unit.

  • Page 22: Setting The Picture Scroll

    To raise the picture, press ▲. CINEMA WIDE3 picture size (for letter box programs with subtitles) To fill the width of the screen, it is extended horizon- tally. However; it is only slightly extended at the top and the bottom. SCROLL ADJUSTMENT The top and bottom edges of the picture may be hidden.

  • Page 23: Using The Aspect Feature

    Using the aspect feature Mode Picture Quality SPORTS Bright and dynamic picture When the ASPECT feature is set to ON and the (factory-set) unit receives a 480i signal, the picture size is STANDARD Standard picture quality (factory- automatically selected (as described in the set) following table).

  • Page 24: Selecting The Color Temperature

    Selecting the color Resetting your picture temperature adjustments The RESET function returns your picture quality Change the picture quality by selecting from adjustments to the following factory settings: three preset color temperatures—COOL, MEDIUM, and WARM: PICTURE PREFERENCE .. SPORTS TINT ........center (0) BRIGHTNESS ....

  • Page 25: Cc Advanced

    You can select from among the following items and Press EXIT to return to the normal screen. parameters. NOTE: TEXT SIZE: AUTO, SMALL, STANDARD, • If the program or video you selected is not closed- LARGE captioned, no captions will display on-screen. TEXT TYPE: AUTO, DEFAULT, MONO W.

  • Page 26: Sound Control Adjustment

    Press ▲ or ▼ to select “HDMI1”, then press Press EXIT to return to the normal screen. to select “HDMI” or “DVI”. NOTE: • Generally you can leave your TV in stereo mode because the TV automatically outputs the type of sound being broadcast (stereo or mono).

  • Page 27: Resetting Your Audio Adjustments

    Setting the auto shut off AUDIO If the AUTO SHUT OFF feature is ON, and a station being viewed stops broadcasting, the TV HDMI1 HDMI AUDIO LANGUAGE DIGITAL OUTPUT will automatically shut itself off after 15 minutes. / DOLBY DIGITAL RESET Press SETUP/TV MENU, then press select...

  • Page 28: Preparation

    Picture menu setting: Press ▲ or ▼ to select “RESET”, then press BRIGHTNESS: To adjust the brightness of PC Monitor-screen. Preparation CONTRAST: To adjust the contrast of PC Monitor-screen. HOR POSITION: To adjust the horizontal The following pages describe the setup/operation position of the image on the in DVD mode.

  • Page 29: Playback Procedure

    • If you place a single-faced disc label backwards (i.e. Playback procedure the wrong way) “Reading” will appear in the display and then “Incorrect Disc” will be displayed. • Some playback operations of DVDs may be inten- tionally fixed by software producers. Since this unit Press TV/DVD to select DVD mode.

  • Page 30: Mp3/Wma/Jpeg And Audio Cd Playback

    MP3/WMA/JPEG and A file browser screen will appear on the TV screen. Audio CD playback Operation status File number Elapsed time Selected file name This player can play back MP3/WMA/JPEG-data 1/15 00:00:00 /MP3-5.MP3 which has been recorded on CD-R or CD-RW. To MP3-5 Select Files produce MP3/WMA/JPEG-data, you need a Win-...

  • Page 31: Setting The Jpeg Interval

    JPEG CD playback Setting the JPEG interval In the file browser, press to select the You can continuously play back all JPEG files desired JPEG file. automatically. To display a thumbnail list, press DVD MENU. Press to select the desired file. Press SETUP/TV MENU in the stop mode.

  • Page 32: Repeat Playback (Cd)

    Press to select “Program View”, then press ENTER. Program View shows only the programed Folder-1 Select Files files that you have added in Step 2. Folder-2 Repeat :Off MP3-1 Mode :Random MP3-2 MP3-3 WMA-1 Folder-1 MP3-1 Edit Mode Edit Mode JPEG Preview WMA-2 Folder-2...

  • Page 33: Repeat Playback

    Press to select the “Time”, “Title/track” or “Chapter”. Press Number buttons (0–9) to input the number. • If you input a wrong number, press CANCEL. To resume normal playback press REPEAT A-B • Refer to the package supplied with the disc to again.

  • Page 34: Changing Soundtrack Language

    Press SUBTITLE during playback until “Off” appears. Press ENTER. Playback starts from the marked scene. To Cancel the Mark Press MARKER. Changing the subtitle language Press to select the Marker 1-3. You can select the language when playing back a disc recorded with multi-lingual subtitles.

  • Page 35: Title Selection

    English, Francais, Espanol : Title selection The selected language will be heard or seen. Other: Two or more titles are recorded on some discs. Other language can be selected (see the If the title menu is recorded on the disc, you can “Language code list”...

  • Page 36: Setting On Screen Display

    Setting on screen display Film: Suitable for playback of film content pictures. Video: On screen display can be switched on or off when Suitable for playback of video content pictures. you press the DISPLAY button. Press SETUP/TV MENU or RETURN to remove Press SETUP/TV MENU in the stop mode or No the menu screen.

  • Page 37: Parental Control Setting

    Night Mode : Off Parental Digital Out Password : Change Bitstream PCM: Change Dolby Digital to PCM Press SETUP/TV MENU or RETURN to remove for the output. the Menu screen. Select when connected to a 2 channel digital stereo amplifier. NOTE: Bitstream: Disc audio bitstream data will be •...

  • Page 38: Temporary Disabling Of Rating Level By Dvd Disc

    Temporary disabling of rating level by DVD disc Some pre-recorded DVD discs may attempt to temporarily cancel the rating level that you have set. You will be given the option to allow or not allow the override. Load a DVD disc (see page 29). If the DVD disc has been designed to temporarily cancel the Rating level, the screen which follows the “Reading”...

  • Page 39: Language Code List

    Language code list Enter the appropriate code number for the initial settings “Menu”, “Subtitle” and/or “Audio” (see page 35). Language Name Code Language Name Code Language Name Code Language Name Code Abkhazian 1112 Fiji 1620 Lingala 2224 Singhalese 2919 Afar 1111 Finnish 1619...

  • Page 40: Connections To Other Equipment

    Connections to other equipment The exact arrangement you use to interconnect various video and audio components to this unit is dependent on the model and features of each component. Check the Owner's Manual provided with each component for the location of video and audio inputs and outputs. To connect the LCD TV/DVD to a VCR Rear of the unit To AUDIO/VIDEO IN 1 (or 2)
  • Page 41 Connections to other equipment (continued) To connect a HDMI or a DVI device to the unit The HDMI input receives digital audio and uncompressed video from a HDMI device or uncompressed digital video from a DVI device. When you connect to a DVI device with a HDMI-to-DVI adapter cable, it transfers only video signal. Separate analog audio cords required.
  • Page 42 Connections to other equipment (continued) To connect the TV/DVD to a camcorder, or a TV Game To playback from a camcorder, connect the camcorder to the unit as shown. This unit can also be used as a display device for many video games. However, due to the wide variety of signals generated by these devices and subsequent hook-up variations required, they have not all been included in the suggested connection diagrams.

  • Page 43: Reception Disturbances

    Reception disturbances Most types of television interference can be remedied by adjusting the height and position of the VHF/ UHF antenna. Outdoor antennas are recommended for best results. The most common types of television interference are shown below. If one of these symptoms appear when the TV/DVD is connected to a Cable TV system, the disturbance may be caused by the local Cable TV company broadcast.

  • Page 44: Problems And Troubleshooting

    Problems and troubleshooting Use the following check list for troubleshooting when you have problems with your TV/DVD. Consult your local dealer or service outlet if problems persist. Be sure all connections are properly made when using with other units. SYMPTOMS POSSIBLE SOLUTIONS PAGE POWER...
  • Page 45 Problems and troubleshooting (continued) SYMPTOMS POSSIBLE SOLUTIONS PAGE • No disc is inserted. Playback doesn’t start. • The disc may be dirty. Clean up the disc. • The unit cannot play CD-ROMs, etc. No picture. • TV/DVD selector is not set correctly. •...

  • Page 46: Specifications

    Specifications GENERAL Power supply: AC 120V 60Hz Power consumption: Operation: 180W Stand by: 1W Weight: 15.1 kg (33.3 lbs) Dimensions: Width : 822 mm (32-3/8 inches) Height : 604 mm (23-3/4 inches) Depth : 282.5 mm (11-1/8 inches) Operating temperature: 5˚C - 40˚C Operating humidity: Less than 80%...

  • Page 47: Limited Warranty

    limited WARRANTY 32” TFT LCD TV WITH DVD PLAYER ORION warrants this product to be free from manufacturing defects in material and workmanship under normal use and conditions for a period of 90 days from date of original purchase in the United States. Should service be necessary under this warranty for any reason due to a manufacturing defect or malfunc- tion during the first ninety (90) days from date of original purchase, ORION will provide in-home repair service by an ORION authorized Independent Service Center at no charge.
  • Page 48 J5Z80501A SH 07/07 Printed in Thailand...
