Frigidaire FRS6HR4H Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRS6HR4H
  6. Factory parts catalog
Frigidaire FRS6HR4H Factory Parts Catalog

Frigidaire FRS6HR4H Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS6HR4H:
Table of Contents

Advertisement

Quick Links

Download this manual
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet 240389616
N58L00001.eps N58FAAAAB4.eps N58RAAABB4.eps N58BAAAAA0.eps
N58SJCACB2.eps N58TAAAAA7.eps N58CAAAAC1.eps N58XDAAAA1.eps
N58YBAAAA5.eps N58I1151.eps W241526901A.eps W241708401.eps
S241526901A.eps S241708401.eps
u
x Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
FRS6HR4HB3 FRS6HR4HB4 FRS6HR4HB5 FRS6HR4HW3 FRS6HR4HW4 FRS6HR4HW5
R134a
R134a
R134a
black
black
black
115
115
115
241526901
241526901
241708401
241856000
241856000
241856000
North America North America North America North America North America North America
241649298
241649298
241649298
240389616
240389629
Publication No.
5995496295
07/07/31
(EN/SERVICE/KHB)
137
R134a
R134a
R134a
white
white
white
115
115
115
241526901
241526901
241708401
241856000
241856000
241856000
241649298
241649298
241649298
240389616
240389616
240389629
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS6HR4H
©
Copyright
2007 Home Pr
All rights reserved.
oducts, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS6HR4H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRS6HR4H

Summary of Contents for Frigidaire FRS6HR4H

  • Page 1 Product No. FRS6HR4HB3 FRS6HR4HB4 FRS6HR4HB5 FRS6HR4HW3 FRS6HR4HW4 FRS6HR4HW5 Series R134a R134a R134a R134a R134a R134a Color black black black white white white Volts Wiring Diagram 241526901 241526901 241708401 241526901 241526901 241708401 Owner's Guide 241856000 241856000 241856000 241856000 241856000 241856000 Market North America North America North America North America North America North America Energy Guide 241649298...

  • Page 2: Freezer Door

    Publication No: 5995496295 FRS6HR4H FREEZER DOOR 07/07...
  • Page 3 FRS6HR4H Publication No: 5995496295 FREEZER DOOR Model Index: A FRS6HR4H (FRS6HR4HB3) B FRS6HR4H (FRS6HR4HB4) C FRS6HR4H (FRS6HR4HB5) D FRS6HR4H (FRS6HR4HW3) E FRS6HR4H (FRS6HR4HW4) F FRS6HR4H (FRS6HR4HW5) POS. NO PART NO. DESCRIPTION 241786006 A B C - - - Gasket-frzr door, black, magnetic 241786002 - - - D E F Gasket-frzr door, white, magnetic...

  • Page 4: Refrigerator Door

    Publication No: 5995496295 FRS6HR4H REFRIGERATOR DOOR 07/07...
  • Page 5 FRS6HR4H Publication No: 5995496295 REFRIGERATOR DOOR Model Index: A FRS6HR4H (FRS6HR4HB3) B FRS6HR4H (FRS6HR4HB4) C FRS6HR4H (FRS6HR4HB5) D FRS6HR4H (FRS6HR4HW3) E FRS6HR4H (FRS6HR4HW4) F FRS6HR4H (FRS6HR4HW5) POS. NO PART NO. DESCRIPTION 241786005 A B C - - - Gasket-refr door, black, magnetic 241786001 - - - D E F Gasket-refr door, white, magnetic...
  • Page 6 Publication No: 5995496295 FRS6HR4H CABINET 07/07...
  • Page 7 FRS6HR4H Publication No: 5995496295 CABINET Model Index: A FRS6HR4H (FRS6HR4HB3) B FRS6HR4H (FRS6HR4HB4) C FRS6HR4H (FRS6HR4HB5) D FRS6HR4H (FRS6HR4HW3) E FRS6HR4H (FRS6HR4HW4) F FRS6HR4H (FRS6HR4HW5) POS. NO PART NO. DESCRIPTION 240435912 A B C D E F Cover-air duct 240475911 A - - D - - Cover-evap coil, lower 241719711...
  • Page 8 Publication No: 5995496295 FRS6HR4H SHELVES N58SJCACB2 07/07...
  • Page 9 FRS6HR4H Publication No: 5995496295 SHELVES Model Index: A FRS6HR4H (FRS6HR4HB3) B FRS6HR4H (FRS6HR4HB4) C FRS6HR4H (FRS6HR4HB5) D FRS6HR4H (FRS6HR4HW3) E FRS6HR4H (FRS6HR4HW4) F FRS6HR4H (FRS6HR4HW5) POS. NO PART NO. DESCRIPTION 241657602 A B C D E F Shelf, flip up, wire 241657502 A B C D E F Shelf, fixed, freezer...
  • Page 10 Publication No: 5995496295 FRS6HR4H CONTROLS N58TAAAAA7 07/07...
  • Page 11 FRS6HR4H Publication No: 5995496295 CONTROLS Model Index: A FRS6HR4H (FRS6HR4HB3) B FRS6HR4H (FRS6HR4HB4) C FRS6HR4H (FRS6HR4HB5) D FRS6HR4H (FRS6HR4HW3) E FRS6HR4H (FRS6HR4HW4) F FRS6HR4H (FRS6HR4HW5) POS. NO PART NO. DESCRIPTION 5308000010 A B C D E F Fan Blade, red, evaporator fan 215474201 A B C D E F Washer, "slinger", nylon, evap fan shaft...
  • Page 12 Publication No: 5995496295 FRS6HR4H SYSTEM N58CAAAAC1 07/07...
  • Page 13 FRS6HR4H Publication No: 5995496295 SYSTEM Model Index: A FRS6HR4H (FRS6HR4HB3) B FRS6HR4H (FRS6HR4HB4) C FRS6HR4H (FRS6HR4HB5) D FRS6HR4H (FRS6HR4HW3) E FRS6HR4H (FRS6HR4HW4) F FRS6HR4H (FRS6HR4HW5) POS. NO PART NO. DESCRIPTION 240333603 A B C D E F Condenser 218679607 A B C D E F Block-evap coil, styrofoam, (2) 218944001 A B C D E F...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995496295 FRS6HR4H ICE & WATER DISPENSER 07/07...
  • Page 15 FRS6HR4H Publication No: 5995496295 ICE & WATER DISPENSER Model Index: A FRS6HR4H (FRS6HR4HB3) B FRS6HR4H (FRS6HR4HB4) C FRS6HR4H (FRS6HR4HB5) D FRS6HR4H (FRS6HR4HW3) E FRS6HR4H (FRS6HR4HW4) F FRS6HR4H (FRS6HR4HW5) POS. NO PART NO. DESCRIPTION 218976409 A B C D E F Tube, water, door 218976419 A B C D E F...

  • Page 16: Ice Container

    Publication No: 5995496295 FRS6HR4H ICE CONTAINER 37A 34 34 33 N58YBAAAA5 07/07...
  • Page 17 FRS6HR4H Publication No: 5995496295 ICE CONTAINER Model Index: A FRS6HR4H (FRS6HR4HB3) B FRS6HR4H (FRS6HR4HB4) C FRS6HR4H (FRS6HR4HB5) D FRS6HR4H (FRS6HR4HW3) E FRS6HR4H (FRS6HR4HW4) F FRS6HR4H (FRS6HR4HW5) POS. NO PART NO. DESCRIPTION 241716101 A B C D E F Auger-ice 241685201 A B C D E F Cam-drive 241734001...

  • Page 18: Ice Maker

    Publication No: 5995496295 FRS6HR4H ICE MAKER 07/07...
  • Page 19 FRS6HR4H Publication No: 5995496295 ICE MAKER Model Index: A FRS6HR4H (FRS6HR4HB3) B FRS6HR4H (FRS6HR4HB4) C FRS6HR4H (FRS6HR4HB5) D FRS6HR4H (FRS6HR4HW3) E FRS6HR4H (FRS6HR4HW4) F FRS6HR4H (FRS6HR4HW5) POS. NO PART NO. DESCRIPTION 218976409 A B C D E F Tube, water, door 218976419 A B C D E F Tube-water inlet, valve to door...
  • Page 20 Publication No: 5995496295 FRS6HR4H ICE MAKER 07/07...
  • Page 21 FRS6HR4H Publication No: 5995496295 ICE MAKER Model Index: A FRS6HR4H (FRS6HR4HB3) B FRS6HR4H (FRS6HR4HB4) C FRS6HR4H (FRS6HR4HB5) D FRS6HR4H (FRS6HR4HW3) E FRS6HR4H (FRS6HR4HW4) F FRS6HR4H (FRS6HR4HW5) POS. NO PART NO. DESCRIPTION 241796401 A B C D E F Tube-water fill, extension 55 # 241734301 A B C D E F...

  • Page 22: Wiring Schematic

    Publication No: 5995496295 FRS6HR4H WIRING SCHEMATIC 07/07...
  • Page 23 FRS6HR4H Publication No: 5995496295 WIRING SCHEMATIC 07/07 # Functional Parts * Non-Illustrated Parts...

  • Page 24: Wiring Diagram

    Publication No: 5995496295 FRS6HR4H WIRING DIAGRAM 07/07...
  • Page 25 FRS6HR4H Publication No: 5995496295 WIRING DIAGRAM 07/07 # Functional Parts * Non-Illustrated Parts...
