Frigidaire FRS6HF55KW - 26 cu. Ft. Refrigerator Service Data Sheet

Frigidaire FRS6HF55KW - 26 cu. Ft. Refrigerator Service Data Sheet

Parts catalog
Hide thumbs Also See for FRS6HF55KW - 26 cu. Ft. Refrigerator:

Advertisement

Table of Contents

See also: Installation Manual
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet 240389636
N58L00001.eps N58FCCBBC5.eps N58RCCBBB17.eps N58BAAAAB1.eps
N58SJCHBD10.eps N58TAAAAB4.eps N58CAAAAC10.eps N58XBAAAB1.eps
N58YBAAAA5.eps N58I1151-1.eps W241970401.eps S241970401.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
FRS6HF55KB0 FRS6HF55KM0 FRS6HF55KQ0 FRS6HF55KS0 FRS6HF55KW0
R134a
R134a
R134a
black
silver mist
bisque
115
115
115
241970401
241970401
241970401
241856000
241856000
241856000
North America North America
North America
241935593
241935593
241935593
240389636
240389636
Publication No.
5995535126
09/03/11
(EN/SERVICE/DCS)
137
R134a
R134a
stainless
white
115
115
241970401
241970401
241856000
241856000
North America North America
241935593
241935593
240389636
240389636
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS6HF55K
©
Copyright
2009 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS6HF55KW - 26 cu. Ft. Refrigerator

Summary of Contents for Frigidaire FRS6HF55KW - 26 cu. Ft. Refrigerator

  • Page 1 Product No. FRS6HF55KB0 FRS6HF55KM0 FRS6HF55KQ0 FRS6HF55KS0 FRS6HF55KW0 Series R134a R134a R134a R134a R134a Color black silver mist bisque stainless white Volts Wiring Diagram 241970401 241970401 241970401 241970401 241970401 Owner's Guide 241856000 241856000 241856000 241856000 241856000 Market North America North America North America North America North America Energy Guide...

  • Page 2: Freezer Door

    Publication No: 5995535126 FRS6HF55K FREEZER DOOR Stainless Handle N58FCCBBC5 03/09...
  • Page 3 FRS6HF55K Publication No: 5995535126 FREEZER DOOR Model Index: A FRS6HF55K (FRS6HF55KB0) B FRS6HF55K (FRS6HF55KM0) C FRS6HF55K (FRS6HF55KQ0) D FRS6HF55K (FRS6HF55KS0) E FRS6HF55K (FRS6HF55KW0) POS. NO PART NO. DESCRIPTION 241786006 A B - D - Gasket-frzr door, black, magnetic 241786002 - - C - E Gasket-frzr door, white, magnetic 240334201 A B C D E...

  • Page 4: Refrigerator Door

    Publication No: 5995535126 FRS6HF55K REFRIGERATOR DOOR Stainless Handle N58RCCBBB17 03/09...
  • Page 5 FRS6HF55K Publication No: 5995535126 REFRIGERATOR DOOR Model Index: A FRS6HF55K (FRS6HF55KB0) B FRS6HF55K (FRS6HF55KM0) C FRS6HF55K (FRS6HF55KQ0) D FRS6HF55K (FRS6HF55KS0) E FRS6HF55K (FRS6HF55KW0) POS. NO PART NO. DESCRIPTION 241786005 A B - D - Gasket-refr door, black, magnetic 241786001 - - C - E Gasket-refr door, white, magnetic 240323002 A B C D E...
  • Page 6 Publication No: 5995535126 FRS6HF55K CABINET N58BAAAAB1 03/09...
  • Page 7 FRS6HF55K Publication No: 5995535126 CABINET Model Index: A FRS6HF55K (FRS6HF55KB0) B FRS6HF55K (FRS6HF55KM0) C FRS6HF55K (FRS6HF55KQ0) D FRS6HF55K (FRS6HF55KS0) E FRS6HF55K (FRS6HF55KW0) POS. NO PART NO. DESCRIPTION 240435912 A B C D E Cover-air duct 241719711 A B C D E Cover-evap coil, lower 5303208309 A B C D E...
  • Page 8 Publication No: 5995535126 FRS6HF55K SHELVES N58SJCHBD10 03/09...
  • Page 9 FRS6HF55K Publication No: 5995535126 SHELVES Model Index: A FRS6HF55K (FRS6HF55KB0) B FRS6HF55K (FRS6HF55KM0) C FRS6HF55K (FRS6HF55KQ0) D FRS6HF55K (FRS6HF55KS0) E FRS6HF55K (FRS6HF55KW0) POS. NO PART NO. DESCRIPTION 241657602 A B C D E Shelf, flip up, wire 241657502 A B C D E Shelf, fixed, freezer 241657504 A B C D E...
  • Page 10 Publication No: 5995535126 FRS6HF55K CONTROLS 03/09...
  • Page 11 FRS6HF55K Publication No: 5995535126 CONTROLS Model Index: A FRS6HF55K (FRS6HF55KB0) B FRS6HF55K (FRS6HF55KM0) C FRS6HF55K (FRS6HF55KQ0) D FRS6HF55K (FRS6HF55KS0) E FRS6HF55K (FRS6HF55KW0) POS. NO PART NO. DESCRIPTION 5308000010 A B C D E Fan Blade, red, evaporator fan 215474201 A B C D E Washer, "slinger", nylon, evap fan shaft 241563601 A B C D E...
  • Page 12 Publication No: 5995535126 FRS6HF55K SYSTEM N58CAAAAC10 03/09...
  • Page 13 FRS6HF55K Publication No: 5995535126 SYSTEM Model Index: A FRS6HF55K (FRS6HF55KB0) B FRS6HF55K (FRS6HF55KM0) C FRS6HF55K (FRS6HF55KQ0) D FRS6HF55K (FRS6HF55KS0) E FRS6HF55K (FRS6HF55KW0) POS. NO PART NO. DESCRIPTION 240333603 A B C D E Condenser 218679607 A B C D E Block-evap coil, styrofoam, (2) 218944001 A B C D E...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995535126 FRS6HF55K ICE & WATER DISPENSER N58XBAAAB1 03/09...
  • Page 15 FRS6HF55K Publication No: 5995535126 ICE & WATER DISPENSER Model Index: A FRS6HF55K (FRS6HF55KB0) B FRS6HF55K (FRS6HF55KM0) C FRS6HF55K (FRS6HF55KQ0) D FRS6HF55K (FRS6HF55KS0) E FRS6HF55K (FRS6HF55KW0) POS. NO PART NO. DESCRIPTION 218976409 A B C D E Tube, water, door 218976418 A B C D E Tube-water inlet, inlet valve, to filter 218976419...

  • Page 16: Ice Container

    Publication No: 5995535126 FRS6HF55K ICE CONTAINER 37A 34 34 33 N58YBAAAA5 03/09...
  • Page 17 FRS6HF55K Publication No: 5995535126 ICE CONTAINER Model Index: A FRS6HF55K (FRS6HF55KB0) B FRS6HF55K (FRS6HF55KM0) C FRS6HF55K (FRS6HF55KQ0) D FRS6HF55K (FRS6HF55KS0) E FRS6HF55K (FRS6HF55KW0) POS. NO PART NO. DESCRIPTION 241716101 A B C D E Auger-ice 241685201 A B C D E Cam-drive 241734001 A B C D E...

  • Page 18: Ice Maker

    Publication No: 5995535126 FRS6HF55K ICE MAKER L O C L O C A R M A R M K E D K E D U N T U N T I N T I N T L A C L A C INSTALLATION PARTS N58I1151-1 03/09...
  • Page 19 FRS6HF55K Publication No: 5995535126 ICE MAKER Model Index: A FRS6HF55K (FRS6HF55KB0) B FRS6HF55K (FRS6HF55KM0) C FRS6HF55K (FRS6HF55KQ0) D FRS6HF55K (FRS6HF55KS0) E FRS6HF55K (FRS6HF55KW0) POS. NO PART NO. DESCRIPTION 218976409 A B C D E Tube, water, door 218976418 A B C D E Tube-water inlet, inlet valve, to filter 218976419 A B C D E...
  • Page 20 Publication No: 5995535126 FRS6HF55K ICE MAKER L O C L O C A R M A R M K E D K E D U N T U N T I N T I N T L A C L A C INSTALLATION PARTS N58I1151-1 03/09...
  • Page 21 FRS6HF55K Publication No: 5995535126 ICE MAKER Model Index: A FRS6HF55K (FRS6HF55KB0) B FRS6HF55K (FRS6HF55KM0) C FRS6HF55K (FRS6HF55KQ0) D FRS6HF55K (FRS6HF55KS0) E FRS6HF55K (FRS6HF55KW0) POS. NO PART NO. DESCRIPTION 55 # 241734301 A B C D E Valve-water, triple solenoid 218709101 A B C D E Screw, hex head, 10-32 x 0.500 240363602...

  • Page 22: Wiring Schematic

    Publication No: 5995535126 FRS6HF55K WIRING SCHEMATIC 03/09...

  • Page 23: Wiring Diagram

    FRS6HF55K Publication No: 5995535126 WIRING DIAGRAM 03/09 # Functional Parts * Non-Illustrated Parts...
