N58L00001.eps N58FCCBBC5.eps N58RCCBBB17.eps N58BAAAAA2.eps
N58SJCAAB15.eps N58TCAAAB4.eps N58CAAAAC10.eps N58XDAAAA1.eps
N58YBAAAA4.eps N58I1151.eps W241725001.eps S241725001.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
THIS CATALOG SUPERCEDES
PUBLICATION #5995505780.
Product No.
FRS6HF6JB0 FRS6HF6JQ0 FRS6HF6JW0 FRS6HF6JSB0
Series
R134a
Color
black
Volts
115
Wiring Diagram
241725001
Owner's Guide
241856000
Market
North America North America North America North America
Energy Guide
241868036
Service Data Sheet 240389633
Publication No.
5995519732
08/07/23
(EN/SERVICE/KHB)
R134a
R134a
R134a
bisque
white
stain/blk
115
115
115
241725001
241725001
241725001
241856000
241856000
241856000
241868036
241868036
241868036
240389633
240389633
240389633
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS6HF6J
137
©
Copyright
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire FRS6HF6J
Summary of Contents for Frigidaire FRS6HF6J
- Page 1 Product No. FRS6HF6JB0 FRS6HF6JQ0 FRS6HF6JW0 FRS6HF6JSB0 Series R134a R134a R134a R134a Color black bisque white stain/blk Volts Wiring Diagram 241725001 241725001 241725001 241725001 Owner's Guide 241856000 241856000 241856000 241856000 Market North America North America North America North America Energy Guide 241868036 241868036 241868036...
-
Page 2: Freezer Door
Publication No: 5995519732 FRS6HF6J FREEZER DOOR Stainless Handle N58FCCBBC5 07/08... - Page 3 FRS6HF6J Publication No: 5995519732 FREEZER DOOR Model Index: A FRS6HF6J (FRS6HF6JB0) B FRS6HF6J (FRS6HF6JQ0) C FRS6HF6J (FRS6HF6JW0) D FRS6HF6J (FRS6HF6JSB0) POS. NO PART NO. DESCRIPTION 241786006 A - - D Gasket-frzr door, black, magnetic 241786002 - B C - Gasket-frzr door, white, magnetic 240334201 A B C D Bin-door, frzr-upper...
-
Page 4: Refrigerator Door
Publication No: 5995519732 FRS6HF6J REFRIGERATOR DOOR Stainless Handle N58RCCBBB17 07/08... - Page 5 FRS6HF6J Publication No: 5995519732 REFRIGERATOR DOOR Model Index: A FRS6HF6J (FRS6HF6JB0) B FRS6HF6J (FRS6HF6JQ0) C FRS6HF6J (FRS6HF6JW0) D FRS6HF6J (FRS6HF6JSB0) POS. NO PART NO. DESCRIPTION 241786005 A - - D Gasket-refr door, black, magnetic 241786001 - B C - Gasket-refr door, white, magnetic 240323002 A B C D Bin-door, pseudo, bottom...
- Page 6 Publication No: 5995519732 FRS6HF6J CABINET N58BAAAAA2 07/08...
- Page 7 FRS6HF6J Publication No: 5995519732 CABINET Model Index: A FRS6HF6J (FRS6HF6JB0) B FRS6HF6J (FRS6HF6JQ0) C FRS6HF6J (FRS6HF6JW0) D FRS6HF6J (FRS6HF6JSB0) POS. NO PART NO. DESCRIPTION 240435912 A B C D Cover-air duct 241719711 A B C D Cover-evap coil, lower 5303208309 A B C D Plug-hole, factory test 240505801...
- Page 8 Publication No: 5995519732 FRS6HF6J SHELVES N58SJCAAB15 07/08...
- Page 9 FRS6HF6J Publication No: 5995519732 SHELVES Model Index: A FRS6HF6J (FRS6HF6JB0) B FRS6HF6J (FRS6HF6JQ0) C FRS6HF6J (FRS6HF6JW0) D FRS6HF6J (FRS6HF6JSB0) POS. NO PART NO. DESCRIPTION 241657602 A B C D Shelf, flip up, wire 241657502 A B C D Shelf, fixed, freezer 241657504 A B C D Shelf, fixed, upper, freezer...
- Page 10 Publication No: 5995519732 FRS6HF6J CONTROLS N58TCAAAB4 07/08...
- Page 11 FRS6HF6J Publication No: 5995519732 CONTROLS Model Index: A FRS6HF6J (FRS6HF6JB0) B FRS6HF6J (FRS6HF6JQ0) C FRS6HF6J (FRS6HF6JW0) D FRS6HF6J (FRS6HF6JSB0) POS. NO PART NO. DESCRIPTION 5308000010 A B C D Fan Blade, red, evaporator fan 215474201 A B C D Washer, "slinger", nylon, evap fan shaft 241563601 A B C D Bushing-motor mtg, (2)
- Page 12 Publication No: 5995519732 FRS6HF6J SYSTEM N58CAAAAC10 07/08...
- Page 13 FRS6HF6J Publication No: 5995519732 SYSTEM Model Index: A FRS6HF6J (FRS6HF6JB0) B FRS6HF6J (FRS6HF6JQ0) C FRS6HF6J (FRS6HF6JW0) D FRS6HF6J (FRS6HF6JSB0) POS. NO PART NO. DESCRIPTION 240333603 A B C D Condenser 218679607 A B C D Block-evap coil, styrofoam, (2) 218944001 A B C D Drier-filter, R134a System 241586801...
-
Page 14: Ice And Water Dispenser
Publication No: 5995519732 FRS6HF6J ICE & WATER DISPENSER 07/08... - Page 15 FRS6HF6J Publication No: 5995519732 ICE & WATER DISPENSER Model Index: A FRS6HF6J (FRS6HF6JB0) B FRS6HF6J (FRS6HF6JQ0) C FRS6HF6J (FRS6HF6JW0) D FRS6HF6J (FRS6HF6JSB0) POS. NO PART NO. DESCRIPTION 218976409 A B C D Tube, water, door 218976418 A B C D Tube-water inlet, inlet valve, to filter 218976419 A B C D...
-
Page 16: Ice Container
Publication No: 5995519732 FRS6HF6J ICE CONTAINER 37A 34 34 33 N58YBAAAA4 07/08... - Page 17 FRS6HF6J Publication No: 5995519732 ICE CONTAINER Model Index: A FRS6HF6J (FRS6HF6JB0) B FRS6HF6J (FRS6HF6JQ0) C FRS6HF6J (FRS6HF6JW0) D FRS6HF6J (FRS6HF6JSB0) POS. NO PART NO. DESCRIPTION 241716101 A B C D Auger-ice 241685201 A B C D Cam-drive 241734001 A B C D Container-ice, bucket only 241685101 A B C D...
-
Page 18: Ice Maker
Publication No: 5995519732 FRS6HF6J ICE MAKER 07/08... - Page 19 FRS6HF6J Publication No: 5995519732 ICE MAKER Model Index: A FRS6HF6J (FRS6HF6JB0) B FRS6HF6J (FRS6HF6JQ0) C FRS6HF6J (FRS6HF6JW0) D FRS6HF6J (FRS6HF6JSB0) POS. NO PART NO. DESCRIPTION 218976409 A B C D Tube, water, door 218976418 A B C D Tube-water inlet, inlet valve, to filter 218976419 A B C D Tube-water inlet, valve to door...
- Page 20 Publication No: 5995519732 FRS6HF6J ICE MAKER 07/08...
- Page 21 FRS6HF6J Publication No: 5995519732 ICE MAKER Model Index: A FRS6HF6J (FRS6HF6JB0) B FRS6HF6J (FRS6HF6JQ0) C FRS6HF6J (FRS6HF6JW0) D FRS6HF6J (FRS6HF6JSB0) POS. NO PART NO. DESCRIPTION 218709101 A B C D Screw, hex head, 10-32 x 0.500 240363602 A B C D Screw-shoulder 240542901 A B C D...
-
Page 22: Wiring Schematic
Publication No: 5995519732 FRS6HF6J WIRING SCHEMATIC AIR FILTER B E T A C O N T R O L FF THERMISTOR FRZ THERMISTOR 07/08... -
Page 23: Wiring Diagram
FRS6HF6J Publication No: 5995519732 WIRING DIAGRAM WHITE WHITE GRAY GRAY 07/08 # Functional Parts * Non-Illustrated Parts...
